Analogue addressable optical smoke detector
BSR-6155
with integrated isolator
TECHNICAL CHARACTERISTICS
COMMUNICATION PROTOCOL
MAIN VOLTAGE
STANDBY CONSUMPTION
ALARM CONSUMPTION
SMOKE CONCENTRATION SENSITIVITY
INDICATORS
OUTPUT
MAXIMUM LOOP CURRENT (Ic max, -L in/out)
MAXIMUM SWITCH CURRENT (Is max, -L in/out)
MAXIMUM SERIES RESISTANCE (Zc max, -L in-out)
MAXIMUM LEAKAGE CURRENT
IN ISOLATION MODE (I max, -L in/out)
L
ISOLATION VOLTAGE (Vso min-max)
RECONNECT VOLTAGE (Vsc min-max)
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATING TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for your trust in our products
Olympia Electronics - European manufacturer
GENERAL
The user have to read carefully the following instructions, in order to be properly informed and keep them
for future use.
The BSR-6155 is an analogue addressable smoke detector which integrates the function of optical
smoke detection and it can work with any fire panel supports Olympia A Protocol. It can be adjusted to
detect multiple levels of smoke offering flexibility and rich functionality. Also, it integrates a short circuit
isolation circuit which is automatically activated and disconnects the defective node from the remaining
loop, allowing it to be located by the panel.
The detector sends to the main panel an analogue value which depends on the concentration of smoke.
The value is 100 in concentration of 0.107dB/m (small amount of smoke) and increases proportionally to
120 in concentration of 0.300dB/m.
By default the panel is set to sound an alarm when the concentration of smoke is 0.107dB/m. The user
can change this setting from the panel for each detector and define any level of smoke concentration
between the lower and the upper limits, specifying the sensitivity of the system depending on the
requirements of each site.
They are composed by two parts. A plastic base which is placed on the ceiling and the main body of the
detector which fits on the plastic base with a simple rotation to the right. The detectors have a 360 visible
led and a remote led driver which are light up constantly in case of detection of fire, till cancelled from the
panel. Also, they are staying lit even if the sirens are silenced from the panel, so the detector which
detected the alarm is visible. They are turned off only when a reset command is given from the panel. The
indicator led blinks every 10 sec indicating the connection status with the main panel.
Page 1 from 4
20
1293
Olympia A Protocol
12-30V DC
195μΑ
2.5mA (with activated LED)
Adjustable from 0.107 to 0.300 in 0.010 dB/m steps
Alarm LED
Remote LED driver
1A
5A
300mΩ
25mA pulses (6ms duration every 2sec)
8.8 - 11
10.2 - 13
IP42
EN 54-7, EN 54-17
ο
-40 to 70 C
Up to 95%
ABS/PC
103 (d) x 48 (h) mm
160 gr.
2 years
