BSR-6057/A/MAR
OPERATION VOLTAGE
IDLE STATE POWER CONSUMPTION
ALARM POWER CONSUMPTION
SENSITIVITY
INDICATORS/OUTPUT
CLASS
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE

GENERAL

Before installing the detector, the user must read these instructions
carefully and store this manual for future reference. BSR-6057/A/MAR
is used on ships and is an addressable optical smoke and thermal
detector. It co-operates with BSR-2104/MAR, BSR-2114/MAR panels.
The device transmits an analogue value to the panel which depends
on the amount of the smoke that there is in the area. The analogue
value is 100 with obscuration rate 0.120dB/m (small amount of smoke).
The factory setting of the panel is to issue an alarm when the analogue
value is greater than 110. The user can change from the panel this
analogue value from 100 (high sensitivity) up to 120 (low sensitivity). At
the temperature of 60 C the thermal detector is activated and gives an o
120 value. They have two parts, one plastic base which is installed on
the ceiling and the main unit of the detector which is fastened to the
base by a simple turning to the right. The detectors have an indication
led which lights continuously in case of fire detection until there is a
reset signal from the panel. When we silence the sirens the LED
remains lit to show us the detector that issued the alarm. The LED goes
off when we RESET the panel. The indication led also flashes every 8
sec to indicate good operation.

ADDRESS SETTING

To set each detector's address you have to use the device BSR-2143
photo. 1. (refer to it's instruction manual). After the address setting
mark this number to the sticker on the detector's base (ADR:XXX).
Each detector must have an address with which it is recognized from
the panel. It`s forbidden for two devices with same addresses to be
connected to the same loop.

OPERATION CHECK

The operation check can be done by spraying a small amount of
smoke into the detector's chamber. You can use the special smoke
device A-752 of our company, or a similar device. It is advised to
conduct a good operation test every 6 months and every time the
detector position is changed. It is essential to have good air circulation
inside the detector. Therefore care must be taken so that the vents of
the detector are not covered.
NOTE
The detectors must be placed in the ceiling on visible areas with no side
obstacles and away from sides with no air circulation or strong air
currents and vapors. Each detector covers almost 50 m
distance between two detectors must not exceed 15m. Also the
detectors must be placed away from fluorescent tubes at least 50 cm.
The cables cross section must be from 0.5 to 1.5mm .
ATTENTION!!
After the device is installed, care must be taken, so that the detector
vents are not blocked by anything (i.e. dust, paint). Failing to do so will
Page 1 from 3
ADDRESSABLE OPTICAL SMOKE
AND THERMAL DETECTOR

TECHNICAL CHARACTERISTICS

Thank you for your trust in our products
Olympia Electronics - European manufacturer
2
and the
2
21-28V DC
1mA
1.5 mA (with indication LED activated)
0.120dB/m and 60 C
Alarm LED/to external LED driver
A2S
IP44
ΕΝ 54-5, EN 54-7, IEC 60092-504, IEC 60533
-10 to 60 C
Up to 95%
103 (diam.) x 48 (height) mm
160gr.
2 years
prevent the smoke particles to enter the detection chamber.
After the installation, it is the sole responsibility of the user to
maintain the detector for good operation.
o
o
