BS- 655/A
Optical smoke detector
TECHNICAL CHARACTERISTICS
OPERATION VOLTAGE
START UP POWER CONSUMPTION
STANDBY CONSUMPTION
ALARM CONSUMPTION
SMOKE CONCENTRATION SENSITIVITY
INDICATORS
OUTPUT
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATING TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for your trust in our products
Olympia Electronics - European manufacturer
GENERAL
The user have to read carefully the following instructions, in order to be properly informed and
keep them for future use.
The BS-655/A is a conventional smoke detector which integrates function of optical smoke
detection. The detector transitions to alarm state when the concentration of smoke reaches
0.107dB/m.
They are composed by two parts. A plastic base which is placed on the ceiling and the main
body of the detector which fits on the plastic base with a simple rotation to the right. The
o
detectors have a 360 visible led and a remote led driver which are light up constantly in case
of detection of fire, till cancelled from the panel. They are turned off only when a reset
command is given from the panel. The indicator led blinks every 6 sec indicating the normal
function.
INSTALLATION
The detectors should be placed in the ceiling in visible points without side obstacles, away
from places that are barely ventilated or with strong air currents and water vapor. Each
2
detector covers an area of 50 m while the distance between two detectors should not be
more than 15m. Also, they must be placed at least 50 cm away from fluorescent lamps. Cable
diameter should be from . to . 0 5 2 5mm.
MAINTENANCE & FUNCTIONAL TESTING
The detector has fault diagnosis and dust compensation functions, which automatically
informs you through the onboard LED when replacement or cleaning actions are required.
The indication LED blinks every 7 seconds. In normal operation it blinks 1 time, if cleaning
action is required it blinks 2 times and if there is a failure it blinks 3 times. After cleaning
procedure it will take about 10 minutes for detector's working indication to return to normal.
Page 1 from 4
21
1293
17-30V DC
1mΑ for 2 sec
90μΑ
12mA (with activated onboard LED)
0.107 dB/m
Alarm LED
To panel / to external LED driver (BS-572)
IP42
EN 54-7
ο
-40 to 70 C
Up to 95%
ABS/PC
103 (d) x 48 (h) mm
158 gr.
2 years
921655004_09_005
