olympia electronics BSR-6055/A/MAR Quick Start Manual

BSR-6055/A/MAR
ADDRESSABLE OPTICAL SMOKE DETECTOR

TECHNICAL CHARACTERISTICS

OPERATION VOLTAGE
IDLE STATE POWER CONSUMPTION
ALARM POWER CONSUMPTION
SENSITIVITY
INDICATORS
OUTPUT
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for your trust in our products
Olympia Electronics - European manufacturer

GENERAL

Before installing the detector, the user must
read these instructions carefully and store this
manual for future reference. BSR-6055/A/MAR
is used on ships and is an addressable optical
smoke detector. It co-operates with BSR-
2104/MAR, BSR-2114/MAR panels. The
device transmits an analogue value to the
panel which depends on the amount of the
smoke that there is in the area. The analogue
value is 100 with obscuration rate 0.120dB/m
(small amount of smoke). The factory setting of
the panel is to issue an alarm when the
analogue value is greater than 110.The user
can change from the panel this analogue value
from 100 (high sensitivity) up to 120 (low
sensitivity). They have two parts, one plastic
base which is installed on the ceiling and the
main unit of the detector which is fastened to
the base by a simple turning to the right. The
detectors have an indication led which lights
continuously in case of fire detection until there
is a reset signal from the panel. When we
silence the sirens the LED remains lit to show
us the detector that issued the alarm. The LED
goes off when we RESET the panel. The
indication led also flashes every 8 sec to
indicate good operation.

ADDRESS SETTING

To set each detector's address you have to use
the device BSR-2143 photo. 1. (refer to it's
instruction manual). After the address setting
mark this number to the sticker on the
detector's base (ADR:XXX). Each detector
must have an address with which it is
Page 1 of 3
21-28V DC
1mA
1.5 mA (with indication LED activated)
0.120dB/m
Alarm LED
to external LED driver
IP44
EN 54-7, IEC 60092-504, IEC 60533
o
-10 to 60 C
Up to 95%
103 (diam.) x 48 (height) mm
160gr.
2 years
recognized from the panel. It is forbidden for two
devices with same addresses to be connected
on the same loop.

OPERATION CHECK

The operation check can be done by spraying a
small amount of smoke into the detector's
chamber. You can use the special smoke device
A-752 of our company, or a similar device. It is
advised to conduct a good operation test every 6
months and every time the detector's position is
changed. It is essential to exist good air
circulation inside the detector. Therefore care
must be taken so that the vents of the detector
are not covered.
NOTE
The detectors must be placed on the ceiling on
visible areas with no side obstacles and away
from sides with no air circulation or strong air
currents and vapors. Each detector covers
2
almost 50 m and the distance between two
detectors must not exceed 15m. Also the
detectors must be placed away from fluorescent
tubes at least 50cm. The cables cross section
2
must be from 0.5 to 1.5mm .
ATTENTION!!
After the device is installed, care must be taken,
so that the detector vents are not blocked by
anything (i.e. dust, paint). Failing to do so will
prevent the smoke particles to enter the
detection chamber.
After the installation, it is the sole responsibility
of the user to maintain the detector for good
operation.
921605504_09_002
