olympia electronics BS- 657/A Quick Start Manual

BS-657/A
Optical smoke
and rate-of-rise heat detector
EN 54-5:2017,
EN 54-7:2018
DoP: 921657002_59_001
EGINIO
PIERIAS
60300
GREECE
Olympia Electronics guarantees the quality, condition and operation of the goods. The period
of warranty is specified in the official catalogue of Olympia Electronics and also in the
technical leaflet, which accompanies each product. This warranty ceases to exist if the buyer
does not follow the technical instructions included in official documents given by Olympia
Electronics or if the buyer modifies the goods provided or has any repairs or re-setting done
by a third party, unless Olympia Electronics has fully agreed to them in writing. Products that
have been damaged can be returned to the premises of our company for repair or
replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not
charge the buyer depending on the reason of defection. Olympia Electronics reserves the
right to charge or not the buyer the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.gr
info@olympia-electronics.gr
Page 4 from 4
1293
21
Warranty Warranty
921657002_09_008
BS- 657/A
Optical smoke and rate-of-rise heat detector
TECHNICAL CHARACTERISTICS
OPERATION VOLTAGE
START UP POWER CONSUMPTION
STANDBY CONSUMPTION
ALARM CONSUMPTION
SMOKE CONCENTRATION SENSITIVITY
TEMPERATURE SENSITIVITY
INDICATORS
CLASS
OUTPUT
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATING TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for your trust in our products
Olympia Electronics - European manufacturer
GENERAL
The user have to read carefully the following instructions, in order to be properly informed and
keep them for future use.
The BS-657/A is a conventional smoke detector which integrates functions of optical smoke
and heat detection. It can detect smoke and heat. The detector transitions to alarm state when
the concentration of smoke reaches 0.107dB/m or when the temperature reaches 57 C.
Also, the detector transitions to alarm state when the temperature rises suddenly by 32 C
regardless of the initial temperature at the beginning of the sudden rise event.
They are composed by two parts. A plastic base which is placed on the ceiling and the main
body of the detector which fits on the plastic base with a simple rotation to the right. The
o
detectors have a 360 visible led and a remote led driver which are light up constantly in case
of detection of fire, till cancelled from the panel. They are turned off only when a reset
command is given from the panel. The indicator led blinks every 6 sec indicating the normal
function.
INSTALLATION
The detectors should be placed in the ceiling in visible points without side obstacles, away
from places that are barely ventilated or with strong air currents and water vapor. Each
2
detector covers an area of 50 m while the distance between two detectors should not be
more than 15m. Also, they must be placed at least 50 cm away from fluorescent lamps. Cable
diameter should be from 0.5 to 2.5mm.
Page 1 from 4
21
1293
17-30V DC
1mΑ for 2 sec
90μΑ
12mA (with activated onboard LED)
0.107 dB/m
o
57 C
Alarm LED
A1R
To panel / to external LED driver (BS-572)
IP42
EN 54-5,EN 54-7
ο
-40 to 70 C
Up to 95%
ABS/PC
103 (d) x 55 (h) mm
158 gr.
2 years
o
o
921657002_09_008
