- Page 1 MANUAL ENGLISH DCS-4220 Ordercode: D6578 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 DCS-4220 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Installation ................................... 5 Troubleshooting ................................. 5 Product Specification ............................... 6 Dimensions ..................................6 Ordercode: D6578...
- Page 3 DCS-4220 Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling.
- Page 4 DCS-4220 IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the system. Never remove warning or informative labels from the unit. • Never leave any cables lying around. •...
- Page 5 DCS-4220 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.
- Page 6 DCS-4220 Installation 01) Drill a hole in the ceiling, big enough to fit the speaker (Ø 160 mm). 02) Connect the blue cable to the common cable. 03) Connect one of the colored cables to the main feed cable: red cable = 20W, yellow cable = 10W, green cable = 5W.
- Page 7 DCS-4220 Product Specification Power taps: 5/10/20W Line voltage: 100V Impedance: 8 Ω Speaker size LF: 4 inch Speaker size HF: ½ inch Frequency response: 110-20 kHz Sensitivity: 88 dB +/- 3 dB Material: Color: White IP rating: IP40 Mounting hole: Ø...
- Page 8 ©2015 DAP Audio...
