MANUAL
ENGLISH
DCS-6230
V2
Ordercode: D6580
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCS-6230 and is the answer not in the manual?

Questions and answers

Summary of Contents for DAPAudio DCS-6230

  • Page 1 MANUAL ENGLISH DCS-6230 Ordercode: D6580 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    DCS-6230 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Installation ................................... 5 Troubleshooting ................................. 5 Product Specification ............................... 6 Frequency Diagrams @ 500, 1000, 2000, 4000 and 8000 Hz ..................6 Dimensions ..................................
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes:  DAP Audio DCS-6230 6" 2-way ceiling speaker  User manual Safety Instructions Every person involved with the installation, operation and maintenance of this system has to: ...
  • Page 4: Operating Determinations

     Clean only with dry cloth.  When making the hole in your ceiling to mount the DCS-6230, make sure there is sufficient clearance behind the ceiling (no obstructions like A/C channels, power lines etc).  Take care of your speaker wires, they should be free of damage. Damaged speaker wires might result in poor sound quality and can damage amplifiers.
  • Page 5: Return Procedure

    DCS-6230 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
  • Page 6: Installation

    DCS-6230 Installation 01) Drill a hole in the ceiling, big enough to fit the speaker (Ø 210 mm). 02) Connect the blue cable to the common cable. 03) Connect one of the colored cables to the main feed cable: red cable = 30W, yellow cable = 15W, green cable = 7,5W.
  • Page 7: Product Specification

    DCS-6230 Product Specification Power taps: 7,5/15/30W Line voltage: 100V Impedance: 8 Ω Speaker size LF: 6 inch Speaker size HF: ½ inch Frequency response: 60-20 kHz Sensitivity: 88 dB +/- 3dB Material: ABS, RAL 9016 Color: White, RAL 9016 IP rating:...
  • Page 8 DCS-6230 Ordercode: D6580...
  • Page 9: Dimensions

    DCS-6230 Dimensions Design and product specifications are subject to change without prior notice. Website: www.Dap-audio.info Email: service@highlite.com Ordercode: D6580...
  • Page 10: Notes

    DCS-6230 Notes Ordercode: D6580...
  • Page 11 DCS-6230 Ordercode: D6580...
  • Page 12 ©2019 DAP Audio...
