1 Instruction
1.1 Summary
The W1DL is a wireless Skype phone which is composed of one
base and one handset. The base is a high quality speaker phone,
ideal for conference calls. The handset has blue backlighted
graphic LCD. Both base and handset ring for incoming calls.
You can make/receive a call via the handset without the
limitation of USB cable, just like using a mobile phone.
1.2 Features
1. USB Wireless Phone for Skype
2. 2.4GHz ISM Band, suit for Europe, USA, Japan etc
3. Handfree with digital echo cancellation
4. Large graphic LCD with blue backlight
5. Review Skype contacts and call list on handset LCD
6. Both base and handset ring for all incoming calls
7. Multi-language caller ID display feature
8. Auto-select RF channel to improve the quality of voice
1.3 Technical Data
Standby time: More than 100 hours
Talk time: More than 10 hours
Radio range: 50 meters (160 ft)
Battery: 460mAh (Li-battery)
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yealink USBW0002
Summary of Contents for Yealink USBW0002
- Page 1 1 Instruction 1.1 Summary The W1DL is a wireless Skype phone which is composed of one base and one handset. The base is a high quality speaker phone, ideal for conference calls. The handset has blue backlighted graphic LCD. Both base and handset ring for incoming calls. You can make/receive a call via the handset without the limitation of USB cable, just like using a mobile phone.
-
Page 2: System Requirements
1.4 System Requirements 2 Using the USB Wireless Phone 1. Windows 2000 or XP 2.1 Handset’s Keypad Instruction 2. 400MHz processor and free USB1.1 or USB2.0 port ： Contacts 3. 128MB RAM and 15MB free disk space (1) Press to display the contacts list, press 4. -
Page 3: Install Battery
: Dial/Answer Speaker light: (1) Call out or answer a call. (1) During a call via handset, pressing the Handfree key, the speaker light will flash. (2) Press to put a call on hold, release the call by pressing again. (2) The speaker light will be on when Handfree function is active, otherwise it is off. -
Page 4: Run Skypemate
Create a Skype account as shown below: 2.3.3 Register Handset to the base If the LCD shows： , that indicates the handset has not After software startup, the icon will appear to the system tray as registered to the base .Please do the following steps: shown below: (1) Press and hold the “C”... -
Page 5: Make A Call
2.5.2 Run SkypeMate If the icon shown as (the phone is red and the outside is green), it means USB Wireless Phone is connected incorrectly. Double-click the icon on the desktop, the Skype program Please reconnect USB Wireless Phone to PC. will pop up the window as shown below: 2.6 Make a Call 2.6.1 Call Skype user from contacts... -
Page 6: Answer A Call
2.6.6 Activate Handfree while making a call (1) Enter the number on the handset’s keypad and press call out. (2) Press the Handfree key, the speaker light will flash. (3) Place the handset on the base. (4) The speaker light will be turn on. (5) Press the Handfree key to end talking. - Page 7 2.8 State Instruction 2.9 Advanced (1) Ready state (1) Right click the icon on the taskbar and select Advance a. Skype online b. Skype offline c. Missed call (2) The window is shown as below: (2) The icons displayed in call list a.
- Page 8 2.10 Auto-select RF channel (2) The window is shown as below: This function is effective to improve the quality of handset’s voice. The handset will change the RF channel automatically when the voice is not so good. (1) Right click the icon on the taskbar and select Advance (2) The window is shown as below: (3) Enter the number from the PC’s keypad...
- Page 9 3 FAQ Problem 2 I am not able to hear any sound through the earphone? Problem 1 Solution There is no ring can be heard or the ring tone is too low. Please execute the “Control Panel->Sound and Video ( Solution ->Audio”, set Sound Playback and Sound Recording’s (1) Go to Skype, run “Tools->...
- Page 10 Set “Audio In” and “Audio Out” to “USB Audio Device”. Problem 5 Skype is running, but the icon of SkypeMate still show as (the phone is green and the outside is grey)? Solution You have selected the wrong option, go to Skype, execute choose “Tools->...
-
Page 11: Ce Mark Warning
CE Mark Warning: · Connect the equipment into an outlet on a circuit different This is a Class B product. In a domestic environment, this from that to which the receiver is connected. product may cause radio interference, in which case the user ·... - Page 12 PROTECTION OF THE ENVIRONMENT / DISPOSAL OF THE EQUIPMENT Do not on any account put your old equipment out with the domestic refuse. For the sake of the environment, please use your local authority’s collection point set to return and recycle old electric and electronic equipment.
