Pulsar PSBSH 1012B Manual

Buffer switch mode power supply unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PSBSH 1012B
v.1.0
PSBSH 13,8V/1A/7Ah/HERMETIC
Buffer switch mode power supply unit
EN*
Edition: 1'st from 16 th of November 2011
Supercedes the ------------- edition.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSBSH 1012B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar PSBSH 1012B

Summary of Contents for Pulsar PSBSH 1012B

  • Page 1 PSBSH 1012B v.1.0 PSBSH 13,8V/1A/7Ah/HERMETIC Buffer switch mode power supply unit Edition: 1’st from 16 th of November 2011 Supercedes the ------------- edition.

  • Page 2: Table Of Contents

    1. Buffer power supply PSBSH 13,8V/2x0,5A/7Ah - PSBSH 1012B + LB2 2x0,5A (AWZ586) + 7Ah 2. Buffer power supply PSBSH 13,8V/4x0,3A/7Ah - PSBSH 1012B + LB4 4x0,3A (AWZ574, AWZ576) + 7Ah 3. Buffer power supply PSBSH 13,8V/12V/2A/7Ah - PSBSH 1012B + RN250 (13,8V/12V) + 7Ah 4.

  • Page 3: Description Of Psu Components And Connectors

    PSBSH1012B Fig.1. Block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU pcb (refer to chart 2). Element no. Description ; pins - configuration of UVP battery protection function • protection (disconnection) of the battery off •...
  • Page 4 PSBSH1012B Fig.2. View of the pcb. Table 2. Elements of the PSU (refer to chart 3). Element no. Description Isolation transformer Power upply unit board (tab. 1, fig. 2) TAMPER; microswitches (contacts) for sabotage protection (NC) fuse in the power supply circuit (230V/AC)

  • Page 5: Specifications

    PSBSH1012B 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3) Mains supply 230V/AC (-15%/+10%) Current up to 0,14 A Power frequency 50Hz Supply power 17 W...

  • Page 6: Installation

    PSBSH1012B - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min. - between output circuit and PE protection circuit (O/P-FG) 500 V/AC min. Insulation resistance: - between input circuit and output or protection circuit 100 MΩ, 500V/DC Operating parameters (tab.6).

  • Page 7: Operating Status Indication

    PSBSH1012B 11. Connect the battery in accordance with the signs: +BAT red to ‘plus’, -BAT black to ‘minus’, (the LB diode light should fade throughout the time of charging). 12. Once the tests and control operation have been completed, close the PSU.
  • Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt. 2. If a purchase proof is missing, a three-year warranty period is counted from the device’s production date.
