Summary of Contents for Pulsar PSBSEP04124
Page 1
PSBSEP04124 v.1.1 PSBSEP 12-18V/4x1A/2x7Ah/SEP Switch mode buffer power supply unit for CCTV. Edition: 3 from 12.12.2013 Supercedes the edition: 2 from 16.09.2013...
PSBSEP04124 www.pulsar.pl Features: • 4 independently adjustable delivery channels for • START battery activation button • uninterruptible power supply in the range of LED optical indication • 12 ÷ 18VDC/4x1A FAC technical output indicating AC power • battery housing: 2x7Ah/12V loss •...
PSBSEP04124 The maximum output current is set to 4x1A at the output voltage of 12V. If the output voltage is higher than 12V, reduce the power consumption by the receivers according to the diagram 1. Diagram 1. In case of mains power loss, the unit will instantly switch to battery operation. The PSU is enclosed in a metal casing (color: RAL 9003) with battery housing for two 7Ah/12V batteries.
PSBSEP04124 www.pulsar.pl 1.3. The description of components and connectors of the PSU. Table 1. The description of components of the PSU. Component Description [Fig. 2] ; jumpers- battery charging current configuration • Ibat =0,2 A • Ibat =0,5 A Description:...
Page 5
PSBSEP04124 Fig. 2. The view of the Power supply PCB (Printed Circuit Board). Fig. 3. The view of the PSU. Table 2. Components of the PSU (see Fig. 3) Component No. Description [Fig. 3] Isolation transformer fuse in the power supply circuit (230V/AC)
PSBSEP04124 Safety of use (Table 5). Protection class PN-EN 60950-1:2004 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Insulation electrical strength: - between input (network) circuit and the output circuits of the PSU (I/P-O/P) 3000 V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min.
Page 8
PSBSEP04124 www.pulsar.pl 4. Connect the receivers with the AUX1 ... AUX4 connectors of the terminal block on the power supply module. 5. Connect the devices to the technical outputs, if needed: - FAC; AC status indication (alarm panel, controller, indicator, LED etc.).
PSBSEP04124 Diagram of connecting the camera and the recorder to the MSEP412 module. 3. Power supply operation indication. 3.1 Optical indication. The PSU is fitted with 8 LED lights at the front panel: RED LED: • on – The PSU supplied with 230V AC voltage •...
PSBSEP04124 www.pulsar.pl 3.2 Technical outputs. The PSU has the following indication outputs: • FAC – • FAC technical output indicating AC power failure - OC type output indicating AC power failure. During normal operation, (230V AC power on) the output is shorted to ground (L state –...
PSBSEP04124 4.4 Battery operation. In case of mains power loss, the unit will instantly switch to battery operation. To run the PSU from the battery, connect the BAT connectors in accordance with the markings: +BAT red to 'plus', -BAT black to 'minus’ on the battery, then press and hold the START button for 5 seconds.
Page 12
WEEE separately. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a five-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
