PSBSEP04124
v.1.0
PSBSEP 12-18V/4x1A/2x7Ah/SEP
Buffer, switched mode power supply for CCTV.
EN*
Edition: 1st (6th Feb 2012)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSBSEP04124 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar PSBSEP04124

Summary of Contents for Pulsar PSBSEP04124

  • Page 1 PSBSEP04124 v.1.0 PSBSEP 12-18V/4x1A/2x7Ah/SEP Buffer, switched mode power supply for CCTV. Edition: 1st (6th Feb 2012)

  • Page 2: Table Of Contents

    PSBSEP04124 www.pulsar.pl Features: • 4 independent adjustable channels, delivering • START for manual battery connection • uninterrupted voltage within the range of LED indication • 12÷18VDC/4x1A FAC technical output indicating AC power • fitting 2x7Ah/12V batteries loss • 4 separate OVP protection systems, one per channel, •...

  • Page 3: Block Diagram

    PSBSEP04124 Acceptable output current of the PSU is 4x1A with the preset 12V voltage at the output. If this voltage exceeds 12V, the receivers’ current consumption shall be reduced, according to the chart 1. Chart 1. In case of a power loss, a battery back-up is activated immediately. The PSU is mounted in a metal enclosure (RAL 9003 colour) that accommodates 2x7Ah/12V batteries and a microswitch indicates door opening (faceplate).

  • Page 4: Description Of Psu Components And Connectors

    PSBSEP04124 www.pulsar.pl 1.3 Description of PSU components and connectors Table 1. Elements of the PSU module. Element no. Description Fig. 2 ; pins – battery charging current adjustment • Ibat =0,2 A • Ibat =0,5 A Caption: jumper on, jumper off...
  • Page 5 PSBSEP04124 Fig.2. View of the PSU’s pcb. Fig.3. The view of the PSU. Table 2. Elements of the PSU (see fig. 3). Element no. Description [fig. 3] Isolation transformer fuse in the power supply circuit (230V/AC) MAIN L-N connector 230V/AC,...

  • Page 6: Specifications

    PSBSEP04124 www.pulsar.pl 1.4 Specifications: - electrical specifications (tab.2) - mechanical specifications (tab.3) - operation safety (tab.4) - operating specifications (tab.5) Electrical specifications (tab. 3). Mains supply 230 VAC (-15%/+10%) Current consumption 0,5A@230V AC max. Power frequency 50Hz PSU power 60W max.

  • Page 7: Installation

    PSBSEP04124 Operation safety (tab.5). Protection class PN-EN 60950-1:2004 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input (network) circuit and output circuits of the PSU (I/P-O/P) 3000 V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min.

  • Page 8: Operating Status Indication

    PSBSEP04124 www.pulsar.pl 7. With the OVP1 ÷ OVP4 jumpers, choose the over voltage protection, separately for each channel. The protection level must be set min. 1,5V higher than the output voltage. 8. Supply the ~230V/AC to the transformer (the AC red diode and AUX diode should be permanently illuminated).

  • Page 9: Operation And Use

    PSBSEP04124 Fig. 5. Electrical diagram of the OC technical outputs. • TAMPER - output that indicates unwanted opening of the PSU: contains volt-free (potential-free) contacts indicating the door status - unit closed: contacts normally closed (NC), unit opened: contacts normally open (NO) 4.
  • Page 10 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt. 2. If a purchase proof is missing, a three-year warranty period is counted from the device’s production date.
