Electrical connection

5.9.3 Closing the cover of the electronics compartment
1. Screw down the cover of the electronics compartment.
2. Turn the securing clamp 90 ° in the clockwise direction and, using an Allen key (3 mm),
tighten the screw of the securing clamp on the electronics compartment cover with
2.5 Nm.
6 Electrical connection
6.1 Connecting requirements
6.1.1 Terminal assignment
18
1.
Micropilot FMR53, FMR54 FOUNDATION Fieldbus
3 mm
2. 2.5 Nm
A0021451
