Commissioning
7. Setup → Full calibration
 Specify the full distance F (distance from the 0% mark to the 100% mark).
8. Setup → Level
 Displays the measured level L (for verification purposes).
9. Setup → Distance
 Displays the distance D between the reference point R and the level L (for
verification purposes).
10. Setup → Signal quality
 Displays the signal quality of the analyzed level echo (for verification purposes).
11. Setup → Mapping → Confirm distance
 Compare the distance displayed with the actual value to start recording an
interference echo map.
