  • Page 1 Optical Power Meter MT-7603 English English...
  • Page 3 USER'S GUIDE Optical Power Meter English English...

  • Page 4: Warning And Note

    WARNING WARNING You are cautioned that changes or modifications not expressly approved in this document could void your authority to operate this equipment. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet.

  • Page 5: Table Of Contents

    Contents 1. Warning and Note 2. Accessories 3. Product presentation 3.1 Description 3.2 Set batteries 3.2 Power on/off, auto power off 3.3 Backlight 3.4 Wavelength select 3.5 Wavelength calibrate 3.6 Wavelength ID 3.7 Unit select 3.8 Reference 3.9 Data Storage 3.10 Communication and data processing 3.11 Visual Fault Locator 3.12 Battery energy detect...

  • Page 6: Accessories

    Standard MT-7603 Fiber Optical Power Meter >2s PERM Save Unit Host Optical Power Meter MT-7603 English FC Fiber Adapter Manual Optional 3x AA LR6 1.5V or rechargeable battery charger/ output 5V/500mA...

  • Page 7: Product Presentation

    Description MT-7603 Fiber Optical Power Meter >2s PERM Save Unit 1-VFL connector 2-OPM connector 3-LCD 4-OPM wavelength shift /WAVE ID key 5-VFL on/off key 6-Reference set/check key 7-Unit shift key 8-USB Power key Backlight key 10-Data Save/Recall key...

  • Page 8: Set Batteries

    Set batteries 1.Press and push down 2.Open the lid 3.Place the batteries 4.Place the batteries...

  • Page 9: Power On/Off, Auto Power Off

    Power on/off, auto power off PERM MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Press the Power key to turn on the device with auto power off. After 10 minutes no key pressed, it will auto power off.

  • Page 10: Backlight

    Backlight MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM >2s PERM Save Unit When the device power on, press the power key to turn on or turn off the backlight.

  • Page 11: Wavelength Select

    Wavelength select MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit When testing, you must select the right wavelength. Press the key for shifting the wavelength from: 850nm,1300nm,1310nm,1490nm,1550nm,1625nm.

  • Page 12: Wavelength Calibrate

    Wavelength calibrate MT-7603 Fiber Optical Power Meter >2s PERM Save Unit The device has wavelength calibration function. During the device is booting on , long press Save key to enter this function. Press key to select wavelength, and press Save...

  • Page 13: Wavelength Id

    Wavelength ID MT-7603 PERM GLINT Fiber Optical Power Meter >2s PERM Unit Save Long press to turn on the WAVE ID and display at the same time. Long press again to exit the WAVE ID. Optical power meter with WAVE ID function can detect and change to the same wavelength when it works with the laser source at WAVE ID function.

  • Page 14: Unit Select

    Unit select MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Unit Press the key for shifting the unit from: Unit dBm, mW/uW/nW. mW/uW/nW: 1mW=1000uW, 1uW=1000nW dBm: (dBm)=10*log(mW)

  • Page 15: Reference

    Reference MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Press key to check the reference value you set last time,and wait 2 seconds or press key to exit. And if keep pressing for 2 seconds, you can store the current dBm as a new reference value.

  • Page 16: Data Storage

    Data Storage MT-7603 PERM 1KHz Save Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Save When in testing interface, user can press Save to the History interface,press key and key to check storage date.and press Save Unit key again to exit .

  • Page 17: Communication And Data Processing

    Communication and data processing Feature 1.The data collection can save as ".xls" file. 2.Collecting real-time data automatically(0.2 seconds to 10 minutes), and save as ".xls" file. 3.Saving real-time data automatically(every 10 minutes). Basic Operation A. Read the recorded data 1. Turn on the device, and connect with PC. 2.
  • Page 18 Communication and data processing Collect real-time data 1 Connect the device with PC, and turn it on. 2. Click "Connect Device" button to identify the device. 3.Click "Collect RT Data" button to collect real-time data. You should set parameters before collecting, including real-time cycle and acquisition time.

  • Page 19: Visual Fault Locator

    Visual Fault Locator (optional) MT-7603 PERM 1KHz GLINT Save GLINT Fiber Optical Power Meter >2s PERM Save Unit The device can build in a optional VFL module, press the VFL key to shift the conditions: on-> glint->off...

  • Page 20: Battery Energy Detect

    Battery energy detect MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Remain80%---100% Remain40%---80% Remain20%---40% Remain less than20% If the energy is too low, the beep will be on and device will auto power off.

  • Page 21: Battery Charge

    The rechargeable batteries must be in device when you use the AC/DC adaptor for charging. And do not charge the non-rechargeable batteries, or the device will be destroyed and also lose the guarantee. MT-7603 5V/500mA Fiber Optical Power Meter >2s PERM...

  • Page 22: Detailed

    Detailed MT-7603 Measurement range -70~+8dBm Measurement 850nm,1300nm,1310nm,1490nm,1550nm,1625nm wavelengths Resolution 0.01dB Accuracy 0.2dB Linearity 2.0% Detector type InGaAs Optical Connector FC/PC Application fiber type 9/125 m~62.5/125 m Display Resolution +8~ -60dBm: 0.01dB ; -60~ -70dBm: 0.1dB Power Display Units dBm, mW, uW, nW,...
  • Page 24 Optical Power Meter...
  • Page 26 3.10 3.11 3.12 3.13 3.14...
  • Page 27 MT-7603 Fiber Optical Power Meter >2s PERM Save Unit Optical Power Meter MT-7603 English 3x AA LR6 1.5V 5V/500mA...
  • Page 28 MT-7603 Fiber Optical Power Meter >2s PERM Save Unit 8-USB...
  • Page 30 PERM MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit PERM...
  • Page 31 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM >2s PERM Save Unit...
  • Page 32 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit 850nm,1300nm,1310nm,1490nm,1550nm,1625nm...
  • Page 33 MT-7603 Fiber Optical Power Meter >2s PERM Save Unit Save Save Unit -3dB~+3dB...
  • Page 34 MT-7603 PERM GLINT Fiber Optical Power Meter >2s PERM Unit Save...
  • Page 35 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Unit Unit mW/uW/nW mW/uW/nW 10 log (mW)=(dBm) 1mW=1000uW,1uW=1000nW...
  • Page 36 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Unit...
  • Page 37 MT-7603 PERM 1KHz Save Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Save 1000 1000 1000 Save Unit Save Save...
  • Page 38 .xls .xls...
  • Page 39 10 m 30 m 1H 8H 24H 3D 7D 30D 120D360D 0.2s...
  • Page 40 MT-7603 PERM 1KHz GLINT Save GLINT Fiber Optical Power Meter >2s PERM Save Unit -> ->...
  • Page 41 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit...
  • Page 42 MT-7603 5V/500mA Fiber Optical Power Meter >2s PERM Save Unit...
  • Page 43 MT-7603 -70~+8dBm 850nm,1300nm,1310nm,1490nm,1550nm,1625nm 0.01dB 0.2dB 2.0% InGaAs FC/PC 9/125 m~62.5/125 m +8~ -60dBm: 0.01dB ; -60~ -70dBm: 0.1dB dBm, mW, uW, nW, 1000 270Hz,1kHz, 2kHz >160H -20 ~+70 <90%RH -10 ~+60 <90%RH AA/LR6 1.5V X3 PCS ( 170mm 97mm 38mm...
  • Page 45 Optical Power Meter...
  • Page 47 3.10 3.11 3.12 3.13 3.14...
  • Page 48 MT-7603 Fiber Optical Power Meter >2s PERM Save Unit Optical Power Meter MT-7603 English 3x AA LR6 1.5V 5V/500mA...
  • Page 49 MT-7603 Fiber Optical Power Meter >2s PERM Save Unit 8-USB...
  • Page 51 PERM MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit PERM...
  • Page 52 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM >2s PERM Save Unit...
  • Page 53 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit 850nm,1300nm,1310nm,1490nm,1550nm,1625nm...
  • Page 54 MT-7603 Fiber Optical Power Meter >2s PERM Save Unit Save Save Unit -3dB~+3dB...
  • Page 55 MT-7603 PERM GLINT Fiber Optical Power Meter >2s PERM Unit Save...
  • Page 56 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Unit Unit mW/uW/nW mW/uW/nW 10 log (mW)=(dBm) 1mW=1000uW,1uW=1000nW...
  • Page 57 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Unit...
  • Page 58 MT-7603 PERM 1KHz Save Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Save Save Save Unit Save...
  • Page 59 .xls .xls...
  • Page 60 10 m 30 m 1H 8H 24H 3D 7D 30D 120D360D 0.2s...
  • Page 61 MT-7603 PERM 1KHz GLINT Save GLINT Fiber Optical Power Meter >2s PERM Save Unit -> ->...
  • Page 62 MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit 80%---100% 40%---80% 20%---40%...
  • Page 63 MT-7603 5V/500mA Fiber Optical Power Meter >2s PERM Save Unit...
  • Page 64 MT-7603 -70~+8dBm 850nm,1300nm,1310nm,1490nm,1550nm,1625nm 0.01dB 0.2dB 2.0% InGaAs FC /PC 9/125 m~62.5/125 m +8~ -60dBm: 0.01dB ; -60~ -70dBm: 0.1dB dBm, mW, uW, nW, 1000 270Hz,1kHz, 2kHz >160H -20 ~+70 <90%RH -10 ~+60 <90%RH AA/LR6 1.5V X3 PCS ( 170mm 97mm 38mm...
  • Page 65 MT-7603-C...
  • Page 66 1365 25 021-68183050 www.prokits.com.tw...
  • Page 67 PROKIT'S INDUSTRIES CO.,LTD http://www.prokits.com.tw Email: pk@mail.prokits.com.tw ã 2020 Prokit's Industries Co., LTD. All rights reserved 2020001(C)
