appenDICes

Telnet Commands

‡ Port: support 3 ports of 23/1023/2023
‡ Multi-connections: Projector could receive commands from different ports at the same time
‡ Command Format: Follow RS232 command format (support both of ASCII and HEX)
‡ Command Response: Follow RS232 return message.
lead Code projector ID
Standby State

~
Fix code One Digit~ 00
notee: For wide screen resolution (WXGA), the compatibility support is dependent on Notebook/PC models.

aMX Device Discovery Commands

‡ DP: 239.255.250.250
‡ Port No.: 9131
‡ Each UDP broadcast information as below are updated around 40 seconds
Command
Device-UUID MAC address (Hex value without' ':' separator)
Device-SKDClass The Duet DeviceSdk class name
Device-Make Maker name
Device-Model Model name
Config-URL Device's IP address
LAN IP address is shown up if LAN IP address is valid.
Wireless LAN IP address is shown up if Wireless LAN IP address is valid.
Revision The revision must follow a major.minor.micro scheme. The revision is only
increased if the command protocol is modified.
notee:
‡
For wide screen resolution (WXGA), the compatibility support is dependent on Notebook/PC models.
‡ This AMX function is only to support AMX Device Discovery.
‡ The broadcast information only send out through valid interface.
‡ Both LAN and Wireless LAN interfaces could be supported at the same time.
‡ If "Beacon Validator" was used. Please take care below information.
Command ID
  
Defined by Optoma 2 or 3 Digit.
See the Follow content
Description
space

n
One Digit Per item Definition Fix code One Digit
Variable Carriage Return
CR
Remark (parameter)
12 digits
VideoProjector
MakerPXLW
Projector
http://xxx.xxx.xxx.xxx/index.html
1.0.0
