User Manual
RS232 Commands and Protocol
Function List
RS232 Pin Assignments
D-Sub 9 pin
(from the projector side)
1
1 CD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
(from the cable side)
C1
COLOR
1
Black
2
Brown
3
Red
4
Orange
5
Yellow
6
Green
7
Blue
8
Purple
9
White
SHELL
DW
C2
1
3
2
6
5
4
8
7
9
SHELL
EN-81
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Optoma EH501
Summary of Contents for Optoma EH501
-
Page 1: Function List
RS232 Commands and Protocol Function List RS232 Pin Assignments D-Sub 9 pin (from the cable side) (from the projector side) COLOR 1 CD Black Brown Orange Yellow Green Blue Purple White SHELL SHELL EN-81... -
Page 2: Rs232 Protocol Function List
To also include AMX beacon signal in RS232 protocol In basic terms, AMX controllers will issue a poll periodically to detect 3rd party devices connected to the RS232 port (in this case Optoma). The poll is "AMX" in ASCII followed by a carriage return 'r'. - Page 3 -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SEND to projector ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Function Description 232 ASCII Code HEX Code -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ~XX00 1 7E 30 30 30 30 20 31 0D Power ON ~XX00 0 7E 30 30 30 30 20 30 0D Power OFF (0/2 for backward compatible) ~XX00 1 ~nnnn 7E 30 30 30 30 20 31 20 a 0DPower ON with Password ~nnnn = ~0000 (a=7E 30 30 30 30)
- Page 4 ~XX230 3 7E 30 30 32 33 30 20 31 0D 3D Mode ~XX400 0 7E 30 30 34 30 30 20 30 0D 3D 2D ~XX400 1 7E 30 30 34 30 30 20 31 0D ~XX400 2 7E 30 30 34 30 30 20 32 0D ~XX405 0 7E 30 30 34 30 35 20 30 0D 3D Format Auto...
- Page 5 ~XX455 0 7E 30 30 34 35 35 20 30 0D Extron ~XX455 1 7E 30 30 34 35 35 20 31 0D ~XX456 0 7E 30 30 34 35 36 20 30 0D PJLink ~XX456 1 7E 30 30 34 35 36 20 31 0D ~XX457 0 7E 30 30 34 35 37 20 30 0D AMX Device Discovery ~XX457 1...
- Page 6 ~XX127 1 7E 30 30 31 32 37 20 31 0D Format (W501) n: 0/1/2/3/4/5 = 4:3/16:9/16:10/LBX/Native/AUTO (EH501) n: 0/1/2/3/4 =4:3/16:9/LBX/Native/AUTO (X501) n: 0/1/2/3 =4:3/16:9/Native/AUTO *16:9 or 16:10 depend on Screen Type setting ~XX128 1 7E 30 30 31 32 38 20 31 0D Color Temperature...
