  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    TablE of ConTEnTs safETY ....................4 Important Safety Instruction....................... 4 3D Safety Information ........................ 5 Copyright ........................... 6 Disclaimer ..........................6 Trademark Recognition ......................6 FCC ............................7 Declaration of Conformity for EU countries ................7 WEEE ............................7 InTRoDUCTIon .................. 8 Package Overview........................
  • Page 3 Image size and projection distance ..................68 Projector dimensions and ceiling mount installation ..............72 IR remote control 1 codes ......................73 IR remote control 2 codes ......................75 Troubleshooting ........................77 Warning indicators ........................78 Specifications ........................... 81 Optoma global offices ....................... 82 English...

  • Page 4: Safety

    safETY The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: 3D Safety Information

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 6: Copyright

    ‡ If you experience any of the following symptoms, stop viewing 3D pictures immediately and consult a medical specialist: (1) altered vision; (2) light-headedness; (3) dizziness; (4) involuntary movements such as eye or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions; (9) cramps;...

  • Page 7: Fcc

    This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 8: Introduction

    InTRoDUCTIon Package overview Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items under optional accessories may not be available depending on the model, specification and your region of purchase. Please check with your place of purchase. Some accessories may vary from region to region. The warranty card is only supplied in some specific regions.

  • Page 9: Product Overview

    InTRoDUCTIon Product overview notee: Keep a minimum distance of 20 cm between the “inlet” and “outlet” labels. Item Item Lamp Cover Lens Focus Ring Ventilation (inlet) Zoom Lever 10. Ventilation (outlet) IR Receiver 11. Kensington Lock Port Keypad 12. Power Socket Tilt-Adjustment Foot 13.

  • Page 10: Connections

    InTRoDUCTIon Connections Type 1 (9 Io) Audio In Audio Out VGA-IN / YPbPr VGA-OUT VIDEO USB Power HDMI 1 / MHL HDMI 2 Out (5V 1.0A) MOUSE / SERVICE RS-232C Type 2 (13 Io) Audio Out Audio In 1 VGA-IN 1 / YPbPr VGA-IN 2 / YPbPr S-VIDEO VIDEO...
  • Page 11 InTRoDUCTIon Item Type 1 (9 Io) Type 2 (13 Io) HDMI 1 / MHL Connector √ √ HDMI 2 Connector √ √ USB Power Out (5V 1A) Connector / MOUSE / SERVICE √ √* Connector a) VGA-IN 1 / YPbPr Connector and VGA-IN 2 / YPbPr Connector √...

  • Page 12: Keypad

    InTRoDUCTIon Keypad Item Item On/Standby LED Enter Lamp LED Menu Keystone Correction Four Directional Select Keys Temp LED 10. Source Information 11. Power Re-Sync English...

  • Page 13: Remote Control 1

    InTRoDUCTIon Remote control 1 Item Item Power On / Off 10. IR LED Indicator Keystone + / - 11. Freeze AV Mute 12. Aspect Ratio Volume - / + Mute Enter 14. Four Directional Select Keys Menu 15. 3D HDMI 16.

  • Page 14: Remote Control 2

    InTRoDUCTIon Remote control 2 Power Switch Freeze Enter Page+ Laser Page- V Keystone Volume Menu HDMI Video User1 User2 User3 Source Resync Item Item Power On / Off 15. Brightness Mode Freeze 16. Mouse On / Off Display Blank / Audio Mute 17.

  • Page 15: Setup And Installation

    Do not operate the projector in any orientation other that table top or ceiling mount. The projector should be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate the warranty and may shorten the lifetime of the projector lamp or the projector itself. For none standard installation advise please contact Optoma. English...
  • Page 16 sETUP anD InsTallaTIon Type 1 (9 Io) Audio In Audio Out VGA-IN / YPbPr VGA-OUT VIDEO USB Power HDMI 1 / MHL HDMI 2 Out (5V 1.0A) MOUSE / SERVICE RS-232C MOLEX English...
  • Page 17 sETUP anD InsTallaTIon Type 2 (13 Io) Audio Out Audio In 1 VGA-IN 1 / YPbPr VGA-IN 2 / YPbPr S-VIDEO VIDEO USB Power HDMI 1 / MHL HDMI 2 Out (5V 1.0A) MOUSE / SERVICE Audio In 2 /Mic In VGA-OUT / YPbPr RS-232C RJ-45...
  • Page 18 sETUP anD InsTallaTIon Item Type 1 (9 Io) Type 2 (13 Io) MHL Cable √ √ HDMI Cable √ √ RCA Component Cable √ √ VGA In Cable √ √ S-Video Cable √ Video Cable √ √ Audio In Cable √...

  • Page 19: Adjusting The Projector Image

    sETUP anD InsTallaTIon adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom and focus...
  • Page 20 sETUP anD InsTallaTIon Installing / replacing the batteries Press firmly and slide the battery cover off. Install new battery into the compartment. Remove the old battery and install new one (CR2025). Ensure that the side with a “+” is facing Put the cover back.
  • Page 21 sETUP anD InsTallaTIon Effective range Infra-Red (IR) remote control sensor is located on top of the projector. Ensure to hold the remote control at an angle within 30 degrees perpendicular to the projector’s top IR remote control sensor to function correctly. The distance between the remote control and the sensor should not be longer than 6 meters (~ 20 feet).

  • Page 22: Using The Projector

    UsInG THE PRoJECToR Powering on / off the projector Powering on Securely connect the power lead and signal/source cable. When connected, the On/Standby LED will turn red. Turn on the projector by pressing the " " either on the projector keypad or the remote control. A start up screen will display in approximately 10 seconds and the On/Standby LED will be flashing green or flashing blue.

  • Page 23: Selecting An Input Source

    UsInG THE PRoJECToR selecting an input source Turn on the connected source that you want to display on the screen, such as computer, notebook, video player, etc. The projector will automatically detect the source. If multiple sources are connected, push the source button on the projector keypad or the remote control to select the desired input.

  • Page 24: Menu Navigation And Features

    UsInG THE PRoJECToR menu navigation and features The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. To open the OSD menu, press on the remote control or the projector keyboard.

  • Page 25: Osd Menu Tree (Type 1)

    UsInG THE PRoJECToR osD menu tree (Type 1) main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Presentation Bright Cinema Game Display Mode [Data] sRGB DICOM SIM. User Off [Default] Blackboard Light Yellow Wall Color Light Green Light Blue Pink...
  • Page 26 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Cancel [Default] Reset Color Matching Exit Red Gain -50~50 Green Gain -50~50 Blue Gain -50~50 Red Bias -50~50 RGB Gain/Bias Green Bias -50~50 Blue Bias -50~50 Cancel [Default]...
  • Page 27 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu 3D Mode DLP-Link [Default] 3D [Default] 3D->2D Auto [Default] 3D Format Top and Bottom Frame Sequential 3D sync invert Off [Default] Display 16:9 16:10 [WXGA WUXGA models] Aspect Ratio LBX [except SVGA XGA models]...
  • Page 28 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Optional Filter Installed Filter Usage (Read only) Hours 300hr Filter Settings Filter Reminder 500hr [Default] 800hr 1000hr Cancel [Default] Filter Reset Off [Default] Direct Power On Off [Default] Signal Power On...
  • Page 29 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu White Grid Test Pattern White IR Function HDMI 2 Test Pattern Brightness Contrast Sleep Timer [Default] Color Matching User1 Color Temp Gamma Projection Lamp Settings Zoom Freeze...
  • Page 30 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Projector ID 0~99 English [Default] Deutsch Français Italiano Español Português Polski Nederlands Svenska Norsk Dansk Suomi ελληνικά 繁體中文 Language 簡体中文 日本語 한국어 Русский Magyar Čeština Setup...
  • Page 31 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu HDMI1/MHL HDMI2 Input Source Video Default [Default] HDMI1/MHL Custom Default [Default] HDMI2 Custom Input Name Default [Default] Custom Default [Default] Video Custom Off [Default] High Altitude Options Off [Default]...
  • Page 32 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Regulatory Serial Number Source Resolution 00x00 Refresh Rate 0.00Hz Display Mode Power mode (Standby) Bright Information Lamp Hours Dynamic Eco+ Total Projector ID 00~99 Filter Usage Hours...

  • Page 33: Osd Menu Tree (Type 2)

    UsInG THE PRoJECToR osD menu tree (Type 2) main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Presentation Bright Cinema Game Display Mode [Data] sRGB DICOM SIM. User Off [Default] Blackboard Light Yellow Wall Color Light Green Light Blue Pink...
  • Page 34 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Cancel [Default] Reset Color Matching Exit Red Gain -50~50 Green Gain -50~50 Blue Gain -50~50 Red Bias -50~50 RGB Gain/Bias Green Bias -50~50 Blue Bias -50~50 Cancel [Default]...
  • Page 35 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu 3D Mode DLP-Link [Default] 3D [Default] 3D->2D Auto [Default] 3D Format Top and Bottom Frame Sequential 3D sync invert Off [Default] Display 16:9 16:10 [WXGA WUXGA models] Aspect Ratio LBX [except SVGA XGA models]...
  • Page 36 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Front [Default] Rear Projection Ceiling-top Rear-top 16:9 [WXGA/WUXGA Screen Type models] 16:10 [Default] Lamp Reminder On [Default] Lamp Settings Cancel [Default] Lamp Reset Optional Filter Installed Filter Usage...
  • Page 37 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Security Month Security Security Timer Hour Change Password HDMI Link Inclusive of TV HDMI Link Mutual Settings Power On Link PJ --> Device Device -->...
  • Page 38 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Color Matching [Default] Color Temp Gamma Projection User2 Lamp Settings Zoom Freeze HDMI 2 VGA 2 Remote Test Pattern Settings [depends on Brightness remote] Contrast Sleep Timer...
  • Page 39 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu ไทย Türkçe Language Tiếng Việt Bahasa Indonesia Română Slovenčina Closed Captioning Off [Default] Top left Top right Menu Location Center [Default] Menu Settings Bottom left Bottom right Menu Timer...
  • Page 40 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Off [Default] Keypad Lock Off [Default] Information Hide Default [Default] Logo Neutral Options None [Default, for Video/Pro-AV model] Blue [Default, for Data model] Setup Background Color...
  • Page 41 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Regulatory Serial Number Source Resolution 00x00 Refresh Rate 0.00Hz Display Mode Power mode (Standby) Bright Lamp Hours Dynamic Information Eco+ Total Network Status IP Address Projector ID 00~99...

  • Page 42: Display Image Settings Menu

    UsInG THE PRoJECToR Display menu Display image settings menu Display mode (Data mode) There are many factory presets optimized for various types of images. ‡ Presentation: This mode is suitable for showing PowerPoint presentations when the projector is connected to the PC. ‡...
  • Page 43 UsInG THE PRoJECToR Color Temperature (Data mode): Select a color temperature from Warm, Medium, or Cool. ‡ ‡ Color matching: Select the following options: ± Color: Adjust the red (R), green (G), black (B), cyan (C), yellow (Y), magenta (M), and white (W) level of the image.

  • Page 44: Display 3D Menu

    UsInG THE PRoJECToR Eco+: When Eco+ mode is activated, the brightness level of the content is automatically detected to ‡ significantly reduced lamp power consumption (up to 70%) during periods of inactivity. Reset Return the factory default settings for color settings. Display 3D menu 3D mode Use this option to disable the 3D function or select the appropriate the 3D function.
  • Page 45 UsInG THE PRoJECToR notee: ‡ Detailed informations about LBX mode: ± Some Letter-Box Format DVDs are not enhanced for 16x9 TVs. In this situation, the image will not look right when displaying image in 16:9 mode. In this situation, please try to use the 4:3 mode to view the DVD.
  • Page 46 UsInG THE PRoJECToR WXGa scaling table (screen type 16e:10): notee: ‡ Supported screen type 16:9 (1280x720), 16:10 (1280x800). ‡ When screen type is 16:9, the16x10 format becomes unavailable. ‡ When screen type is 16:10, the 16x9 format becomes unavailable. ‡ If you select auto option then the display mode will be also automatically changed.
  • Page 47 UsInG THE PRoJECToR WXGa scaling table (screen type 16e:9): 16 e: 9 screen 480i/p 576i/p 1080i/p 720p Scale to 960x720. 16x9 Scale to 1280x720. Scale to 1280x960, then get the central 1280x720 image to display. native mode 1:1 mapping centered. 1:1 mapping 1280x720 1:1 mapping...

  • Page 48: Display Edge Mask Menu

    UsInG THE PRoJECToR 1080P auto mapping rulee: Input resolution auto/scale auto H-resolution V-resolution 1920 1080 1440 1080 1440 1080 1024 1440 1080 4e:3 1280 1024 1440 1080 1400 1050 1440 1080 1600 1200 1440 1080 1280 1920 1080 Wide laptop 1280 1800 1080...

  • Page 49: Audio Mute Menu

    UsInG THE PRoJECToR Audio menu audio mute menu mute Use this option to temporarily turn off the sound. ‡ one: Choose the “On” to turn mute on. ‡ offe: Choose the “Off” to turn mute off. notee: “Mute” function affects both internal and external speaker volume. audio volume menu Volume Adjust the audio volume level.

  • Page 50: Setup Filter Settings Menu

    UsInG THE PRoJECToR Setup filter settings menu optional filter Installed Set the warning message setting. ‡ Yese: Display warning message after 500 hours of use. notee: “Filter Usage Hours / Filter Reminder / Filter Reset” will only appear when “Optional Filter Installed” is “Yes”. ‡...

  • Page 51: Setup Security Menu

    UsInG THE PRoJECToR Usb Power Set the USB power settings. ‡ one: The projector is always powered on by a USB power source. ‡ offe: The USB Power function is off. ‡ autoe: The projector is automatically powered on by a USB power source. Wireless (Type 2) Set this function “On”...

  • Page 52: Setup Test Pattern Menu

    UsInG THE PRoJECToR Power on link CEC power on command. ‡ mutuale: Both projector and CEC device will be turned on simultaneously. ‡ PJ -> Devicee: The CEC device will be turned on only after the projector is switched on. ‡...

  • Page 53: Setup Reset Menu

    UsInG THE PRoJECToR auto source If you set this option “On” and press the button on the projector keypad or button on the remote control then the next available input source is selected automatically. Set “Off” to disable auto source function. Input source (Type 1) Select the input source between HDMI1/MHL, HDMI2, VGA, and Video.

  • Page 54: Network Lan Menu

    UsInG THE PRoJECToR Network menu (Type 2) network lan menu network status Display the network connection status (read-only). maC address Display the MAC address (read-only). DHCP Use this option to enable or disable the DHCP function. ‡ on: Projector will obtain an IP address automatically from your network. ‡...

  • Page 55: Network Control Menu

    UsInG THE PRoJECToR making a direct connection from your computer to the projector* Turn “Off” the DHCP option on the projector. Configure the IP address, Subnet Mask, Gateway, and DNS on projector (“Network > LAN”). Open Network and Sharing Center page on your PC, and assign the identical network parameters to your PC as set on projector.

  • Page 56: Setup Network Control Settings Menu

    UsInG THE PRoJECToR setup network control settings menu lan_RJ45 function For simplicity and ease of operation, the projector provides diverse networking and remote management features. The LAN / RJ45 function of the projector through a network, such as remotely manage: Power On / Off, brightness, and contrast settings.
  • Page 57 UsInG THE PRoJECToR lan RJ45 Connect an RJ45 cable to RJ45 ports on the projector and the PC (laptop). Audio Out Audio In 1 VGA-IN 1 / YPbPr VGA-IN 2 / YPbPr S-VIDEO VIDEO USB Power HDMI 1 / MHL HDMI 2 Out (5V 1.0A)
  • Page 58 UsInG THE PRoJECToR Click “Properties”. Type in the IP address and Subnet mask, then press “OK”. Press the “Menu” button on the projector. Open on projector network > lan. Enter the following connection parameters: ± DHCP: Off ± IP Address: 192.168.0.100 ±...
  • Page 59 UsInG THE PRoJECToR The projector is setup for remote management. The LAN / RJ45 function displays as follows: Information page Main page Tool page Contact IT helpdesk English...
  • Page 60 UsInG THE PRoJECToR Rs232 by Telnet function There is alternative RS232 command control way, in projector so called “RS232 by TELNET” for LAN / RJ45 interface. Quick start-Guide for “Rs232 by Telnet” ‡ Check and get the IP address on OSD of the projector. ‡...

  • Page 61: Info Menu (Type 1)

    UsInG THE PRoJECToR Info menu Info menu (Type 1) View the projector information as listed below: ‡ Regulatory ‡ Serial Number ‡ Source ‡ Resolution ‡ Refresh Rate ‡ Display Mode ‡ Power mode(standby) ‡ Lamp Hours ‡ Projector ID ‡...

  • Page 62: Maintenance

    maInTEnanCE Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, a warning message will appear on the screen. Warning lamp Warning lamp life exceeded. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible.
  • Page 63 maInTEnanCE Replacing the lamp (continued) Procedure: Switch off the power to the projector by pressing the " " button on the remote control or the projector keypad. Allow the projector to cool down for at least 30 minutes. Disconnect the power cord. Unscrew the screw on the cover.

  • Page 64: Installing And Cleaning The Dust Filter

    maInTEnanCE Installing and cleaning the dust filter Installing the dust filter notee: Dust filters are only required/supplied in the selected regions with excessive dust. Cleaning the dust filter We recommend you to clean the dust filter every three months. Clean it more often if the projector is used in a dusty environment.

  • Page 65: Additional Information

    aDDITIonal InfoRmaTIon Compatible resolutions Digital compatibility b0/Established b0/standard Timing b0/Detail Timing b1/Video mode b1/Detail Timing Timing 720x400 @ 70Hz SVGA: Native timing: 640x480p @ 60Hz 720x480p @ 60Hz 640x480 @ 60Hz 800x600 @ 120Hz XGA: 1024x768 @ 60Hz 720x480p @ 60Hz 1280x720p @ 60Hz 640x480 @ 67Hz 1024x768 @ 120Hz...
  • Page 66 aDDITIonal InfoRmaTIon Analog compatibility b0/Established b0/standard Timing b0/Detail Timing b1/Video mode b1/Detail Timing Timing 720x400 @ 70Hz SVGA: Native timing: 1366x768 @ 60Hz 640x480 @ 60Hz 800x600 @ 120Hz XGA: 1024x768 @ 60Hz 640x480 @ 67Hz 1024x768 @ 120Hz WXGA: 1280x800 @ 60Hz; 1280x720 @ 60Hz 640x480 @ 72Hz 1280x800 @ 60Hz...
  • Page 67 If 3D input is 1080p@24hz, the DMD should replay with integral multiple with 3D mode. ‡ Support NVIDIA 3DTV Play if there is no patent fee from Optoma. 1080i@25hz and 720p@50hz will run in 100 hz; other 3D timing will run in 120hz.

  • Page 68: Image Size And Projection Distance

    aDDITIonal InfoRmaTIon Image size and projection distance Type 1e: Diagonal screen size W x H Projection Distance (D) offset (Hd) length (inch) (feet) size of (16e:9) Width Height Width Height Wide Tele Wide Tele (inch) screen 0.73 0.55 28.80 21.6 4.59 5.25 0.08...
  • Page 69 aDDITIonal InfoRmaTIon 1080P Diagonal screen size W x H Projection Distance (D) offset (Hd) length (inch) (feet) size of (16e:9) Width Height Width Height Wide Tele Wide Tele (inch) screen 0.80 0.45 31.38 17.65 3.94 4.27 0.07 2.76 0.89 34.86 19.6 4.27 4.59...
  • Page 70 aDDITIonal InfoRmaTIon WXGA Diagonal screen size W x H Projection Distance (D) offset (Hd) length (inch) (feet) size of (16e:9) Width Height Width Height Wide Tele Wide Tele (inch) screen 0.78 0.48 30.53 19.08 2.95 3.94 0.06 2.36 0.86 0.54 33.92 21.2 3.28...
  • Page 71 aDDITIonal InfoRmaTIon 5.2 cm English...

  • Page 72: Projector Dimensions And Ceiling Mount Installation

    InfoRmaTIon Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...

  • Page 73: Ir Remote Control 1 Codes

    aDDITIonal InfoRmaTIon IR remote control 1 codes Key legend Description Key code Power Press to turn on / off the projector. Freeze Press to freeze the projector image. Aspect Press to change aspect ratio of a displayed image. AV mute Press to turn off/ on projector built-in speaker ‡...
  • Page 74 aDDITIonal InfoRmaTIon Key legend Description Key code Press to choose VGA source. Video Press to choose video source. Source Press to select an input signal. Press to automatically adjust the picture brightness to give an Brightness mode optimum contrast performance. ReSync Automatically synchronize the projector to the input source.

  • Page 75: Ir Remote Control 2 Codes

    aDDITIonal InfoRmaTIon IR remote control 2 codes Power Switch Freeze Enter Page+ Laser Page- V Keystone Volume Menu HDMI Video User1 User2 User3 Source Resync Printing-key Description code definition Power Power on/off Press to turn on / off the projector. Switch Switch Press to switch the USB mouse on / off.
  • Page 76 aDDITIonal InfoRmaTIon Printing-key Description code definition Enter Enter Confirm your item selection. Enter Page - Page- Press to page down. Laser Laser Use as laser pointer. Page + Page+ Press to page up. Keystone+ Press to adjust image distortion caused by tilting the V Keystone projector.

  • Page 77: Troubleshooting

    aDDITIonal InfoRmaTIon Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...

  • Page 78: Warning Indicators

    aDDITIonal InfoRmaTIon Two images, side-by-side format ‡ Press "3D" button and switch to "SBS" for input signal is HDMI 1.3 2D 1080i side-by-side. Image does not display in 3D ‡ Check if the battery of 3D glasses is drained. ‡ Check if the 3D glasses is turned on.
  • Page 79 aDDITIonal InfoRmaTIon lED lightning messages Power LED Power LED Temp-LED Lamp-LED Message (Red) (Green or Blue) (Red) (Red) Standby state Steady light (Input power cord) Flashing Flashing Flashing Flashing Standby state (Burn (0.5 sec off / (0.5 sec off / (0.5 sec off / (0.5 sec off / in mode)
  • Page 80 aDDITIonal InfoRmaTIon ‡ Temperature warning: Warning TEmPERaTURE Too HIGH Please: 1. Make sure air in and outlets are not blocked. 2. Make sure the environment temperature is under 45 degree C. If the problem persists in spite of the above. Please contact a service center for repair.

  • Page 81: Specifications

    UsInG THE PRoJECToR Specifications optical Description Native resolution XGA/ WXGA/ 1080P Lens Manual zoom and manual focus Image size (diagonal) 22.9”~252” (overdrive to 300”) Projection distance 1m ~ 10m (focus range) (overdrive to 12m) Electrical Description Color reproduction 1073.4 Million color - Horizontal scan rate: 15.375~91.146 KHz Scan rate - Vertical scan rate: 50~ 85 Hz (120Hz for 3D feature projector)

  • Page 82: Optoma Global Offices

    UsInG THE PRoJECToR Optoma global offices For service or support, please contact your local office. Japan 3178 Laurelview Ct. 888-289-6786 東京都足立区綾瀬3-25-18 Fremont, CA 94538, USA 510-897-8601 info@os-worldwide.com 株式会社オーエス www.optomausa.com services@optoma.com 0120-380-495 www.os-worldwide.com コンタクトセンター: Canada Taiwan 3178 Laurelview Ct. 888-289-6786 12F., No.213, Sec. 3, Beixin Rd.,...
