- Page 1 LCD display solutions User Manual 28” 4K 3840 x 2160@60Hz LCD AP-K28 Aluminum front bezel NAP-K28 Front NEMA4 / IP65 DP-K28 Aluminum Front Panel OP-K28 Universal Open Frame Designed and manufactured by Austin Hughes UM-UV-621-K28-Q221V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, April 2021 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > AP-K28 / NAP-K28 Package Content Structure Diagram & Dimension Mounting Hardware & Installation < Part. 2 > DP-K28 Package Content Structure Diagram & Dimension Mounting Hardware & Installation < Part. 3 > OP-K28 Package Content Structure Diagram &... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > AP-K28 / NAP-K28 < 1.1 > Package Content 28” 4K LCD Display AP-K28 / NAP-K28 28” 4K LCD Display X 1 6ft DP cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Power Audio HDMI 1.4...
- Page 6 < 1.2 > Structure Diagram Front view Side View AP-K28 NAP-K28 Bottom view Rear case Rear view LCD panel 6mm aluminum front bazel Audio speaker, pair LCD membrane Remote sensor Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 703.9 x 71.3 x 424.5 mm...
-
Page 7: Ap-K28 / Nap-K28
< 1.2 > Dimension 28” 4K LCD Display Front View Side View AP-K28 NAP-K28 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-K28-Q221V1 www.austin-hughes.com... - Page 8 < 1.3 > VESA Installation VESA mount ( 100*100mm ) ■ Hardware and M6*4 pcs for VESA mount are not provided UM-UV-621-K28-Q221V1 www.austin-hughes.com...
-
Page 9: Package Content
< Part 2 > DP-K28 < 2.1 > Package Content 28” 4K LCD Display DP-K28 28” 4K LCD Display X 1 6ft DP cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Power Audio HDMI 1.4 HDMI 2.0 UM-UV-621-K28-Q221V1 www.austin-hughes.com... -
Page 10: Structure Diagram & Dimension
< 2.2 > Structure Diagram Front view Side View DP-K28 Bottom view Rear case Rear view LCD panel 8mm aluminum front cover Audio speaker, pair LCD membrane Remote sensor Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 681.9 x 66.8 x 402.5 mm... -
Page 11: Part. 2 > Dp-K28
< 2.2 > Dimension 28” 4K LCD Display Front View Side View DP-K28 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-K28-Q221V1 www.austin-hughes.com... - Page 12 < 2.3 > VESA Installation VESA mount ( 100*100mm ) ■ Hardware and M6*4 pcs for VESA mount are not provided UM-UV-621-K28-Q221V1 www.austin-hughes.com...
-
Page 13: Package Content
< Part 3 > OP-K28 < 3.1 > Package Content 28” 4K LCD Display OP-K28 28” 4K LCD Display X 1 6ft DP cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Power Audio HDMI 1.4 HDMI 2.0 UM-UV-621-K28-Q221V1 www.austin-hughes.com... -
Page 14: Structure Diagram & Dimension
< 3.2 > Structure Diagram Front view Side View OP-K28 Bottom view Rear case LCD panel Rear view Universal open frame mounting Audio speaker, pair LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Product Dimension Packing Dimension Gross... -
Page 15: Part. 3 > Op-K28
< 3.2 > Dimension 28” 4K LCD Display Front View Side View OP-K28 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-K28-Q221V1 P.11 www.austin-hughes.com... - Page 16 < 3.3 > Installation ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) VESA mount ( 100*100mm ) ■ Hardware and M6*4 pcs for VESA mount are not provided UM-UV-621-K28-Q221V1 P.12 www.austin-hughes.com...
-
Page 17: Product Specifi Cations
< Part 4 > < 4.1 > Product Specifi cations 28” 4K LCD Display Mechanical Design AP-K28 NAP-K28 DP-K28 OP-K28 Protection 6mm front bezel NEMA 4 / IP65 front cover open frame Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005 VESA mount 100 x 100 mm Universal mount... - Page 18 < 4.1 > Product Specifi cations Environmental Conditions Operating Temperature 0 to 55°C degree Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Temperature -20 to 60°C degree Non-operating Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration ( 11ms duration ) Vibration 10~300Hz 0.5G RMS random vibration Physical Specifi...
-
Page 19: On-Screen Display Operation ( Osd )
< 4.2 > On-screen Display Operation ( OSD ) 28” 4K LCD Display Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen... - Page 20 < 4.2 > On-screen Display Operation ( OSD ) Picture Brightness : Adjust the screen brightness Contrast : Adjust the difference between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position Picture size : Adjust the image size...
- Page 21 < 4.2 > On-screen Display Operation ( OSD ) 28” 4K LCD Display Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) / PBP 3WIN ( Main screen + 2 sub screen ) / PBP 4WIN ( Main screen + 3 sub screen ) Select the signal input of each sub screen...
-
Page 22: Picture In Picture ( Pip ) / Picture By Picture ( Pbp )
< 4.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 4.3.1 > Picture in Picture ( PIP ) Mode Display the Sub screen in the Main screen. OSD Menu → MISC → PIP Mode → Large / Small / OFF Main screen Sub screen Position... - Page 23 28” 4K LCD Display < 4.3.2 > Picture By Picture ( PBP ) Mode Display the Sub screen next to the Main screen. OSD Menu → MISC → PIP Mode → PBP Main screen Sub screen Size LCD Monitor Main / Sub screen 1920 x 1200 955 x 716 1920 x 1080...
-
Page 24: Remote Controller ( Rc-2 )
< 4.4 > How to Use RC-2 Remote Controller INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 and 0 - 9 above, enter the second digit within two seconds. -
Page 25: Options
< Part 5 > Options < 5.1 > Option Table 28” 4K LCD Display Options AP / NAP ✓ ✓ ✓ ✓ ✓ ✓ MCS multi-screen control Touchscreen ✓ ✓ ✓ DC Power ✓ ✓ ✓ MIL-type / lockable connector ✓... - Page 26 < 5.2 > Options : 12G / 4K60 / SD-SDI Austin Hughes’ SDI input is an ideal solution for the broadcast-grade video and high resolution CCTV market. Designed for use with displays, a SDI input module can support up to 3840 x 2160p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 27 < 5.3 > Options : 3G / HD / SD-SDI input 28” 4K LCD Display Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with UltraView displays, a SDI input...
- Page 28 More control is always good. Especially when it is necessary and ( Multi-display Control ) easy. Austin Hughes provides MCS solution to control the OSD of various UltraView LCD display up to 64 units. The RS-232C is used for the communication between the PC and the fi...
- Page 29 < 5.5 > Options : DC Power 28” 4K LCD Display Model 125V Input rating Input voltage: 24-Volt 48-Volt 110-Volt Input range: 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current - No load 50 mA 50 mA 40 mA - Full load 4880 mA...
- Page 30 < 5.6 > Options : MIL-type or Lockable Connector Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
- Page 31 < 5.7 > Options : Quad Display 28” 4K LCD Display QD Specifi cation Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System NTSC Resolution 1024 x 525 1024 x 625 Refresh Rate Video Input 1.0 Vpp, 75 Ohm x 4 Camera Input...
- Page 32 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2021 Austin Hughes Electronics Ltd. All rights reserved. UM-UV-621-K28-Q221V1 www.austin-hughes.com...
