SPECIFICATIONS

SPECIFICATIONS
Power Output
Normal Mode: 250 W RMS × 1 channels at 4 Ω and
≤ 1% THD + N
Signal-to-Noise Ratio: 60 dBA (reference: 1 W into 4 Ω)
Power Output
Normal Mode: 400 W RMS × 1 channels at 2 Ω and ≤ 1% THD + N
Maximum Power Output
800 W
Load Impedance
Normal Mode: 4 Ω (2 Ω to 8 Ω allowance)
Frequency Response
20 Hz to 200 Hz ( +0 dB, –3 dB)
Input Sensitivity/Impedance
2 V/21 kΩ (0.2 V to 5 V, variable)
Distortion
Less than 0.08% (at 100 Hz)
Power Requirement
DC 14.4 V (11 V to 16 V allowance)
Grounding system
Negative ground
Dimensions (W×H×D)
227 mm × 52 mm × 185 mm
(8-15/16 in. × 2-1/16 in. × 7-5/16 in.)
Mass (approx.)
1.7 kg (3.8 lbs)
Accessories
Speaker input connector 4P × 1
Mounting Screw Ø 4 (3/16 in.) × 20 mm (13/16 in.) × 4
Design and specifications are subject to change without notice.
English
