UI elements

The user interface you open with the Web browser is divided into the following sections:
1
Home Basic Setup Wizard
Operating Mode
Internet
...
...
...
Antenna selection
5
Tab selection:
1
Open the Home, Basic Setup Wizard, Advanced Settings or Status tabs to
display the contents of each configuration area.
Language button:
2
Select your language. This button is only available on the Home screen.
Logout button:
3
This button is only displayed if a system password is set up.
Log off from your SE681 WiMAX.
Open Help window button:
4
Open the online Help relating to the menu item currently in the working area.
Menu area:
5
Click the menu items to display the respective pages of the currently open con-
figuration area or a submenu.
Working area:
6
Check the settings on your SE681 WiMAX and change them as necessary.
Advanced Settings
User interface
2
Language
Status
6
3
Logout
4
21
