4.3.3 AC Current measurement

1. Rotate the switch on position on a measurement range between 2A
the current value under test is unknown, select the highest range
2. Fig. 4), then the current value is shown at display
3. "OL" message is shown at display the current under test is over the maximum value
that the instrument is able to measure
4. For HOLD and MAX functions please refer to paragraph 4.2
1.888.610.7664
Make sure that all the test leads are disconnected from the meter terminals
for current measurement.
Fig. 4: Taking AC current measurement
Put the conductor to be tested inside to the clamp jaw (see
www.calcert.com
15
10 20
5 25
0 30
CAUTION
EN - 11
HT4010
and 600A . If
