Installation, Service and User Instructions
Built-in gas hotplates
DIMENSIONS: 36
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
OBSERVE ALL GOVERNING CODES AND ORDINANCES.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapors and liquid in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
- If you cannot reach your gas suppliers, call the fire department.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
Read this instruction booklet before installing and using the appliance.
The manufacturer will not be responsible for any damage to property or to persons caused by
incorrect installation or improper use of the appliance.
The manufacturer reserves the right to make changes to its products when considered necessary and useful,
without affecting the essential safety and operating characteristics.
This appliance has been designed for non-professional, domestic use only.
(French version page 10)
1/2
Models B3H0..Q7X(2 or 5)D
Models B3K0..U7X(2 or 5)D
BERTAZZONI
''
(W) x 21
(925 mm)
''
(D)
1/4
(540 mm)
Type 'A'
Type 'B'
Cod. 310498
Advertisement
Table of Contents
Related Manuals for Bertazzoni B3H0 Q7X2 D Series
Summary of Contents for Bertazzoni B3H0 Q7X2 D Series
- Page 1 Installation, Service and User Instructions (French version page 10) BERTAZZONI Built-in gas hotplates DIMENSIONS: 36 ’’ (W) x 21 ’’ (925 mm) (540 mm) Models B3H0..Q7X(2 or 5)D Type ‘A’ Models B3K0..U7X(2 or 5)D Type ‘B’ IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR’S USE.
-
Page 2: Table Of Contents
INDEX: Installation Instructions……………………………………..………………………..pag.2 Inserting the hotplate……………………………………………..…………………..pag.3 Requirements……………………………………..……………………………….…..pag.3 Attaching the hotplate……………………………………..………………………….pag.4 Gas connection……………………………………..…………………………………pag.4 Electrical connection……………………………………..……………………….…..pag.5 Wiring diagrams……………………………………..…………………………….…..pag.5 Room ventilation…………………………………….…………………………………pag.5 Location and venting…………………………………….…………………………….pag.5 Replacement of nozzles……………………………………..………………………..pag.5 Regulation of burners……………………………………………...………………….pag.6 Descriptions…………………………………………………………………………….pag.6 Service & maintenance instructions……………………………..…………………..pag.6 Greasing the valves……………………………………………..…………………….pag.7 User instructions……………………………………………..………………………..pag.7 Using burners……………………………………………………..……………………pag.7 Cleaning the appliance……………………………………………..…………………pag.8 Figures………………………………………………...…………..……………………pag.19 Installation instructions This appliance shall only be installed by an authorized person. -
Page 3: Inserting The Hotplate
The minimum gas supply pressure for checking the regulator setting shall be at least 1“ w.c. (249 Pa) above the inlet specified manifold pressure to the appliance (this operating pressure is 4” w.c. (1.00 kPa) for Natural Gas and 11” w.c. (2.75 kPa) for LP Gas). ATTENTION: A manual valve shall be installed in an accessible location in the gas line external to the appliance for the purpose of turning on or shutting off gas to the appliance WARNING: Do not use aerosol sprays in the vicinity of this appliance while it is in operation... -
Page 4: Attaching The Hotplate
Attaching the hotplate To prevent liquids from leaking accidentally into the underlying storage space, the appliance is equipped with a special gasket. To apply this gasket, carefully follow the instructions in Fig. 3. Lay out the protective sealing strips along the edges of the opening in the bench top and carefully overlap the strip end. (See Fig. 3). insert the hotplate into the bench top opening. -
Page 5: Electrical Connection
Electrical connection The connection of the hobs to mains is effected via the flex and the three pin plug located underneath the hotplate. The appliance operate at a main voltage of 120V a.c., frequency 60Hz. Electric power absorption is about 1W for 5 gas burner version or 2W for 6 gas burners version. WARNING: Electrical Grounding Instructions: This appliance is equipped with a (three-prong) grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptable. -
Page 6: Regulation Of Burners
CAUTION: save the orifices removed from the appliance for future use Regulation of burners Regulation of the "MINIMUM" on the burners To regulate the minimum on the burners carry out the following procedure indicated below: 1) Turn on the burner and put the knob onto position MINIMUM ( small flame ). 2) Remove the knob ( Fig. -
Page 7: Greasing The Valves
For the location of the wall receptable for the connection of the three-pin earthed plug of the appliance, see indications given in Fig. 1- 2 WARNING: After first installation of the appliance or after any service intervention concerning main gas parts of the appliance, make the leak test using water with soap on the gas connections in order to verify the correct installation. -
Page 8: Cleaning The Appliance
Note: It is recommended not to try to ignite the burner if the relative flame cap is not in the correct position Tips for using burners correctly: WARNING: During use of each gas burner(s) adjust the burner flame size properly so it does not extend beyond the edge of the cooking utensil. - Page 9 After sale service: Dealer /Importer: Name, address, phone SERVICE CENTERS Name Phone MANUFACTURER: BERTAZZONI SPA VIA PALAZZINA, 8 – 42016 – GUASTALLA (REGGIO E.) ITALY Tel. 0522/226411 – telefax 0522/226440 – http://www.bertazzoni-italia.com...
- Page 10 Installation, Service et Instructions pour l’Utilisateur BERTAZZONI Tables de cuisson gaz à encastrer DIMENSIONS: 36 ’’ (W) x 21 ’’ (925 mm) (540 mm) Modèles B3H0..Q7X(2 or 5)D Type ‘A’ Modèles B3K0..U7X(2 or 5)D Type ‘B’ IMPORTANT: A CONSERVER POUR L’UTILISATION DE L’INSPECTEUR ELECTRIQUE LOCAL.
- Page 11 INDEX: Instructions d’installation..…………………………………..………………………...page 11 Insertion de la table de cuisson..………………………………..………………….. .page 12 Exigences…..……………………………………..……………………………….….. page 12 Fixation de la table de cuisson….………………………..………………………….. page 13 Branchement du gaz………………………………..………………………………….page 13 Branchement électrique…………………………………..……………………….…..page 13-14 Schéma de câblage..………………………………..…………………………….…...page 14 Ventilation du local……………………………………………………………… ……page 14 Positionnement et dégazage…………………………….……………………………page 14 Remplacement des becs….…………………………………..………………………page 14 Réglage des brûleurs….
- Page 12 Le kit d’injecteurs pour le changement du type de gaz est contenu dans l’emballage avec le kit d’installation de la table et le livret d’instructions. La pression d’alimentation maximum du gaz en entrée dans le régulateur de pression de l’appareil à gaz est de 20’’...
- Page 13 (*) Notes: -B1 est la distance min. entre le bord frontal de l’appareil et le bord frontal de l’armoire. -B2 et B4 sont les distances minimum entre le bord latéral droit/gauche de l’appareil et le mur latéral (si présent). -B3 est la distance minimum entre le bord arrière de l’appareil et le mur arrière. Fixation de la table de cuisson Pour empêcher aux liquides de fuir accidentellement dans l’espace de stockage sous-jacent, l’appareil est équipé...
- Page 14 Branchement électrique Le branchement de la table de cuisson au réseau est effectué par le fil électrique et la fiche tripolaire positionnée sous la table de cuisson. L’appareil fonctionne à une tension du réseau de 120V c.a., fréquence 60Hz. L’absorption d’énergie électrique est d’environ 1W pour la version au 5 brûleur à gaz ou 2W pour la version de 6 brûleurs à...
- Page 15 Modèle B3K0..U7X(2 or 5)D Brûleur Position Diam inj. Dèbit nom. Dèbit reduit By-pass Pressure size 1/100mm Type [i.w.c.] [BTU/h] [BTU/h] [1/100mm] Auxiliaire Frontale D. 0,92 4” 3750 1098 réglé 0,56 LP(Propane) 11” 3750 1098 0,29 Semi-Rapide Arriere G et C 1,17 4”...
- Page 16 Descriptions LEGENDE DESCRIPTIVE POUR LES DESCRIPTION DES TABLES TABLES DE CUISSON 1. Brûleur petit Modèle ‘A’ Fig. 11 2. Brûleur moyen Modèle ‘B’ Fig. 12 3. Brûleur rapide 4. Brûleur dual (poêle chinoise) 5. Bouton de commande du brûleur frontal gauche 6.
- Page 17 Ne stockez aucun matériel dangereux ou inflammable dans les meubles suspendus sur l’appareil; stockez-les dans un lieu sûr pour éviter les risques potentiels. Pour une utilisation sûre de l’appareil, ne l’employez pas pour le chauffage des locaux. N’utilisez pas de pulvérisateurs d’aérosol à proximité de cet appareil lorsqu’il est en fonction Pour la description des tables de cuisson, référez-vous aux instructions d’installation.
- Page 18 - Quand vous utilisez les brûleurs, assurez-vous d’avoir positionné correctement les manches des casseroles. Tenir les enfants loin de l’appareil. - Quand vous cuisinez des mets avec de l’huile ou de la graisse, qui sont très inflammables, l’utilisateur ne devra pas laisser l’appareil sans surveillance. ATTENTION: Si l’alimentation est découpée, les brûleurs peuvent être allumés avec des allumettes.
- Page 19 Service après vente: Revendeur /Importateur: Nom, adresse, téléphone CENTRES DE SERVICE Téléphone FABRICANT: BERTAZZONI SPA VIA PALAZZINA, 8 – 42016 – GUASTALLA (REGGIO E.) ITALY Tél. 0522/226411 – fax 0522/226440 – http://www.bertazzoni-italia.com...
- Page 20 Fig 1 Fig 2 Fig.3 Fig.4 Fig.5 Fig.6...
- Page 21 Fig.7 Fig.8 Inches 1” 11/16 1” 3/16 1” 1/16 4”7/16 Fig.9 Fig.10...
- Page 22 Fig.11 Fig.12 Fig.13 Fig.14 Fig.15...
- Page 23 Fig.16 Fig.17...
