- Page 1 Inch (Viewable size 18 ) High Resolution Color Monitor (B19CL) Printed on the recyclable paper Printed in Korea Part No. 942149060001 - 02...
- Page 2 FCC Information This equipment has been tested and found to comply with limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful inteference to radio Communications.
- Page 3 Introduction Introduction Caution Features Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 19-inch(18 inch visual)high performance display color monitor Warning Automatically scans frequencies from If this equipment has more than one interface connector, do not leave cables connected to - Horizontal frequency: 30 to 96KHz unused interfaces.
- Page 4 Introduction Introduction Safety information Power management system Provided with this monitor is a detachable power supply cord with IEC320 style terminations. This monitor meets VESA(Video Electronics Standards Association) DPMS(Display Power It may be suitable for connection to any UL listed personal computer with similar Management Signalling)standards.
- Page 5 Installation Controls Pin assignment table D-Sub Mini 15pin connector Additional up front controls Power Switch : Turns the monitor power on or off, When the power is on, the LED is lit. Pin No. 15 Pin D-Sub Macintosh Red Video Red Ground Accessing on screen menu Green Video...
- Page 6 Controls Controls Geometry Controls Menu Contrast & Brightness Menu 31.5KHz 60Hz 31.5KHz 60Hz GEOMETRY PINCUSHION CONTRAST BRIGHTNESS PARALLELOGRAM The Geometry controls allow you to adjust the TRAPEZOID PINBALANCE curvature or angle of displayed image. TOP CORNER BOTTOM CORNER ROTATION EXIT : Exit the Brightness or Contrast menu. Cursor : Increase or decrease the Brightness Pincushion : Increase or decrease the curvature of the sides either inward or outward.
- Page 7 Controls Troubleshooting OSD Position Menu Troubleshooting guide POSITION : Moves the OSD Position vertically up or down. If your monitor is not performing properly, please use the following troubleshooting chart for : Moves the OSD Position horizontally left or quick solutions to common problems. right.
- Page 8 Specifications Appendix Preset Timings Electrical Specifications ITEM B19CL This Monitor B19AL has preset modes for the 14 most popular industry standards for Plug and CRT Type 19 , 90 deflection, FST Play capability. CRT Dot pitch 0.26mm (0.22 in Hor.)
