Summary of Contents for Hansol H950
- Page 1 TFT-LCD Color Monitor Printed on the recyclable paper Printed in Korea Part No. 942205010002- 01...
-
Page 2: Table Of Contents
Changes or modifications not expressly approved by the Troubleshooting manufacturer responsible for compliance could void the user's authority to operate the equipment Warning ENERGY STAR As an ENERGY STAR partner, Hansol Electronics Inc. has determined that this product meets energy Star guidelines for energy efficiency. -
Page 3: Parts
Good Posture Guide Parts Place the monitor to face the user and then adjust the monitor angle. Take a break (for about 10 minutes) at every hour during the work with monitor. Refer to the following figure to take the correct posture. Look down the monitor below the horizon. -
Page 4: Connection To Signal Source
Connection to Signal Source The range of control Angle How to Adjust the Stand Basic Connection Port for AC power cable Port for Audio cable from audio source. Port for Head Phone or External Speaker Port for signal cable from DVI signal source. Kensington Lock Port for signal cable from analog signal source. -
Page 5: Installing Monitor Driver
Installing Monitor Driver Run (Click) "Install" at Floppy Diskette driver and select the model name to set the optimum display in Window 95, 98 or 2000, XP. Use the Driver provided. Click 'Monitor'. Click 'Next>'. Click 'Advanced..'. Click 'Change..'. Automatic Installation 1. -
Page 6: Name And Function Of Front
Name and Function of Front Front panel Functions Power button Power button is located in the lower center of the Front Bezel. You can push the button to turn on/off the power. Power Indicating LED Dark : Power off Green : Normal mode Green blinking : DPMS mode or Check Signal Cable mode. -
Page 7: Power Management Feature
Power Management Feature Adjusting OSD The monitor is equipped with a power saving circuit that confirms to the world-standard Display Power Manager Signalling Input Source (DPMS) mode of Video Electronics Standard Association (VESA). The power management feature requires that the video card of the computer should support DPMS function. - Page 8 Image Brightness &Contrast SELECT MENU MENU SELECT 1. Press the MENU button to access main menu. 1. Press the MENU button to access main menu. 2. Use to move Image ICON. 2. Use to move Brightness and Contrast ICON. 3. Press SELECT button into the submenu. 3.
- Page 9 Clock Phase Preset Color MENU SELECT 1. Use to select the 6500K, and 9300K. 1. Press to move Clock Phase ICON. 2. Press the Menu button to return previous state. 2. Use SELECT button to select it. 3. Use to correct fine trembling or Video noise. 6500K : Reddish white 9300K : Bluish white User Color...
- Page 10 OSD H-Position Language MENU SELECT SELECT 1. Use to move OSD H-Position ICON. 1. Use to move Language ICON. 2. Press SELECT button to select it. 2. Press SELECT button to select it. 3. Use to adjust OSD left or right. 3.
-
Page 11: Standard Signal Table
Sound (Option) Auto-Config SELECT or MENU VOL BUTTON 1. When change DVI display into Analog display, select source button located in the left. 1. Use to move Sound ICON. Analog display will be showed after Analog input message. 2. Press SELECT button to select it. 3. -
Page 12: Specification
Pin assignment table D-Sub Specification Mini 15pin connector Model H950 (B19AF Type Amorphous active matrix super TFT LCD Screen Size 48.3cm (Diagonal) Maximum Resolution 1280 X 1024 @ 75 Hz Pin No. Assignment Pin No. Assignment Red Video 5V Input Pixel Range 0.294 mm X 0.294 mm... -
Page 13: Troubleshooting
Troubleshooting Power LED is dark. Check the power connection. Adjust COLOR at User Mode in OSD Color Color is irregular. No picture. (Refer to page 4) Menu. OSD, "check signal." Check the resolution and frequency of is displayed on the Check the computer power is on. -
Page 14: Warning
Warning To prevent damage or loss, please read this warning carefully. When connecting/disconnecting the plug, pull out the plug itself, and never pull the cord to prevent fire caused by short. To prevent electric shock, do not connect/dis- connect the plug with wet hand. If you see smoke or smell something burning, stop using the unit, switch off the power, pull out the plug, and then contact your local service station.
