  • Page 1 Network Camera Quick Guide DC-T1833WHR Powered by...

  • Page 2: Safety Precautions

    Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. Read Instructions 10. Overloading Do not overload wall outlets and extension cords as this can result All the safety and operating instructions should be read before the appliance is operated.

  • Page 3: Fcc Compliance Statement

    IDIS Co., Ltd. reserves all rights concerning this document. Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this document are subject to change without prior notice for reasons such as functionality enhancements.
  • Page 4 Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. Some parts may differ depending on the situation. Network Camera Mounting Bracket Camera Sun Shield Open Source Guide Quick Guide Allen Wrench Sun Shield Screw, O Ring (1ea.) Screws (4ea.) Ferrite Core...

  • Page 5: Camera Installation

    Cable Network Port BNC Video Out (Yellow Cable) Power In (Red Cable) FGND Audio In Audio Out Alarm In Alarm Out Camera Installation Screw the camera sun shield to the camera using the screw and rubber provided with the camera. Screw the mounting bracket to the wall or ceiling by using screws provided with the camera.

  • Page 6: Specifications

    Specifications External Dimensions (Ø x H) 90mm x 321.9mm Weight (Main Unit) 3.06 lbs. (1.39kg) Working Temperature -40°C ~ +50°C (-40°F ~ +122°F) [-20°C ~ +50°C (-4°F ~ +122°F) when the heater is operating] Operating Humidity 0% ~ 90% Power Input 12VDC, PoE(IEEE 802.3af, Class3) Power Consumption Max.
  • Page 12 IDIS Co., Ltd. For more information, please visit www.idisglobal.com...
