Zephyr Duo Is. ADL-E42ASX Specifications page 2

ARC COLLECTION
D U O
MODEL
A D L- M 9 0 A S X
A D L- E 4 2 A S X
FEATURES
Controls
Speed Levels
Auto Delay-Off
CleanAir Function
Remote Control
Lighting
Tri-Level Lighting
Filters
Recirculating
Duct Cover Extension
PERFORMANCE
*
Internal Blower - CBI-290A
Internal Blower - CBI-600A
In-Line Blower - PBN-1000A
External Blower - CBE-1000
AC INPUT
AC POWER
**
Hood Only
MOUNTING HEIGHTS
Height from the cooking surface
HOOD HEIGHTS
Standard
Minimum Ducted
Minimum Recirculating
Maximum
Short Kit - Z1C-00LL
Minimum Ducted
Minimum Recirculating
Maximum
Long Kit - Z1C-01LL
Minimum Ducted
Minimum Recirculating
Maximum
DUCT SPECIFICATIONS
Vertical - Internal
Vertical - In-Line/External
Horizontal
OPTIONAL ACCESSORIES
Recirculating Kit
Duct Cover Extension Kit, Short
(8 1/2'–9 1/2' ceiling)
Duct Cover Extension Kit, Long
(9 1/2'–12' ceiling)
WOOD TRIM
Charcoal - 1 5/8", 90cm
Charcoal - 1 5/8", 42"
Wenge (brown) - 1 5/8", 90cm
Wenge (brown) - 1 5/8", 42"
* Requires purchase of Zephyr blower, sold separately. **AC power listed above is for hood
with lights only. See blower specs on our website for more AC power details. ***10" round
duct connects to external and in-line blower. Must transition from 10" to 8" before duct
passes through ceiling. A 10" to 8" adapter is included with the external and in-line blowers.
ISLAND
36"
42"
Memory Touch Glass
3
Yes
Yes
Yes, RF
Halogen, 20W x 4
Yes
Decorative Mesh x 3
Yes
Yes
290 CFM, 3.2 Sones Max.
600 CFM, 6 Sones Max.
1000 CFM, Sones NA
1000 CFM, Sones NA
120V - 60Hz
Max. 80W, 0.66 Amps
Min. 24"–Max. 36"
30"
30"
34"
37 1/2"
37 1/2"
49"
53 1/2"
53 1/2"
79"
6"
10" to 8"***
NA
ZRC-00LL
Z1C-00LL
Z1C-01LL
AUW-00CH
AUW-01CH
AUW-00BR
AUW-01BR
9 1/4"
C L
elec. k/o
6 11/16"
7 1/2"
Top
(blower housing and ceiling bracket)
11 3/16"
3 1/8"
23 5/8"
Side
12 15/16"
blower
housing
11 7/8"
35 7/16" or 42"
Front
Zephyr Corporation
2277 Harbor Bay Parkway 1.888.880.VENT
Alameda, CA 94502 www.zephyronline.com
ext. blower
connection
5/8"
min. ducted - 30"
min. recirc. - 30"
max. - 34"
nov08.0101
