Installing and Removing the Optional Table Top Stand

CAUTIONN: • Installing and removing the stand must be done by two or more people.
• When installing the monitor stand, handle the unit with care to avoid pinching your fingers.
For installation, follow the instructions included with the stand or mounting equipment. Use only those devices recommended by
the manufacturer.


NOTEN: • For UN462A/UN462VA/UN492S/UN492VS, ONLY use thumbscrews which are included with the optional
table top stand.
For UN552A/UN552S/UN552VS, ONLY use thumbscrews which are included in the monitor.

• Install the stand so the long end of the feet face forward. Use the ST-322 for the UN462A/UN462VA/UN492S/
UN492VS and the ST-5220 for the UN552A/UN552S/UN552VS.

• UN492S/UN492VS: DO NOT use this monitor on the floor with the table top stand. Please use this monitor on a table
or with a mounting accessory for support.
Prevent Tipping


CAUTIONN:
When using the monitor with the optional table top stand, fasten the monitor to a wall using a cord or chain that can support
the weight of the monitor in order to prevent the monitor from falling. Fasten the cord or chain to the monitor using the provided
clamps and screws.
For the UN462A/UN462VA/UN492S/UN492VS, the clamps and screws are included with the optional table top stand.
UN462A/UN462VA/UN492S/UN492VS
100 mm
Screw Holes
Clamp
Screw (M4)
Before attaching the monitor to the wall, make sure that the wall can support the weight of the monitor.


CAUTIONN: Be sure to remove the cord or chain from the wall before moving the monitor.
Table
Cord or chain
Optional table top stand
Soft cloth
UN552A/UN552S/UN552VS
325.9 mm
Clamp
Screw (M4)
English−15
Screw Holes
Cord or chain
