3. Installing an Option Board
1. Turn off the main power switch.
2. Place the monitor face down on the protective sheet.
NOTEN: Be sure to place the monitor on a flat and adequate space.
3. Remove the attached slot cover by unscrewing the installed screws (Figure 1), sliding to right (Figure 2) and moving up
(Figure 3).
Figure 1
4. Insert the Option Board into the monitor and fix it with the removed screws (Figure 4).
(Recommended Fasten Force: 139 - 189N•cm).

NOTEN:
Unless your monitor is purchased as part of a special bundle package, no Option Boards will be in the box or installed
in the monitor. These are optional accessories available for separate purchase. Please contact your supplier for a list of
Option Boards available for your monitor.

M ake sure the board is inserted into the slot in the correct orientation.

D o not apply excessive force to manipulate the Option Board before attaching it with screws.


WARNINGN: Please refer to

Installing and Removing the Optional Table Top Stand

WARNINGN:

Please refer to


CAUTIONN: Please refer to
For installation, follow the instructions included with the stand or mounting equipment. Use only those devices recommended by
the manufacturer.


NOTEN:
• Use the ST-801.

• ONLY use screws which are included with the optional table top stand.
Install the stand so the long end of the feet face forward.

• The monitor can only be used in the landscape orientation with the tabletop stand.
Figure 2
"WARNING 14".
"WARNING 8".
"CAUTION 5".
Table
Figure 3
Optional table top stand
Soft cloth
English−18
