USER GUIDE

Grille Installation

REMOVING AND INSTALLING GRILLE

!
WARNING
Disconnect electric power to the unit before
removing the grille.
When using the unit, the grille must be installed.
!
WARNING
DO NOT touch the condenser fins. The condenser
fins are SHARP and can be easily damaged.
Removing the grille
1. Disconnect power to the unit.
2. Loosen the two screws (1).
3. Remove grille (2) from unit.
Installing the grille
1. Align cabinet and grille holes and secure, but do not
over tighten grille screws (1).
2. Reconnect power to the unit.
Grille Installation
1
2
16
