Chapter 5
Setup & Configuration
In order to configure Wasp WCS3900 Series Scanners, you must
familiarize yourself with the setup procedures on the following pages. The
default settings of the scanners are identified on each page and clearly
The default settings have been
marked using an asterisk (*).
programmed for the most common barcode configurations. Use
the setup & configuration barcodes only to customize the
WCS3900 Series Scanner settings.
If you need to configure the
Scanner, the default settings will be overwritten. All the programmed
settings are stored permanently in non-volatile memory; therefore, your
configuration will be maintained even if the keyboard power to the
WCS3900 Series Scanners are removed by turning off your PC.
In order to configure Wasp WCS3900 Series Scanners,
two basic steps need to be followed:
(1) Locate the group that contains the options to be changed.
(2) Scan the barcode representing the option to be changed.
The scanner will sound two beeps.
To change Minimum/Maximum Length:
(1) Scan the Minimum or Maximum Length barcode on page 15.
(2) Scan a 2 digit value from the ASCII table on pages 31-34
(3) Scan the Minimum or Maximum Length barcode again.
Example:
To have a minimum length barcode of 1, you must scan a
0 then 1, then scan the minimum barcode again. To have a maximum
length barcode of 10, you must scan a 1 then 0, then scan the
maximum barcode again.
