Chapter 3
Installation
WCS3900 USB Scanner
1. Insert the USB cable directly into your PC's USB port.
WCS3900 PS2 Scanner
Scanning Aperture
1. Turn off your computer.
2. Unplug your PC keyboard cable and plug the male end (Din 6)
of the WCS3900 Scanner directly into your PC keyboard port.
Plug your keyboard cable into the other end (female Din 6) of the
the scanner.
3. Turn your computer on.
Trigger
USB Port
Trigger
Din-6M
Din-6F
4
Scanning Aperture
