Digisol DG-GR4342L Quick Installation Manual

Gepon/gpon onu 300mbps wi-fi router with 1 pon, 1 ge, 3 fe and 2 fxs port
Hide thumbs

Advertisement

Quick Links

Download this manual
GEPON/GPON ONU 300Mbps
Wi-Fi Router with 1 PON,
1 GE, 3 FE and 2 FXS Port
DG-GR4342L
V1.1
05-01-2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the DG-GR4342L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digisol DG-GR4342L

Summary of Contents for Digisol DG-GR4342L

  • Page 1 GEPON/GPON ONU 300Mbps Wi-Fi Router with 1 PON, 1 GE, 3 FE and 2 FXS Port DG-GR4342L V1.1 05-01-2021...
  • Page 2 Please check with your local distributors for the latest information. No part of this document can be copied or reproduced in any form without written consent from the company. Trademarks: ® DIGISOL is a trademark of DIGISOL SYSTEMS LTD. All other trademarks are the property of the respective manufacturers.
  • Page 3 They are highly reliable and easy to maintain, with guaranteed QoS for different service. And it is fully compliant with GPON and EPON technical regulations such as ITU-T G.984.x & IEEE802.3ah. DG-GR4342L is a dual mode ONU which can detect and exchange PON mode automatically.
  • Page 4 1:3 Technical Parameters Technical item DG-GR4342L PON interface 1 GPON/EPON connector, SC single-mode/single-fiber, GPON: uplink 1.25Gbps, downlink 2.5Gbps; EPON: symmetric 1.25Gbps Wavelength Tx:1310nm, Rx:1490nm Optical interface SC connector LAN interface 1* 10/100/1000Mbps and 3*10/100Mbps auto adaptive Ethernet interfaces (RJ45). 2* POTS (RJ11).
  • Page 5 1:5 Panel Description Figure 3 Name Function Connect PON port with internet by SC type, single mode optical fiber cable. FXS 1 / 2 Connect the telephone with FXS port by telephone wire. If you only have one telephone, you should use FXS1 port.
  • Page 6 1:6 Indication Panel Figure 4 Name Status Description Power is not supplied Power is supplied Device is not registered to EPON/GPON OLT Device has been registered to EPON/GPON OLT FLASH Device registered incorrect Rx optical power is normal Rx optical power is lower than the sensitivity of the FLASH optical receiver WAN is ineffective.
  • Page 7 Name Status Description Does not use WPS or WPS client is connected (LED turn off after 5 minutes of successful connection). WPS client is connected. (LED turn off after 5 minutes of successful connection) WPS client is connecting. FLASH Device is power off or USB device is not connected. USB device is connected, but without ongoing data transmission.

  • Page 8: Installation

    Installation 2:1 Quick Installation 1. Connecting the optical fiber cable to the unit. a) Remove the protective cap of the optical fiber. b) Clean the end of the optical fiber with an optical fiber end cleaner. c) Remove the protective cap of the ONU optical interface (PON interface).
  • Page 9 2:2 Set Up Connection Set Up Wired Connection Connect PC with ONU Ethernet port by RJ-45 cable. The PC will receive the IP automatically from the ONU DHCP server in the range of 192.168.1.x/24. Then access the ONU using IP address 192.168.1.1 with username/ password: admin Figure 5 Set Up Wireless Connection...

  • Page 10: Web Management

    Web Management DG-GR4342L provides simple Web management functions, including Device Information, modify LAN Management IP address, LOID and Password, Configuration File backup and restore, firmware upgrade etc... NOTE: About More ONU Detail Configuration should be configured via CTC OAM Protocols from OLT.
  • Page 11 Figure 9 WAN Connection Configure the WAN connection as per the ISP specified. Create DHCP/Static/PPPoE connection.
  • Page 12 Figure 10 LAN Settings IP address and Subnet Mask: LAN port IP address and mask DHCP option: Enable or disable the DHCP server and configure the IP address pool, DNS,etc NOTE: DHCP server changes takes effect after the device is restarted.
  • Page 13 Figure 11 WLAN Settings WLAN basic displays the current configuration information. Modify these parameters to change WiFi basic features. Security is used to set up encryption for each SSID and WPS function.
  • Page 14 Figure 12 Device Management Upgrade Firmware upgrade Menu displays the current equipment upgrades related information. Configuration File Management To download or restore the configuration file.
  • Page 16 DIGISOL SYSTEMS LIMITED L-7, Verna Industrial Estate, Digisol is a Subsidiary of Smartlink Holdings Limited Salcete, GOA - 403722 www.digisol.com 1800 209 3444 helpdesk@digisol.com...
