I M P O R T A N T I N S T A L L A T I O N
M E A S U R E M E N T S
D
A: Overall length
B: Overall width
C: Overall height
D: Height — flange bottom to tub bottom
E: Inside tub height
F: Center of overflow to tub bottom
G: Drain center to right tub edge
H: Inside bowl width at top of bowl
I: Inside bowl width at bottom of bowl
J: Inside bowl length at top of bowl
K: Inside bowl length at bottom of bowl
A
H
I
N
M
G
J
E
F
K
L: Flange edge depth
M: Top flange width
N: Drain center to edge of flange
O: Allow 1/2" to 1" to D for wet bedding
P: Pre-leveled frame height* – Adds
1/2"- 3" to height
Q: Air bath height* – Adds approximately
2" to height
* Please measure actual tub prior to building
any decking or framing. Specifications are
subject to change without notice. MTI Baths
is NOT responsible for any preparatory
labor or materials.
B
L
C
O
P Q
