  • Page 1 PZ7111/PZ7112/PZ7121/PZ7122 10x Zoom Dual Streams PoE IP Sur veillance...

  • Page 2: Table Of Contents

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Table of Contents Overview3 Read before use ��������������������������������������������������������������������������������������������������������������������������������������3 Package contents ������������������������������������������������������������������������������������������������������������������������������������3 Physical description ���������������������������������������������������������������������������������������������������������������������������������4 Installation 7 Hardware installation �������������������������������������������������������������������������������������������������������������������������������7 Network deployment ��������������������������������������������������������������������������������������������������������������������������������8 Software installation ������������������������������������������������������������������������������������������������������������������������������ 11 Accessing the Network Camera 12 Using web browsers ������������������������������������������������������������������������������������������������������������������������������12...

  • Page 3: Overview3

    Therefore, it can display clear-cut images on near or distant objects. With flexible 300-degree pan and 135-degree tilt, PZ71x1/71x2 can give users more comprehensive control over the monitored site� PZ71x1/71x2 is incorporated with VIVOTEK’s self-developed Bach SoC, giving users the advantages of dual-codec (MPEG-4 and MJPEG), dual streams and two-way audio by SIP protocol�...

  • Page 4: Physical Description

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Physical description Front panel Lens Status LED Rear panel Microphone in Ethernet 10/100 RJ45 socket Power cord socket General I/O terminal block General I/O Terminal Block This Network Camera provides a general I/O terminal block which is used to connect external input / output devices.

  • Page 5: Status Led

    Blinking red Solid green Steady green with blinking red Steady green and red Steady red with blinking green Blinking red and green VIVOTEK - A Leading Provider of Multimedia Communication Solutions PIN 1 Power+12V PIN 2 Digital output +12V PIN 3...
  • Page 6 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Hardware Reset Audio Audio There is an indented reset button on the side panel of the Network Camera� It is used to reboot the Network Camera or restore the Network Camera to factory default� Sometimes rebooting the Network Camera could set the Network Camera back to normal state�...

  • Page 7: Installation 7

    ► If you want to intall the Network Camera on the wall, please use the wall mount bracket (optional, not included in the package)� VIVOTEK - A Leading Provider of Multimedia Communication Solutions ► Keep away interference source to make sure performance integrate, and avoid snow or moiré...

  • Page 8: Network Deployment

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Network deployment Setup the Network Camera over the Internet This section explains how to configure the Network Camera to Internet 1� If you have external devices such as sensors and alarms, make connection from general I/O terminal block�...
  • Page 9 Internet connection via PPPoE (Point-to-Point over Ethernet) Choose this connection type if you are connected to the Internet via a DSL Line� Please refer to PPPoE on page 33 for details� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 9...
  • Page 10 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Set up the Network Camera through Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, which allows it to be powered via a single Ethernet cable� If your switch/router supports PoE, refer to the following illustration to connect the Network Camera to a PoE-enabled switch/router via an Ethernet cable�...

  • Page 11: Software Installation

    After your network environment is analyzed, please click Next to continue the program� 3� The program will search all VIVOTEK devices in the same LAN� 4� After searching, the main installer window will pop up� Click on the MAC and model name which match the product label on your device to connect to the Network Camera via the Internet Explorer�...

  • Page 12: Accessing The Network Camera 12

    3� The live video will be displayed in your web browser� 4. If it is the first time for you to install VIVOTEK’s network camera, some information bar will pop up as below� Follow the instruction to install required plug-in on your computer�...
  • Page 13 ► If you see a dialog box indicating that your security settings prohibit running ActiveX Controls, please enable your ActiveX 1� Choose Tools > Internet Options > Security > Custom Level� 2. Look for Download signed ActiveX VIVOTEK - A Leading Provider of Multimedia Communication Solutions ® Controls for your browser� ®...

  • Page 14: Using Rtsp Players

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using RTSP players To view the MPEG-4 streaming media using RTSP players, you can use one of the following players that support RTSP streaming� Quick Time Player Real Player VLC media player 1�...

  • Page 15: Using 3Gpp-Compatible Mobile Devices

    5� Type the URL commands in the player� The format is rtsp://<public ip address of your camera>:<rtsp port>/<RTSP streaming access name for stream1 or stream2>� For example: VIVOTEK - A Leading Provider of Multimedia Communication Solutions MPEG-4 176 x 144 5 fps 40kbps 12.2kbps...

  • Page 16: Using Vivotek Recording Software

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using VIVOTEK recording software The product software CD also contains recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras� Please install the recording software; then launch the program to add the Network Camera to the Channel list� For detailed information about how to use the recording software, please refer to the user’s manual of the software or...

  • Page 17: Main Page 17

    Main Page This chapter explains the layout of the main page� It is composed of the following sections: Logo of VIVOTEK INC�, Host name, Camera control panel, Menu, and Live video window� Logo of VIVOTEK INC. Camera control area PTZ control panel Configuration area Logo of VIVOTEK INC.
  • Page 18 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Pan: Click this button to start the auto pan� When the current position is Home or on the left side of Home, the camera starts panning from the current position to the left-most position, then to the right- most position, and finally backward to the original position.
  • Page 19 Go to: Once the Administrator has determined the preset positions; you can aim the camera using this control� For more information, please refer to Camera control of Configuration on page 54� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Mute function is not activated, move the slider bar to adjust the...
  • Page 20 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ The following window is displayed when the video mode is set to MJPEG: Video title Title and time Video title: The video title can be configured� For more information, please refer to Video settings on page 46�...

  • Page 21: Client Settings 21

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Client Settings This chapter explains how to select the stream transmission mode and saving options at local computer� When completed with the settings on this page, click Save on the page bottom to take effect�...
  • Page 22 VIVOTEK - A Leading Provider of Multimedia Communication Solutions MP4 Saving Options Users can record the live video as they are watching it by clicking page. Here, you can specify the storage destination and file name. Folder: Specify a storage destination for the recorded video files.

  • Page 23: Configuration 23

    Click Configuration on the main page will enter the camera setting pages� Note that only Administrators can access the configuration page. VIVOTEK offers an easy-to-use user interface that helps you setup your network camera without much efforts� To simplify the setting procedure, VIVOTEK designs two kinds of user inferface- -advanced mode for professional users and basic mode for entry-level users�...

  • Page 24: System

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode Configuration list Click to switch to Basic mode Firmware Version Each function on the configuration list will be explained in the following sections� Those functions that only show in Advanced mode are marked with Advanced mode �...
  • Page 25 VIVOTEK - A Leading Provider of Multimedia Communication Solutions System Time Keep current date and time: Select this option to reserve the current date and time of the Network Camera� The Network Camera’s internal real-time clock maintains the date and time even when the power of the system is turned off�...

  • Page 26: Security

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Security This section explains how to enable password protection and create multiple accounts� Root Password The administrator account name is “root”, which is permanent and can not be deleted� If you want to add more accounts in Manage User column, please apply a password for the “root”...

  • Page 27: Https

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTPS Advanced mode This section explains how to enable authentication and encrypted communication over SSL� It helps protect streaming data transmission over the Internet� Enable HTTPS Check this item to enable HTTPS communication, and then select a connection option: "HTTP & HTTPS"...
  • Page 28 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 4� The Certificate Information will automatically show up in the third column as below� You can click Property to see the detailed information of the certificate. 5� Click Home to return to the main page� Change the address from “http://” to “https://“ on the Address bar and press Enter on your keyboard�...
  • Page 29 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Create self-signed certificate manually 1� Select this option� 2� Click Create to open a Create Certificate page, and then click Save to generate the certificate. 3� The Certificate Information will automatically show up in the third column as below� You can click Property to see the detailed information of the certificate.
  • Page 30 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 3� If you see the following Information Bar, click OK and the menu bar on the top of the page to allow the Pop-ups� 4. The Pop-up window shows an example of a certificate request.
  • Page 31 ► If you want to create and install other certificate, please remove the existing one. To remove the signed certificated, uncheck the Enable HTTPS secure connection in the first column and click Save� Then click Remove to erase the certificate. VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 31...

  • Page 32: Network

    Use fixed IP address: Select this option to manually assign a static IP address to the Network Camera� 1� You can make use of VIVOTEK installation wizard 2 (IW2) on the software CD to easily set up the Network Camera in LAN� Please refer to Software installation on page 11 for details�...
  • Page 33 Note that you must log on to the computer as a system administrator to install the UPnP components� 1� Go to Start, click Control Panel, and then click Add or Remove Programs� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 33...
  • Page 34 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 2� In the Add or Remove Programs dialog box, click Add/Remove Windows Components� 3� In the Windows Components Wizard dialog box, select Networking Services and then click Details� 4� In the Networking Services dialog box, select Universal Plug and Play and then click OK�...
  • Page 35 Network Camera� For example, when the HTTP port is set to 80 and the secondary HTTP port is set to 8080, refer to the list below for the Network Camera’s IP address� VIVOTEK - A Leading Provider of Multimedia Communication Solutions In LAN http://192.168.4.160 or...
  • Page 36 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Access name for stream 1 / Access name for stream 2: The access name is used to differentiate the streaming source� When using Mozilla Firefox or Netscape to access the Network Camera, and the video mode is set to JPEG, users will receive continuous JPEG pictures�...
  • Page 37 FTP server allows the user to save recorded video clips� And you can utilize VIVOTEK Installation Wizard 2 to upgrade firmware via FTP server. By default, the FTP port is set to 21. It also can be assigned with another port number between 1025 and 65535�...

  • Page 38: Rtsp Streaming

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions RTSP Streaming To utilize the RTSP streaming authentication, make sure that your have set a password for the Network Camera first; please refer to Security on page 26 for details� Authentication: Depending on your network security requirements, the Network Camera provides three types of security settings for streaming via RTSP protocol: disable, basic and digest�...
  • Page 39 If the multicast RTP video ports are incorrectly assigned, the following warning message will display: Multicast TTL [1~255]: The multicast TTL (Time to live) is the value that tells the router the range a packet can be forwarded� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 39...

  • Page 40: Wireless Lan (Pz7112/Pz7122 Only)

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Wireless LAN (PZ7112/PZ7122 only) SSID (Service Set Identifier): It is a name that identifies a wireless network. Access Points and wireless clients attempting to connect to a specific WLAN (Wireless Local Area Network) must use the same SSID�...
  • Page 41 128 bites key length: 26 Hex digits or 13 characters� NOTE ► When 22(“), 3C(<) or 3E(>) are input in network key, the key format can’t be changed to ASCII format� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 41...
  • Page 42 ► After wireless configurations are completed, click Save and the camera will reboot� Wait for the live image is reloaded to your browser� For VIVOTEK 7000-series cameras, you have to unplug the power cable and Ethernet cable from the camera; then re-plug the power cable to the camera� The camera will switch to wireless mode�...

  • Page 43: Ddns

    Enable DDNS: Select this option to enable the DDNS setting� Provider: Select a DDNS provider from the Provider drop-down list� VIVOTEK offers Safe100.net, a free dynamic domain name service to VIVOTEK customers� It is recommended that you register Additionally, we offer other DDNS providers, such as Dyndns�org(Dynamic), Dyndns�org(Custom), TZO�...
  • Page 44 4� Select Enable DDNS and then click Save to take effect� ■ CustomSafe100 VIVOTEK offers documents to establish CustomSafe100 DDNS server for distributors and system integrators� You can use CustomSafe100 to register a dynamic domain name if your distributor or system integrators offer such services�...

  • Page 45: Access List

    Delete allowed list / Delete denied list 1� In the Delete allowed list or Delete denied list, select a list from the drop-down list� 2� Click Delete to take effect� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Denied Alowed...

  • Page 46: Audio And Video

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Audio and video This section explains how to cofigure audio and video performances of the Network Camera. It is composed of the following two columns: Video settings and Audio settings� Video Settings Video title: Enter a name that will be displayed on the title bar of the live video�...
  • Page 47 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode Image Settings Click Image Settings to open the page� In this page, you can tune Brightness, Saturation, Contrast, and Sharpness for video compensation� Image Adjustment ■ Brightness: Adjust the image brightness level, which ranges from -5 to +5. The default value is set to 0.
  • Page 48 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode CCD Adjustment Click CCD settings to open the CCD Adjustment page� In this page, you can set the Auto electronic shutter (AES), Auto tracking white balance, White balance control, Low lux mode, and BLC settings�...
  • Page 49 NTSC 704 x 480 352 x 240 QCIF 176 x 120 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode 704 x 576 352 x 288 176 x 144 User's Manual - 49...
  • Page 50 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Maximum frame rate This limits the maximal refresh frame rate per second� Set the frame rate higher for a smoother video quality� The frame rates are selectable at the following rates: 1fps, 2fps, 3fps, 5fps, 8fps, 10fps, 15fps, 20fps and 25fps, and 30fps�...

  • Page 51: Audio Settings

    ► The Network Camera offers two inputs to capture audio - internal microphone or external microphone. The internal/external microphone switch is located on the back panel of the Network Camera� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 51...

  • Page 52: Motion Detection

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Motion detection This section explains how to configure the Network Camera to enable motion detection. A total of three motion detection windows can be configured. Video(TCP-AV) Follow the steps below to enable motion detection: 1�...
  • Page 53 30%, the motions are judged to exceed the defined threshold; therefore, the motion window will be outlined in red� For applications that require higher security management, it is suggested to set higher sensitivity settings and smaller percentage values� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Percentage = 30% User's Manual - 53...

  • Page 54: Camera Control

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Camera control This section explains how to control the Network Camera’s Pan/Tilt/Zoom/Focus operation by a control panel and set prset positions� Preset Position In this page, you can set preset positions for the Network Camera� You can also select some preset positions for it to partol.

  • Page 55: Patrol Settings

    5� Click the selected locations and then click Up or Down to arrange the order for patrolling� 6� Adjust the Auto pan/patrol speed. 7� Click Save to enable the settings� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 55...
  • Page 56 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Dwelling time (sec) Set the stop time of each preset location during auto patrol of the network camera� ■ The preset positions will also show on the camera control panel on the Home page as below�...
  • Page 57 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Homepage layout Advanced mode This section explains how to set up your own customized homepage layout� Preview This column shows the settings of your hompage layout� You can manually setup the background and font colors in Theme Options, the third column on this page�...
  • Page 58 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Theme options Here you can change the color of your homepage layout� There are three kinds of preset patterns for you to choose� The new layout will simultaneously present in the Preview column� Click Save to enable the settings�...
  • Page 59 4� Drag the slider bar and click on the left square to select a desired color� 5� The selected color will show up in the corresponding blank and in the Preview column� 6� Click Save to enable the settings� VIVOTEK - A Leading Provider of Multimedia Communication Solutions color picker User's Manual - 59...

  • Page 60: Application

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Application Advanced mode This section explains how to configure the Network Camera to react in response to particular situations (event)� A typical application is that when a motion is detected, the Network Camera sends buffered images to a FTP server or e-mail address as notifications.
  • Page 61 Motion detection on page 52 for details� ■ Periodically This option allows the Network Camera to trigger periodically for every other defined minute. At most 999 minutes can be set� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 61...
  • Page 62 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Digital input This option allows the Network Camera to use external digital input device or sensor as a trigger source� Depending on your applications, there are many choices of digital input devices on the market which helps to sense any changes in temperature, vibration, sound and light, etc�...
  • Page 63 65� Click Add Media to configure page 68� Here is an example of Event Settings page: VIVOTEK - A Leading Provider of Multimedia Communication Solutions Server Settings� For more information, please refer to Server Settings Media Settings� For more information, please refer to Media Settings on...
  • Page 64 VIVOTEK - A Leading Provider of Multimedia Communication Solutions When completed, click Save to take effect and then click Close to quit Event Settings page� The new event settings / server settings / media settings will appear in the event drop-down list on the Application page�...

  • Page 65: Server Settings

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Server Settings In the Server column, click Add Server on Event Settings page to open the server setting page� In this page, you can specify where the notification messages will be send when a trigger is activated. A total of 5 server settings can be configured.
  • Page 66 VIVOTEK - A Leading Provider of Multimedia Communication Solutions FTP: Select to send the media files to a FTP server when a trigger is activated. ■ Server address: Enter the domain name or IP address of the FTP server. ■ Server port By default, the FTP port server is set to 21�...
  • Page 67 VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP: Select to send the media files to a HTTP server when a trigger is activated� ■ URL: Enter the URL of the HTTP server. ■ User name: Enter the user name if necessary.

  • Page 68: Media Settings

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Media Settings In Media Settings column, click Add Media on Event Settings page to open the media settings page� In this page, you can specify what kind of media to send when a trigger is activated� A total of 5 media settings can be configured.
  • Page 69 When completed, click Save to take effect and then click Close to quit this page� The new media settings will show up on the Event Settings page as below� Select a server and media type for the event� VIVOTEK - A Leading Provider of Multimedia Communication Solutions 1 sec.

  • Page 70: Recording

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Recording Advanced mode This section explains how to configure the recording settings for the Network Camera. Recording Settings NOTE Before setting up this page, please set up the Network Storage first.
  • Page 71 VIVOTEK - A Leading Provider of Multimedia Communication Solutions If it works, you will also receive a test.txt file on the network storage server. 3� Enter a descriptive server name� 4� Click Save to finish the setting and click Close to quit the page�...
  • Page 72 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Source: Select the recording source (stream 1 or stream 2)� Recording Schedule: Specify the recording duration� ■ Select the days on weekly basis. ■ Select the time for recording in 24-hr time format.

  • Page 73: System Log

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions System log Advanced mode This section explains how to configure the Network Camera to send system log to the remote server as a backup� Remote Log You can configure the Network Camera to send the system log file to a remote server as a log backup.

  • Page 74: View Parameters

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions View parameters Advanced mode The View parameters page lists the entire system’s parameters in alphabetical order� If you need technical assistance, please provide the information listed in this page� 74 - User's Manual...

  • Page 75: Maintenance

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Maintenance This chapter explains how to restore the Network Camera to factory default, upgrade firmware version, etc� Reboot This feature allows you to reboot the Network Camera, which takes about one minute to complete� When completed, the live video page will be displayed in your browser�...
  • Page 76 Note that do not power off the Network Camera during the upgrade� Follow the steps below to upgrade firmware: 1. Download a new firmware file from VIVOTEK website. The file is in pkg file format. 2� Click Browse… and specify the firmware file.
  • Page 77 3. Open the file with Microsoft Notepad and locate your time zone; set the starting time and ending time of the DST. When completed, save the file. VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 77...
  • Page 78 Network Camera. The following message is displayed when attempting to upload an incorrect file format. Export language file: Click to export language strings� VIVOTEK provides nine languages: English, Deutsch, Español, Français, Italiano, 日本語, Português, 簡体中文, and 繁體中文 �...

  • Page 79: Url Commands Of The Network Camera

    URL syntax examples are written with "Example:" in bold face followed by a short description and a light grey box with the example� Example: request a single snapshot image http://mywebserver/cgi-bin/viewer/video�jpg VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 79...

  • Page 80: General Cgi Url Syntax And Parameters

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions General CGI URL syntax and parameters CGI parameters are written in lower-case and as one word without any underscores or other separators. When the CGI request includes internal camera parameters, the internal parameters must be written exactly as they are named in the camera or video server.
  • Page 81 VIVOTEK - A Leading Provider of Multimedia Communication Solutions [&<parameter>…] http://<servername>/cgi-bin/operator/getparam.cgi?[<parameter>] [&<parameter>…] http://<servername>/cgi-bin/admin/getparam.cgi?[<parameter>] [&<parameter>…] where the <parameter> should be <group>[_<name>] or <group>[.<name>] If you do not specify the any parameters, all the parameters on the server will be returned. If you specify only <group>, the parameters of related group will be returned.

  • Page 82: Set Server Parameter Values

    (note: The return page can be a general HTML file(.htm, .html) or a Vivotek server script executable (.vspx) file. It can not be a CGI command. It can not have any extra parameters. This...

  • Page 83: Available Parameters On The Server

    <value1>, Enumeration. Only given values are valid. <value2>, <value3>, … blank A blank string everything inside <> As description VIVOTEK - A Leading Provider of Multimedia Communication Solutions – 1) and (2 – 1) – 1) User's Manual - 83...
  • Page 84 VIVOTEK - A Leading Provider of Multimedia Communication Solutions NOTE: The camera should prevent to restart when parameter changed. Group: system NAME VALUE hostname string[40] ledoff <boolean> date <yyyy/mm/dd>, keep, auto time <hh:mm:ss>, keep, auto datetime <MMDDhhmmYYYY.ss> <domain name>, <ip address>, <blank>...
  • Page 85 VIVOTEK - A Leading Provider of Multimedia Communication Solutions York, Toronto -201: GMT-05:00 Bogota, Lima, Quito, Indiana -160: GMT-04:00 Atlantic Time, Canada, Caracas ,La Paz, Santiago -140: GMT-03:30 Newfoundland -120: GMT-03:00 Brasilia, Buenos Aires, Georgetown, Greenland -80: GMT-02:00 Mid-Atlantic -40: GMT-01:00 Azores, Cape_Verde_IS.
  • Page 86 VIVOTEK - A Leading Provider of Multimedia Communication Solutions daylight_enable <boolean> daylight_dstactualmode <boolean> daylight_auto_begintime string[19] daylight_auto_endtime string[19] 86 - User's Manual New Delhi 230: GMT 05:45 Kathmandu 240: GMT 06:00 Almaty, Novosibirsk, Astana, Dhaka, Sri Jayawardenepura 260: GMT 06:30 Rangoon...
  • Page 87 <Any value> restoreexceptdst <Any value> restoreexceptlang <Any Value> VIVOTEK - A Leading Provider of Multimedia Communication Solutions 0 to Disable automatic time adjustment, otherwise, it means the seconds between NTP automatic update interval. Restore the system parameters to default value after <value> seconds.
  • Page 88 VIVOTEK - A Leading Provider of Multimedia Communication Solutions SubGroup of system: info (The fields in this group are unchangeable.) NAME VALUE modelname string[40] serialnumber <mac address> firmwareversion string[40] language_defaultcount <integer> language_i<0~(count-1)> string[16] customlanguage_maxcount <integer> customlanguage_count <integer> customlanguage_ci<0~(ma string xcount-1)>...
  • Page 89 <ip address> dns1 <ip address> dns2 <ip address> wins1 <ip address> wins2 <ip address> VIVOTEK - A Leading Provider of Multimedia Communication Solutions SECURITY DESCRIPTION (get/set) indicate whether open circuit or closed circuit represents inactive status SECURITY DESCRIPTION (get/set) DO privilege of viewer DO privilege of operator User’s name of root...
  • Page 90 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Subgroup of network: ftp NAME VALUE port 21, 1025~65535 Subgroup of network: http NAME VALUE port 80, 1025 ~ 65535 alternateport 1025~65535 authmode basic, digest s0_accessname string[32] s1_accessname string[32] Subgroup of network: https...
  • Page 91 Infra, Adhoc channel 1~11 1 ~ 13 or 10~11 or 10~13 or VIVOTEK - A Leading Provider of Multimedia Communication Solutions SECURITY DESCRIPTION (get/set) Enable always multicast Multicast IP address Multicast video port Multicast audio port Mutlicast time to live value...
  • Page 92 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 1~14 txrate NONE, 1M, 2M, 5.5M, 11M, 6M, 9M, 12M, 18M, 24M, 36M, 48M, 54M, Auto encrypt authmode OPEN, SHARED keylength 64, 128 keyformat HEX, ASCII keyselect 1 ~ 4 key1...
  • Page 93 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Allowed ending IP address for RTSP connection Denied starting IP address for RTSP connection Denied ending IP address for RTSP connection VALUE SECURITY (get/set)
  • Page 94 VIVOTEK - A Leading Provider of Multimedia Communication Solutions mirror text imprinttimestamp s<0~(m-1)>_codectype s<0~(m-1)>_resolution s<0~(m-1)>_mpeg4_intraperiod s<0~(m-1)>_mpeg4_ratecontrol mode s<0~(m-1)>_mpeg4_quant s<0~(m-1)>_mpeg4_bitrate s<0~(m-1)>_mpeg4_maxframe s<0~(m-1)>_mjpeg_quant s<0~(m-1)>_mjpeg_maxframe 94 - User's Manual <boolean> string[16] <boolean> mpeg4, mjpeg QCIF, (176x120,ntsc) (176x144,pal) CIF, (352x240,ntsc) (352x288,pal) 4CIF, (704x480,ntsc) (704x576,pal)
  • Page 95 -5 ~ 5 saturation -5 ~ 5 contrast -5 ~ 5 sharpness -3 ~ 3 VIVOTEK - A Leading Provider of Multimedia Communication Solutions SECURITY DESCRIPTION (get/set) linein => use line input linein2 => use external microphone input Enable audio mute...
  • Page 96 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: motion_c<0~(n-1)> for n channel product NAME VALUE enable < oolean> win_i<0~2>_enable < oolean> win_i <0~2>_name string[14] win_i <0~2>_left 0 ~ 320 win_i <0~2>_top 0 ~ 240 win_i <0~2>_width 0 ~ 320 win_i<0~2>_height...
  • Page 97 -5 ~ 5 dwelling 0 ~ 9999 axisx -6790 ~ 6790 axisy -786 ~ 1572 VIVOTEK - A Leading Provider of Multimedia Communication Solutions SECURITY DESCRIPTION (get/set) Enable or disable the UPNP port forwarding service. The status of UpnP port forwarding, used internally.
  • Page 98 VIVOTEK - A Leading Provider of Multimedia Communication Solutions axisz 4096 ~ 8859 defaulthome returnhome returnhomeinterval 0 ~ 9999 osdzoom preset_i<0~19>_name string[40] preset_i<0~19>_pan -6790 ~ 6790 preset_i<0~19>_tilt -786 ~ 1572 preset_i<0~19>_zoom 4096 ~ 8859 patrol_i<0~39>_name string[40] Group: privacymask_c<0~(n-1)> for n channel product...
  • Page 99 < boolean > protocol_rtsp < boolean > protocol_sip <boolean> VIVOTEK - A Leading Provider of Multimedia Communication Solutions number of audio output number of video input number of media stream per channel number of video settings per channel number of audio settings per channel...
  • Page 100 VIVOTEK - A Leading Provider of Multimedia Communication Solutions protocol_maxconnection <positive integer> protocol_rtp_multicast_ <boolean> scalable protocol_rtp_multicast_ <boolean> backchannel protocol_rtp_tcp <boolean> protocol_rtp_http <boolean> protocol_spush_mjpeg <boolean> protocol_snmp <boolean> videoin_type 0, 1, 2 videoin_resolution <a list of the available resolution separates by comma) videoin_codec <a list of the...
  • Page 101 0, 1 priority 0, 1, 2 delay 1~999 VIVOTEK - A Leading Provider of Multimedia Communication Solutions available codec list Indicate whether to support the http tunnel for uart transfer Indicate what kind of transmission mode the machine used. TX: server, Rx: receiver box, Both: DVR?.
  • Page 102 VIVOTEK - A Leading Provider of Multimedia Communication Solutions trigger boot, motion, seq, <integer> mdwin <integer> inter 1~999 weekday <interger> begintime hh:mm endtime hh:mm action_do_i<0~(ndo-1) 0, 1 >_enable action_do_i<0~(ndo-1) 1~999 >_duration action_goto_enable 102 - User's Manual Indicate the trigger condition.
  • Page 103 VIVOTEK - A Leading Provider of Multimedia Communication Solutions The selected name of preset positions To enable or disable this server action. The default value is 0. The index of attached media. SECURITY DESCRIPTION...
  • Page 104 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: media_i<0~4>(media_freespace is used internally.) PARAMETER VALUE name string[40] type snapshot, systemlog videoclip snapshot_source <integer> snapshot_prefix string[16] snapshot_datesuffix 0, 1 snapshot_preevent 0 ~ 7 snapshot_postevent 0 ~ 7 videoclip_source <integer> videoclip_prefix...
  • Page 105 -2 ~ 1 countryname string[2] stateorprovincename string[128] VIVOTEK - A Leading Provider of Multimedia Communication Solutions Indicate which weekday is scheduled. One bit represents one weekday. The bit0 (LSB) indicates Saturday. The bit1 indicates Friday. The bit2 indicates Thursday.

  • Page 106: Drive The Digital Output

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions localityname string[128] organizationname string[64] unit string[32] commonname string[64] validdays 0 ~ 9999 Group: layout NAME logo_default logo_link theme_option theme_color_font theme_color_configfont theme_color_titlefont theme_color_controlbackground theme_color_configbackground theme_color_videobackground theme_color_case Drive the digital output Note: This request requires the privilege of viewer.

  • Page 107: Query Status Of The Digital Input

    HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: 7\r\n \r\n di1=1\r\n VIVOTEK - A Leading Provider of Multimedia Communication Solutions path according the the current path. If you omit this parameter, it will redirect to an empty page. User's Manual - 107...

  • Page 108: Query Status Of The Digital Output

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Query status of the digital output Note: This request requires the privilege of viewer. Method: GET/POST Syntax: http://<servername>/cgi-bin/dido/getdo.cgi?[do0][&do1][&do2][&do3] If no parameter is specified, all the status of digital output will be returned.

  • Page 109: Account Management

    [&privilege=<value>][…][&return=<return page>] PARAMETER VALUE method Delete edit VIVOTEK - A Leading Provider of Multimedia Communication Solutions DESCRIPTION the channel number of video source The resolution of image The quality of image DESCRIPTION Add an account to server. When using this method, “username”...

  • Page 110: System Logs

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions username <name> userpass <value> privilege <value> viewer operator admin return <return page> System logs Note: This request require administrator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/syslog.cgi Server will return the up-to-date system log.
  • Page 111 VIVOTEK - A Leading Provider of Multimedia Communication Solutions DESCRIPTION Channel of video source Camera ID Move to camera to home position Move camera up Move camera down Move camera left Move camera right...
  • Page 112 VIVOTEK - A Leading Provider of Multimedia Communication Solutions tele <integer , excluding 0> <integer> 0 ~ 7 focus auto near iris auto open close sethome define default calibrate return <return page> Recall Note: This request requires privilege of viewer...

  • Page 113: System Information

    00 ~ 99 ex: 0100 Preset Locations Note: This request requires operator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/operator/preset.cgi?[channel=<value>] [&addpos=<value>][&delpos=<value>][&return=<return page>] VIVOTEK - A Leading Provider of Multimedia Communication Solutions DESCRIPTION Model name of server. Ex:IP3133-VVTK-0100a The capability field version User's Manual - 113...
  • Page 114 VIVOTEK - A Leading Provider of Multimedia Communication Solutions PARAMETER VALUE addpos <Text string less than 40 characters> channel <0~(n-1)> delpos <Text string less than 40 characters> return <return page> IP filtering Note: This request requires administrator access privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/ipfilter.cgi?
  • Page 115 For rtsp (mp4), user needs to input the url below for a rtsp compatible player. rtsp://<servername>/<network_rtsp_s<0~m-1>_accessname> “m” is the stream number. For detailed streaming protocol, please refer to “control signaling” and “data format” documents. VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 115...

  • Page 116: Technical Specifications

    。 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 。 。 。 Technical Specifications Pan:300 ° Specifications Models ．PZ7111 NTSC CCD (PoE) ．PZ7121 PAL CCD (PoE) ．PZ7112 NTSC CCD (WLAN) ．PZ7122 PAL CCD (WLAN) System ．CPU: Bach SoC ．Flash: 8MB ．RAM: 64MB...

  • Page 117: Technology License Notice

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Technology License Notice MPEG-4 AAC Technology THIS PRODUCT IS LICENSED UNDER THE MPEG-4 AAC AUDIO PATENT LICENSE� THIS PRODUCT MAY NOT BE DECOMPILED, REVERSE-ENGINEERED OR COPIED, EXCEPT REGARD TO PC SOFTWARE, YOU MAY MAKE SINGLE COPIES FOR ARCHIVAL PURPOSES�...

  • Page 118: Electromagnetic Compatibility (Emc)

    EN55022/1998, and the requirement for immunity according to EN50082-1/1992� Liability VIVOTEK Inc� cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the product and manuals without prior notice� VIVOTEK Inc� makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and fitness for any particular purpose�...
