Indoor/2.6x Zoom/Dual Streams
Quick Installation Guide
Türkçe
English
Français
Español
Deutsch
Português
Italiano
Polski
Русский
Česky
Svenska
PZ7131/PZ7132
This guide describes the basic functions of PZ7131/PZ7132
All detailed information is described in the user's manual.
IP Sur veillance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PZ7131 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivotek PZ7131

Summary of Contents for Vivotek PZ7131

  • Page 1 All manuals and user guides at all-guides.com Indoor/2.6x Zoom/Dual Streams Quick Installation Guide Türkçe English Français Español Deutsch Português Italiano Polski Русский Česky Svenska PZ7131/PZ7132 This guide describes the basic functions of PZ7131/PZ7132 All detailed information is described in the user's manual. IP Sur veillance...

  • Page 2: Warning Before Install

    All manuals and user guides at all-guides.com Warning Before Install Power off the Network Camera Keep the Network Camera away as soon as it is found smoking or from water. If the Network Camera smelt unusual. is wet, power off immediately. Contact your distributor when such Contact your distributor when such cases happen.
  • Page 3 All manuals and user guides at all-guides.com Do not place the Network Camera Do not touch the Network Camera on unsteady surfaces. when it's lightening. Do not disassemble the Network Do not drop the Network Camera. Camera. Do not insert any object into the Do not manually pan and tilt the Network Camera, such as needles.

  • Page 4: Package Contents

    All manuals and user guides at all-guides.com Package Contents Power adapter PZ7131 / PZ7132 Screws Antenna (PZ7132 only) Software CD Quick installation guide Ceiling mount brackets Warranty card EN - 3...

  • Page 5: Physical Description

    All manuals and user guides at all-guides.com Physical Description Front panel Lens Built-in microphone Status LED Back panel Antenna (PZ7132 only) Microphone in Ethernet 10/100 Audio out RJ45 socket Power cord socket Indented reset button Mic. In Audio Ext. Int. 12VDC Ethernet Ext.

  • Page 6: Hardware Installation

    All manuals and user guides at all-guides.com Hardware Installation Mounting the Network Camera 1. Attach ceiling mount bracket A to the Network Camera and secure it with two small screws. 2. Drill three pilot holes into the ceiling; hammer the plastic anchors into the holes. 3.

  • Page 7: Network Deployment

    All manuals and user guides at all-guides.com Network Deployment General Connection (without PoE) 1. If you have external devices such as sensors and alarms, make connection from general I/O terminal block. 2. Connect the camera to a switch via Ethernet cable. 3.
  • Page 8 All manuals and user guides at all-guides.com Power over Ethernet (PoE) (PZ7131 only) When using a PoE-enabled switch The Network Camera is PoE-compliant, allowing transmission of power and data via single Ethernet cable. See the following illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable.

  • Page 9: Assigning Ip Address

    "Next" button to continue the program. Installation Wizard 2 3. The program will search the VIVOTEK Video Receivers, Video Servers or Network Cameras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect the Internet Explorer to the Network Camera.

  • Page 10: Ready To Use

    All manuals and user guides at all-guides.com Ready to Use 1. Access to the Network Camera from the Internet. 2. Retrieve live video through web browsers or recording software. For further setup, please refer to user's manual on the software CD. EN - 9...
  • Page 11 All manuals and user guides at all-guides.com Configure the Wireless Connection (PZ7132 only) 1. Check the SSID currently set on your wireless access point (AP). 2. Go to PZ7132's Configuration > Advanced mode > Wireless. 3. Type in the SSID consistent with the setting on your AP. 4.
  • Page 12 All manuals and user guides at all-guides.com P/N:625007900G...

This manual is also suitable for:

Pz7132

Table of Contents
