Summary of Contents for Synergy Global Technology LCD2U17-3K-02
- Page 1 Toll Free: 1-888-865-6888 Tel: 510-226-8368 Fax: 510-226-8968 Email: sales@RackmountMart.com...
- Page 2 1920 x 1080 native resolution / DVI-D + VGA video input 1920 x 1080 & 1920 x 1200 resolution support Triple display console drawer Triple display console drawer LCD2U17-3K-02 LCD2U17-3H-02 Dual display console drawer Dual display console drawer ( Left Hinged )
- Page 3 Legal Information First English printing, January 2018 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
Contents < Part. 1 > Package Content P.1 - 3 Structure Diagram & Dimension P.4 - 7 Installation P.8 - 9 Connection Specifi cations / OSD < Part. 2 > Product Specifi cations P.10 - 13 Keyboard / Mouse Specifi cations P.14 - 16 On-screen Display Operation ( OSD ) P.17 - 20... - Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: < 1.1 > Package Content
< Part 1 > < 1.1 > Package Content LCD2U17-3K-02 unit X 1 LCD2U17-3H-02 or 3T-02 unit X 1 - 6ft DP cable X 2 or 3 (base on no. of displays) - 6ft DVI cable X 2 or 3 (base on no. of displays) - Page 7 < 1.2 > LCD2U17-3K-02 / LCD2U17-3H-02 Dimension 1mm = 0.03937 inch Front View Triple display Dual display ( Left Hinged ) Dual display ( Right Hinged ) Rear View LCD2U17-3K-02 LCD2U17-3H-02 KB / MS Central Central Power Power Central KB / MS...
- Page 8 < 1.2 > LCD2U19-3T-02 Dimension 1mm = 0.03937 inch Front View Triple display Dual display ( Left Hinged ) Dual display ( Right Hinged ) Rear View Central Central Power KB / MS Left Left DVI-D Right Right Side View Top View Product Dimension Model...
-
Page 9: Installation
< 1.3 > Installation - How to install Installation Slides Step ■ The left and right rear mounting brackets are attached to the Multi-display console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. ■... - Page 10 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Unlock the key cylinder to 3 o’clock direction. Step ■ Hold the handle and slide out the drawer. Step Step ■ Flip up the LCD to a suitable angle. Step ■...
- Page 11 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Operate the multi-display drawer. Step ■ Close the Left Right display. ■ Flip down the LCD completely. Step Step ■ Must completely extend the drawer before returning it to the park position. ■...
- Page 12 < 1.3 > Installation - How to Use the Slides Figure 1. ■ A purple release button is located on the front of the slide. ( shown in Figure 1 ). ■ Pull and hold both side release buttons when Figure 2.
- Page 13 < 1.4 > 4K 17" model connection to Display Port Server LCD2U17-3K Multi-display Console Drawer KB / MS Power Central Left Right USB type B Display Port cable USB (B) to (A) x 2 or 3 cable x 1 USB type A DP server * DP cable x 2 and USB (B) to (A) cable x 1 for dual display The LCD console drawer is hot-pluggable, but components of connected devices, such...
- Page 14 < 1.4 > 17" HD / 19" model connection to USB Server LCD2U17-3H Mult-display Console Drawer LCD2U19-3T Central Central Power KB / MS Left Left DVI-D Right Right DVI cable USB KB cable x 1 x 2 or 3 USB server * DVI cable x 2 and USB KB cable x 1 for dual display The LCD console drawer is hot-pluggable, but components of connected devices, such Caution :...
- Page 15 < Part 2 > < 2.1 > Product Specifi cations - LCD2U17-2K / 3K LCD2U17-2K-02 / LCD2U17-3K-02 Panel Native Resolution 3840 x 2160 Panel Size ( diagonal ) 17.3-inch TFT color LCD Brightness ( cd/m² ) Contrast Ratio ( typ. )
- Page 16 < 2.1 > Product Specifi cations - LCD2U17-2K / 3K Product ( W x D x H ) 441.6 x 550 x 88 Physical Specifi cation inch 17.4 x 21.7 x 3.5 Triple display 25.7 kg / 56.5 lb Dual display 21 kg / 46.2 lb Weight Display Port Input...
- Page 17 < Part 2 > < 2.1 > Product Specifi cations - LCD2U17-2H / 3H & LCD2U19-2T / 3T 17" 19" Panel Native Resolution 1920 x 1080 1280 x 1024 Panel Size ( diagonal ) 17.3" 19" Brightness ( cd/m² ) Contrast Ratio ( typ.
- Page 18 < 2.1 > Product Specifi cations - LCD2U17-2H / 3H & LCD2U19-2T / 3T Product 17" 441.6 x 550 x 88 Physical Specifi cation ( W x D x H ) inch 17.4 x 21.7 x 3.5 19" 441.6 x 600 x 88 17.4 x 23.6 x 7.8 inch 17"...
-
Page 19: Keyboard / Mouse Specifi Cations
< 2.2 > Standard Keyboard / Mouse Specifi cations keyboard integrated with touchpad keyboard integrated with trackball 55 ± 5g Key force 3 ± 0.3mm Travelling distance > 10 million life cycle time Switch life Windows / Linux / Unix / Mac OS OS support Supporting layouts America... - Page 20 < 2.2 > MAC Keyboard / Mouse Options MAC keyboard integrated with touchpad MAC keyboard integrated with trackball Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts.
- Page 21 < 2.2 > SUN Keyboard / Mouse Options SUN keyboard integrated with touchpad SUN keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose SUN keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
-
Page 22: On-Screen Display Operation ( Osd )
< 2.3 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... - Page 23 < 2.3 > On-screen Display Operation ( OSD ) - LCD2U17-2K / 3K series Picture Brightness : Adjust the screen brightness Contrast : Adjust the difference between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position...
- Page 24 < 2.3 > On-screen Display Operation ( OSD ) - LCD2U17-2K / 3K series Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) / PBP 3WIN ( Main screen + 2 sub screen ) / PBP 4WIN ( Main screen + 3 sub screen ) Select the signal input of each sub screen...
- Page 25 < 2.3 > On-screen Display Operation ( OSD ) - LCD2U17-2H / 3H & 19-2T / 3T OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio:...
-
Page 26: Part. 3 > Options
< Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input Our SDI input is an ideal solution for the broadcast-grade video and high resolution CCTV market. Designed for use with NOVA series displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 1-year warranty. -
Page 27: Hdmi Video Input
< 3.2 > Options : HDMI video input ( HDCP 2.2 ) LCD2U17-3K : HDMI 2.0 ( HDCP 1.3 ) LCD2U17-3H : HDMI 1.3 ( HDCP 1.1 ) LCD2U19-3T : HDMI 1.2 ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen. - Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2018 Synergy Global Technology Inc. All rights reserved. P.23 www.RackmountMart.com...
