- Page 2 3840 x 2160 native resolution / Display port 1.2 video input 1920 x 1080 native resolution / DVI-D + VGA video input 1920 x 1080 & 1920 x 1200 resolution support Triple display drawer Triple display drawer LCD2U17-3K-011 LCD2U17-3H-011 Dual display drawer Dual display drawer ( Left Hinged )
- Page 3 Legal Information First English printing, January 2018 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
Contents < Part. 1 > Package Content P.1 - 3 Structure Diagram & Dimension P.4 - 7 Installation P.8 - 9 Connection Specifi cations / OSD < Part. 2 > Product Specifi cations P.10 - 13 On-screen Display Operation ( OSD ) P.14 - 17 <... - Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: < 1.1 > Package Content
< Part 1 > < 1.1 > Package Content LCD2U17-3K-011 unit X 1 LCD2U17-3H-011 or 3T-011 unit X 1 - 6ft DP cable X 2 or 3 (base on no. of displays) - 6ft DVI cable X 2 or 3 (base on no. of displays) - Power adapter &... - Page 7 < 1.2 > LCD2U17-3K-011 / LCD2U17-3H-011 Dimension 1mm = 0.03937 inch Front View Triple display Dual display ( Left Hinged ) Dual display ( Right Hinged ) Rear View LCD2U17-3K-011 LCD2U17-3H-011 Power DVI-D Power Central Central Left Left Right Right...
- Page 8 < 1.2 > LCD2U19-3T-011 Dimension 1mm = 0.03937 inch Front View Triple display Dual display ( Left Hinged ) Dual display ( Right Hinged ) Rear View DVI-D Power Central Left Right Side View Top View Product Dimension Model Display (W x D x H) Weight 441.6 x 600 x 88 mm...
-
Page 9: Installation
< 1.3 > Installation - How to install Installation Slides Step ■ The left and right rear mounting brackets are attached to the Multi-display drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. ■... - Page 10 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Unlock the key cylinder to 3 o’clock direction. Step ■ Hold the handle and slide out the drawer. Step Step ■ Flip up the LCD to a suitable angle. Step ■...
- Page 11 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Operate the multi-display drawer. Step ■ Close the Left Right display. ■ Flip down the LCD completely. Step Step ■ Must completely extend the drawer before returning it to the park position. ■...
- Page 12 < 1.3 > Installation - How to Use the Slides Figure 1. ■ A purple release button is located on the front of the slide. ( shown in Figure 1 ). ■ Pull and hold both side release buttons when Figure 2.
- Page 13 < 1.4 > 4K 17" model connection to Display Port Server Multi-display Console Drawer Power Central Left Right Display Port cable DP server * DP cable x 2 for dual display The LCD drawer is hot-pluggable, but components of connected devices, such as the Caution : servers and KVM switch, may not be hot-pluggable.
- Page 14 < 1.4 > 17" HD / 19" model connection to USB Server Mult-display Console Drawer DVI-D Power Central Left Right DVI cable USB server * DVI cable x 2 for dual display The LCD drawer is hot-pluggable, but components of connected devices, such as the Caution : servers and KVM switch, may not be hot-pluggable.
- Page 15 < Part 2 > < 2.1 > Product Specifi cations - LCD2U17-2K / 3K Panel Native Resolution 3840 x 2160 Panel Size ( diagonal ) 17.3-inch TFT color LCD Brightness ( cd/m² ) Contrast Ratio ( typ. ) 1000:1 Colors 16.7 M, 8-bit Viewing Angle ( L/R/U/D ) 89/89/89/89...
- Page 16 < 2.1 > Product Specifi cations - LCD2U17-2K / 3K Product ( W x D x H ) 441.6 x 55 0 x 88 Physical Specifi cation inch 17.4 x 21.7 x 3.5 Triple display 24.1 kg / 53 lb Weight Dual display 19.4 kg / 42.7 lb...
- Page 17 < Part 2 > < 2.1 > Product Specifi cations - LCD2U17-2H / 3H & LCD2U19-2T / 3T 17" 19" Panel Native Resolution 1920 x 1080 1280 x 1024 Panel Size ( diagonal ) 17.3" 19" Brightness ( cd/m² ) Contrast Ratio ( typ.
-
Page 18: Product Specifi Cations
< 2.1 > Product Specifi cations - LCD2U17-2H / 3H & LCD2U19-2T / 3T Product 17" 441.6 x 550 x 88 Physical Specifi cation ( W x D x H ) inch 17.4 x 21.7 x 3.5 19" 441.6 x 600 x 88 17.4 x 23.6 x 7.8 inch 17"... -
Page 19: On-Screen Display Operation ( Osd )
< 2.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... - Page 20 < 2.2 > On-screen Display Operation ( OSD ) - LCD2U17-2K / 3K series Picture Brightness : Adjust the screen brightness Contrast : Adjust the difference between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position...
- Page 21 < 2.2 > On-screen Display Operation ( OSD ) - LCD2U17-2K / 3K series Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) / PBP 3WIN ( Main screen + 2 sub screen ) / PBP 4WIN ( Main screen + 3 sub screen ) Select the signal input of each sub screen...
- Page 22 < 2.2 > On-screen Display Operation ( OSD ) - LCD2U17-2H / 3H & 19-2T / 3T OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio:...
-
Page 23: Part. 3 > Options
< Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input Our SDI input is an ideal solution for the broadcast-grade video and high resolution CCTV market. Designed for use with NOVA series displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 1-year warranty. -
Page 24: Hdmi Video Input
< 3.2 > Options : HDMI video input ( HDCP 2.2 ) LCD2U17-3K : HDMI 2.0 ( HDCP 1.3 ) LCD2U17-3H : HDMI 1.3 ( HDCP 1.1 ) LCD2U19-3T : HDMI 1.2 ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen. - Page 25 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2018 Synergy Global Technology Inc. All rights reserved. P.20 www.RackmountMart.com...
