User Manual
PCH3582/3782/3982: 15/17/19" Industrial Fanless Panel PC
with Atom D525 processor
14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
PCH3582/3782/3982
15/17/19 inch Atom Fanless Panel PC
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product
information, please visit Acnodes' web site at www.acnodes.com.
Advertisement
Table of Contents
Related Manuals for Acnodes PCH3782
Summary of Contents for Acnodes PCH3782
- Page 1 Atom D525 processor © Copyright 2013 Acnodes, Inc. All rights reserved. Product description and product specifications 14628 Central Ave, are subject to change without notice. For latest product Chino, CA 91710 information, please visit Acnodes’ web site at www.acnodes.com. tel:909.597.7588, fax:909.597.1939...
- Page 2 Warning!_______________________________ This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
-
Page 3: Packing List
Packing List Accessories (as ticked) included in this package are: □ AC power cable □ Driver & manual CD disc □ Other._ (please specify) Safety Precautions Follow the messages below to avoid your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆... -
Page 4: Table Of Contents
Table of Contents Warning!…………………………………………………………………………….……..….2 Packing List........................3 Safety Precautions......................3 Chapter 1 Getting Started 1.1 Specifications………………………………………….………….……...…..6 1.2 Dimensions…………………………………...……………….…………..8 1.3 Brief Description of PCH3X82……….………………….………………12 Chapter 2 Hardware Installation 2.1 Mainboard Specifications………………………..…………….…………13 2.2 Jumpers Setting and Connectors………………………….……………17 Chapter 3 BIOS Setup 3.1 Operations after POST Screen.............26 3.2 BIOS SETUP UTILITY..............27 3.3 System Overview...............28 3.4 Advanced Settings.............. - Page 5 5.1 Introduction to Touch Screen Controller Board………………………..72 5.2 Windows 2000/XP USB Driver Installation………………….………..….72 Figures Figure 1.1: Dimensions of PCH3582……………..……………………...9 Figure 1.2: Dimensions of PCH3782……………..……...………………..10 Figure 1.3: Dimensions of PCH3982………………………...………………..11 Figure 1.4: Overview of PCH3X82 ……..….………………………...12 Figure 2.1: Mainboard Overview……………………………………..……..…13 Figure 2.2: Mainboard Dimensions……………………………………………13 Figure 2.3: Jumpers and Connectors Location-TOP…………………...……14...
-
Page 6: Getting Started
Chapter 1 Getting Started 1.1 Specifications Model No. PCH3582 PCH3782 PCH3982 Specs System Processor Atom D525 1.8GHz processor FSB 800MHz System Chipset ICH8M Chipset System Memory 1 x 204 Pin SO-DIMM DDR3 800GHz, up to 2GB SDRAM Storage 1 x 2 .5" SATA HDD Space... - Page 7 Mechanical Construction Stainless Steel Housing (APC-3X82) / Steel Housing (APC-3X83) IP Rating Front Panel IP65 / 6 sides IP42 with waterproof kit Mounting VESA 75x75 VESA 75x75 VESA 100x100 Mount Mount Mount Dimensions (WxHxD) 399(W)x324(H)x 432(W)x358(H)x 470(W)x388.6(H)x 67(D) mm 66.8(D)mm 67(D)mm Environmental 0~50 ﾟ...
-
Page 8: Dimensions
1.2 Dimensions Figure 1.1: Dimensions of PCH3582... -
Page 9: Figure 1.2: Dimensions Of Pch3782
Figure 1.2: Dimensions of PCH3782... -
Page 10: Figure 1.3: Dimensions Of Pch3982
Figure 1.3: Dimensions of PCH3982... -
Page 11: Brief Description Of Pch3X82
1.3 Brief Description of PCH3X82 The fanless PCH3X82 is Atom D525 powered panel PC with a rich variety of functions and peripherals . PCH3X82 is designed for easy and simplified integration into various vehicle applications. It comes with a compact flash slot, 2.5-inch hard disk drive, DDR3 memory, audio jack, 2 Ethernet, DC input. -
Page 12: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation 2.1 Mainboard Specifications Figure 2.1: Mainboard Overview Figure 2.2: Mainboard Dimensions... -
Page 13: Figure 2.3: Jumpers And Connectors Location-Top
Jumpers and Connectors Location-TOP Figure 2.3: Jumpers and Connectors Location- Bottom Figure 2.4:... - Page 14 Specifications Board Size 165mm x 115mm CPU Support Atom D525 /1.80GHz (onboard) Atom N455 /1.66GHz (onboard option） Chipset Atom D525 + ICH8M Atom N455 + ICH8M (option） Atom N455 +ICH8M-E (option, Support RAID0/1） Memory 1x SO-DIMM (204pins), up to 2GB DDR3 800MHz FSB Support Graphics Integrated by D525 / N455 GMA 3150...
- Page 15 Front I/O by 2x5-pin header Power on/off switch Reset switch Power LED status HDD LED status Buzzer Software programmable 1 – 255 second by Super I/O Watchdog Timer 1 x COM Port (COM1) External 4 x USB 2.0 Ports (stack) port 2 x RJ45 GbE Ports (10/100/1000Mbps) 1 x DB15 Port or 2x8 Pin Header...
-
Page 16: Jumpers Setting And Connectors
2.2 Jumpers Setting and Connectors 1. JCLR_CMOS: (2.0mm Pitch 1x3 Pin Header)CMOS clear jumper, CMOS clear operation will permanently reset old BIOS settings to factory defaults. JCLR_CMOS CMOS CLOSE 1-2 NORMAL (default) CLOSE 2-3 Clear CMOS Procedures of CMOS clear: 5.4.1.1 Turn off the system and unplug the power cord from the power outlet. - Page 17 Open ATX Power Mode Close Power Auto on (Default) 6. BAT: (1.25mm Pitch 1x2 box Pin Header) 3.0V Li battery is embedded to provide power for CMOS. Signal Pin# Name Pin1 VBAT PIN2 Ground 7. F_PANEL: (2.0mm Pitch 2X5 Pin Header), Front panel connector. Signal Name Pin# Pin#...
- Page 18 8. USB3: (2.0mm Pitch 2x5 Pin Header) ,Front USB connector, it provides two USB ports via a dedicated USB cable, speed up to 480Mb/s. Signal Name Pin# Pin# Signal Name USB_P6_DN USB_P7_DN USB_P6_DP USB_P7_DP Ground Ground Ground Note: Before connection, make sure that pinout of the USB Cable is in accordance with that of the said tables.
- Page 19 GPIO21 GPIO61 GPIO22 GPIO62 GPIO23 GPIO63 Ground COM3: (2.0mm Pitch 1x4 box Pin Header),it provides selectable RS422/RS485 serial signal output. RS422 Type (option) RS485 Type (option) Signal Name Pin# Pin# Signal Name 422RXD- 422RXD+ 422TXD- 485A- 422TXD+ 485A+ Note: Use COM3 RS232/RS485 Function, please setting JCOM Jumpers and BIOS CMOS Setup.
- Page 20 COM2,COM3,COM4,COM5 Signal Name: Signal Pin# Pin# Signal Name Name Ground COM6 Signal Name: Signal Pin# Pin# Signal Name Name Ground JCOM6 Setting: Pin1-2 : 5V (Default) Pin2-3:12V (option) Note: COM3 port is controlled by pins No.7~10 of JCOM. For details, please refer to description of JCOM and COM33 BIOS Setup.
- Page 21 USB2.0 ports, speed up to 480Mb/s. Each USB Type A Receptacle (2 Ports) Current limited value is 1.5A. If the external USB device current exceeds 1.5A, please separate connectors into different Receptacle. 16. LAN1/2: Connector Rear LAN port,2 standard 10/100/1000M RJ-45 Ethernet (RJ45 ports are provided.
- Page 22 19. CPU SCREW HOLES: Four screw holes for fixed CPU Cooler assemble. 20. COM1: (Type DB9), Rear serial port, standard DB9 serial port is provided to make a direct connection to serial devices. COM1 port is controlled by pins No.1~6 of JCOM, select output Signal RI or 5V or 12v, For details, please refer to description of JCOM.
- Page 23 LVDS1_VDD3 LVDS1_VDD3 LADATAN0 LADATAP0 LADATAN1 LADATAP1 LADATAN2 LADATAP2 LACLKN LACLKP LDDC_CLK LBKLT_EN BKLT_CTRL Ground Ground +V12S +V12S 24. BKL: (2.0mm Pitch 1x5 box Pin Header), Backlight control connector for LVDS1. Pin# Signal Name +DC12V +DC12V Ground Ground BKLT_EN BKLT_CTRL 25. SATA1/2/3: (SATA 7P),SATA1,SATA2,SATA3 SATA Connectors.
- Page 24 27. CN1: (2.5mm Pitch 1x2 box Pin Header), an onboard 5V output connector is reserved to provide power for IDE/SATA devices. Pin# Signal Name +DC5V Ground Note: Output current of the connector must not be above 1A. 28. PC104+: (4x30 Pin), PC104 plus connector, it conforms to standard PC104+ specification.
-
Page 25: Chapter 3 Bios Setup
Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation, the system will display the following screen for your further operation. Press F2 key to continue or F1 key to enter CMOS Setup. AMIBIOS© 2009 American Mega trends , Inc. -
Page 26: Bios Setup Utility
Please select boot device： Hitachi HTS545016B9A300 USB: USB Hotplug FDD ↑and ↓ to move selection ENTER to select Boot device ESC to boot using defaults 3.2 BIOS SETUP UTILITY Press [Del] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. -
Page 27: System Overview
System Date [Tue ESC Exit 01/01/2002] V02.68 © Copyright 1985-2009 American Mega trends , Inc. 3.3 System Overview BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit System Overview User [ENTER]，[TAB] AMIBIOS or [SHIFT-TAB] to Version : 08.00.16 Select a field Build Date : 03/22/12 Use[+] or [-] to : L706V012... -
Page 28: Advanced Settings
3.4 Advanced Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Advanced Settings Configure CPU WARNING: Setting wrong values In below sections may cause system to malfunction. ► CPU Configuration ► IDE Configuration ► Super IO Configuration ► Hardware Health Configuration ←... - Page 29 ► Smbios Configuration Exit ► USB Configuration V02.68 © Copyright 1985-2009 American Mega trends , Inc. 3.4.2 IDE Configuration BIOS SETUP UTILITY Advanced IDE Configuration Options ATA/IDE Configuration [Enhanced] Disabled Configure SATA as [IDE] Enhanced ► Primary IDE Master : [Not Detected] ►...
- Page 30 [IDE] [RAID] [AHCI] Hard Disk Write Protect: [Disabled] [Enabled] IDE Detect Time Out : [35] Options: [0,5,10,15,20,25,30,35] ATA(PI) 80Pin Cable Detection: [Host & Device] [Host] [Device] 3.4.3 Super IO Configuration BIOS SETUP UTILITY Advanced Configure Win627UHG Super IO Chipset Allow BIOS to Select Serial Port1 Address [3F8] Serial Port Base...
- Page 31 [RS485 Type] WatchDog Setting: [Disable] Options: [10sec,20sec,30sec,40sec,1min,2min,4min] 3.4.4 Hardware Health Configuration BIOS SETUP UTILITY Advanced Hardware Health Configuration Fan configuration mode CPU Temperature :41℃/105℉ setting CPUFAN Speed :4800 RPM CPUFAN Mode Setting [Manual Mode ← Select Screen CPUFAN PWM Control [250 ] ↑↓...
- Page 32 BIOS SETUP UTILITY Advanced AHCI Configuration While entering setup, ► AHCI Port0 : [Not BIOS auto detects the Detected] presence of IDE ► AHCI Port1 : [Not devices. This displays Detected] the status of auto ► AHCI Port2 detecting of IDE : [Not devices Detected]...
- Page 33 [1.4]...
- Page 34 [1.1] 3.4.8 PCI Express Configuration BIOS SETUP UTILITY Advanced PCI Express Configuration Enables/Disables Relaxed Ordering [Auto] PCI Express Device Maximum Payload Size [Auto] Relaxed Ordering Extended Tag Field [Auto] No Snoop [Auto] ← Select Screen Maximum Read Request Size [Auto] ↑↓...
- Page 35 Active State Power Management: [Disabled] [Enable] Extended Synch: [Auto] [Disabled] [Enable] 3.4.9 Smbios Configuration BIOS SETUP UTILITY Advanced Smbios Configuration SMBIOS SMI Wrapper Smbios Smi Support [Enabled] Support for PnP Func 50h-54h ← Select Screen ↑↓ Select Item Charge Field General Help F10 Save and Exit ESC Exit...
- Page 36 USB Configuration Enables support for Module Version – 2.24.5-14.4 legacy USB.ATUO option disables legacy support if no USB USB Devices Enabled : None devices are connected Legacy USB Support [Enabled] USB2.0 Controller Mode [Hispeed] ← Select Screen BIOS EHCI Hand-Off [Enabled] ↑↓...
-
Page 37: Advanced Pci/Pnp Settings
Advanced USB Mass Storage Device Configuration Number of seconds USB Mass Storage Reset Delay [20 Sec] POST waits for the USB mass storage device after start unit command Device #1 USB Hotplug Emulation Type [Auto] ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 Save and Exit ESC... - Page 38 IRQ4 F10 Save and Exit [Available] ESC Exit IRQ5 [Available] IRQ6 [Available] IRQ7 [Available] IRQ9 [Available] IRQ10 [Available] V02.68 © Copyright 1985-2009 American Mega trends , Inc. Clear NVRAM: [No] [Yes] Plug & Play OS: [No] [Yes] PCI Latency Timer: [64] [32] [96]...
- Page 39 [Enable] OffBoard PCI/ISA IDE Card: Some PCI IDE cards may require this to be set to the PCI slot number that is holding the card. Auto:Works for most PCI IDE Cards. [Auto] [PCI Slot1] [PCI Slot2] [PCI Slot3] [PCI Slot4] [PCI Slot5] [PCI Slot6] IRQ3/4/5/7/9/10/11/14/15:...
-
Page 40: Boot Settings
3.6 Boot Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Boot Settings Configure Settings ► Boot Setting Configuration During System Boot ► Boot Device Priority ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 Save and Exit ESC Exit V02.68 ©... - Page 41 [Force BIOS] [Keep Current] Bootup Num－Lock: Select Power-on state for Numlock. [On] [Off] PS/2 Mouse Support,: Select support for PS/2 Mouse. [Auto] [Enabled] [Disabled] Wait For „F1‟ If Error: Wait for F1 key to be pressed if error occurs. [Enabled] [Disabled] Hit „DEL‟Messgae Display : Displays “press”...
-
Page 42: Security Settings
3.7 Security Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Security Settings Install or Change the Supervisor Password :Not Installed password. User Password :Not Installed Change Supervisor Password Change User Password Boot Sector Virus Protection [Disabled] ← Select Screen ↑↓... -
Page 43: Advanced Chipset Settings
password. Type the password again and press Enter key. You may press Esc key to abandon password entry operation. To clear the password, just press Enter key when password input window pops up. A confirmation message will be shown on the screen as to whether the password will be disabled. - Page 44 BIOS Setup. If the connected panel is not included in the parameter list, display problem will occur. In this case, Please do not change BIOS setup. 3.8.1 North Bridge Configuration BIOS SETUP UTILITY Chipset North Bridge Chipset Configuration Options PCI MMIO Allocation: 4Gb To 3072MB Auto DRAM Frequency [Auto]...
- Page 45 [PCIE/PCI] Internal Graphics Mode Select: [Enabled, 8MB] Video Function Configuration: BIOS SETUP UTILITY Chipset Video Function Configuration Options DVMT Mode Select [DVMT Fixed Mode Mode] DVMT Mode DVMT/FIXED Memory [256MB] Boot Display Device ← Select Screen [VBIOS-Default] ↑↓ Select Item Flat Panel Type...
- Page 46 DVMT/FIXED Memory Size: [256MB] [128MB] [Maximum DVMT] Boot Display Device: [VBIOS-Default] [CRT] [LVDS] [CRT + LVDS] Flat Panel Type: [1024x 768LVDS] [640x480LVDS] [800x600LVDS] [1280x1024LVDS] [1366x768LVDS] Panel Backlight Control: [Level9] [Level0~15] Note: Panel support PWM Function. 3.8.2 South Bridge Configuration: BIOS SETUP UTILITY Chipset North Bridge Chipset Configuration Options...
- Page 47 F10 Save and Exit ► Video Function Configuration ESC Exit V02.68 © Copyright 1985-2009 American Mega trends , Inc. DRAM Frequency: [Auto] [Max MHz] Configure DRAM Timing By SPD: [Enabled] [Disabled] Initate Graphic Adapter: Select which graphics controller to use as the primary boot device. [IGD] [PCI/IGD] [PCI/PEG]...
- Page 48 DVMT/FIXED Memory [256MB] Boot Display Device ← Select Screen [VBIOS-Default] ↑↓ Select Item Flat Panel Type +- Charge option [1024x768LVDS] F1 General Help Panel Backlight Control [Level 9] F10 Save and Exit HDCP Support ESC Exit Disabled] V02.68 © Copyright 1985-2009 American Mega trends , Inc. DVMT Mode Select: [DVMT Mode] [FIXED Mode]...
-
Page 49: Exit Options
Panel Backlight Control: [Level9] [Level0~15] Note: Panel support PWM Function. 3.9 Exit Options BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Exit Options Exit system setup Save Changes and Exit after saving the Discard Changes and Exit changes Discard Changes F10 key can be used For this operation... -
Page 50: Examples Of Gpio Programming
[Cancel] Discard Changes: Diacard changes? F7 key can be used for this operation) [OK] [Cancel] Load Optimized Defaults: Load Optimized Defaults? F9 key can be used for this operation) [OK] [Cancel] Load Fail-Safe Defaults: Load Fail-Safe Defaults? F9 key can be used for this operation) [OK] [Cancel] 3.10 Examples of GPIO Programming... - Page 51 3.10.4 Read/write GPIO sequence 1. Enter the extended function mode 2. Select logic device number 3. Read/write GPIO register value 4. Exit the extended function mode 3.10.5 Software programming example Enter the extended function mode Writing 87h to index address port twice will enter the extended function mode. Example x86 assembly code: mov dx, 4Eh mov al, 87h...
- Page 52 outportb(0x4F, 0x08); //Select LDN=8, GPIO Port6 outportb(0x4E, 0x07); //LDN selection register outportb(0x4F, 0x09); //Select LDN=9, GPIO Port2 Activate the logic device Example x86 assembly code: mov dx, 4Eh mov al, 030h ;Logic device activation control reg. out dx, al mov dx, 4Fh in al, dx or al, 004h ;Set bit2 to enable GPIO Port6 if LDN=8 or al, 002h ;Set bit1 to enable GPIO Port2 if LDN=9...
- Page 53 Example C code: outportb(0x4E, 0xE6); //GPIO I/O selection reg. outportb(0x4F, 0x0); //0 – normal, 1 – inverted outportb(0x4E, 0xE4); //GPIO inversion reg. outportb(0x4F, 0xFF); //0 – Output, 1 - Input outportb(0x4E, 0xE4); //GPIO inversion reg. outportb(0x4F, 0xF0); //0 – Output, 1 – Input Read GPIO value Example x86 assembly code: mov dx, 4Eh...
- Page 54 Example C code: //Set GPO62 outportb(0x4E, 0xE5); //GPIO data reg. Outportb(0x4F, (inportb(0x4F)|0x4)); //Set Bit[2] //Clear GPO62 outportb(0x4E, 0xE5); //GPIO data reg. Outportb(0x4F, (inportb(0x4F)&0xFB)); //Clear Bit[2] The followings are C language source code: #include "stdio.h" #include "conio.h" //Super I/O index access port #define INDEXP 0x4E #define DATAP 0x4F //Enter super I/O programming mode...
- Page 55 ENTERPRG //Select the logical device 9, GP2 SELETDEV(9) //Activate GP1 WRITEREG(0x30, (inportb(0x30)|0x2)) WRITEREG(0xE6, 0x0) WRITEREG(0xE4, 0xFF) //Exit the super I/O chip programming EXITPRG return 0; //Initialize the GPIO port6 int InitGP6() { //Start the super I/O chip programming ENTERPRG //Select the logical device 8, GP6 SELETDEV(8) //Activate GP1 WRITEREG(0x30, (inportb(0x30)|0x4))
- Page 56 //Start the super I/O chip programming ENTERPRG //Select the logical device 9, GP2 SELETDEV(9) //Read GPIO Value outportb(INDEXP, 0xE5); cGP2 = inportb(DATAP); cGP2 = cGP2 & 0xF; //Exit the super I/O chip programming EXITPRG return cGP2; //Write GPIO Port6 int WriteGP6(unsigned char cGP6) { //Start the super I/O chip programming ENTERPRG //Select the logical device 8, GP6...
- Page 57 InitGP6(); //Read GPIO Port 2 cGP = ReadGP2(); printf("\nRead GPIO Port 2 Status: %X", cGP); //Write GPIO Port 6 WriteGP6(cGP); printf("\nSet GPIO Port 6 Status: %X", cGP); return 0;...
-
Page 58: Chapter 4 Installation Of Drivers
Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows XP. The software and drivers are included with the motherboard. The contents include Chipset Atom D525 + ICH8M, GMA 3150 VGA Chipset, Network Adapter, Realtek ALC662 HD Audio Driver, Touch Panel Driver. -
Page 59: Chipset Driver
4.1 Chipset Driver To install the chipset driver, please follow the steps below. Step 1. Access Industrial Panel PC. Select Chipset Atom D525 + ICH8M. Step 2. Click Next to setup program. - Page 60 Step 3. Read the license agreement. Click Yes to accept the terms of the license agreement. Step 4. Click Next to continue.
- Page 61 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drives.
-
Page 62: Gma 3150 Vga Chipset Driver
4.2 GMA 3150 VGA Chipset Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1. Select GMA 3150 VGA Chipset. Step 2. Click Next to continue. - Page 63 Step 3. Click Next to continue setup program. Step 4. Read the license agreement. Click Yes to accept the license agreement.
- Page 64 Step 5. Click Next. Step 6. Click Next to continue.
- Page 65 Step 7. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drivers.
-
Page 66: Network Adapter Driver
4.3 Network Adapter Driver To install the Network adapter Driver, please follow the steps below. Step 1. Select Network Adapter. Step 2. Click Next to continue. - Page 67 Step 3. Read license agreement. Select I accept the terms in the license agreement then click Next to continue. Step 4. Select Drivers, PROSet for Windows* Device Manager, Advanced Network Services. Click Next to continue.
- Page 68 Step 5. Click Install to begin the installation. Step 6. Click Finish to compete the installation.
-
Page 69: Realtek Hd Audio Driver Installation
4.4 Realtek HD Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Step 1. Select Realtek ALC662 HD Audio Driver from the list. Step 2. Wait for extracting the files then click Next to continue. - Page 70 Step 3. Click Yes to continue the installation. Step 4. Wait for installation.
- Page 71 Step 5. Select Yes, I want to restart my computer now. then click OK.
-
Page 72: Chapter 5 Touch Screen Installation
Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your PenMount 6000 Controller Board to work with different operating systems. NOTE: PenMount USB drivers support up to 15 USB controllers. 5.1 Introduction to Touch Screen Controller Board PenMount 6300 USB control board is a touch screen control board designed for USB interface and specific for 4, 5, 8-wire touch screens. - Page 73 Step 1. Please make sure your PenMount 6000 device had plugged in advance. If your device uses RS232 interface, please plugged in before the machine is turned on. When the system first detects the controller board, a screen appears that shows “Unknown Device”. Do not use this hardware wizard. Press Cancel.
- Page 74 Step 4. Read the license Agreement. Click I agree to agree the license agreement. Step 5. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation.
- Page 75 Step 6. Wait for installation. Then click Next to continue. Step 7. Click OK.
- Page 76 Step 8 Click Finish to compete installation.
- Page 77 5.2.2 Software Functions Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. 1. After installation, click the PenMount Monitor icon “PM” in the menu bar. 2.
- Page 78 Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ESC‟. Command Calibration Command call calibration function.
- Page 79 Step 2. Click Standard Calibration to start calibration procedure NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below:...
- Page 80 Step 3. Come back to PenMount Control Panel and select Tools then Click Advanced Calibration. Step 4. Select Device to calibrate, then you can start to do “Advanced Calibration”. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy.
- Page 81 Setting...
- Page 82 About This panel displays information about the PenMount controller and driver version.
- Page 83 Multiple Monitors Multiple Monitors supports from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/XP support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
- Page 84 Step 2. When the mapping screen message appears, click OK. Step 3. Touch each screen as it displays Please touch this monitor. Press „S‟ to skip Following this sequence and touching each screen is called mapping the touch screens. Step 4. After the setting procedure is finished, maybe you need to calibrate for each panel and controller NOTES: 1.
- Page 85 the system understands where the displays are. 4. If you more monitor mapping one touch screen, Please press „S‟ to skip mapping step. Tools Draw Tests or demonstrates the PenMount touch screen operation. Advanced Calibration Enable Advanced Calibration function Right Button Icon Enable right button function.
- Page 86 About You can see how many devices of PenMount controller that are plugged to your system PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 2000/XP system when you turn on PenMount Monitor in PenMount Utilities. PenMount Monitor has the following function...
- Page 87 PenMount Rotating Functions The PenMount driver for Windows 2000/XP supports several display rotating software packages. Windows Me/2000/XP support display rotating software packages such as: • Portrait‟s Pivot Screen Rotation Software • ATI Display Driver Rotate Function • nVidia Display Driver Rotate Function •...
