Original Instruction Manual
DML305-VS Cast Iron Electronic
Variable Speed Midi Lathe
Version 3.0
November 2012
It is important to register your product as soon as possible in order to receive efficient after sales
support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
Kg
Always wear safety glasses when
using woodworking equipment.
DML305-VS Manual 3.0.indd 1
To register this product please visit
www.recordpower.info
Please see back cover for contact details.
Important
i
For your safety read instructions carefully before
assembling or using this product.
Always read the instructions
provided before using
Save this manual for future reference.
woodworking equipment.
19/09/2013 11:13
Advertisement
Table of Contents
Related Manuals for Record Power DML305-VS
Summary of Contents for Record Power DML305-VS
- Page 1 Original Instruction Manual DML305-VS Cast Iron Electronic Variable Speed Midi Lathe Version 3.0 November 2012 To register this product please visit www.recordpower.info It is important to register your product as soon as possible in order to receive efficient after sales support and be entitled to the full 5 year guarantee.
-
Page 2: Table Of Contents
Machine Description & Technical Specifications Assembly Adjustment Operation Intended Use of the Lathe & Basic Woodturning Instructions 10 Dust Extraction 11 Electrical Connection & Wiring Diagram 12 Parts List & Diagram EU Declaration of Conformity DML305-VS Manual 3.0.indd 2 19/09/2013 11:13... -
Page 3: Explanation Of Symbols
Indicates a risk of severe personal injury from electrical shock Risk of personal injury from lifting of heavy items Indicates a risk of severe personal injury from airborne objects Risk of fire DML305-VS Manual 3.0.indd 3 19/09/2013 11:13... -
Page 4: General Health & Safety Guidance
13. Store machines safely when not in use using the fixings provided. • When not in use, machines should be stored in a dry place, out of reach DML305-VS Manual 3.0.indd 4 19/09/2013 11:13... - Page 5 • A guard or other part that is damaged should be properly repaired • Do not attempt to machine more than one work piece at a time. DML305-VS Manual 3.0.indd 5 19/09/2013 11:13...
-
Page 6: Additional Health & Safety Guidance For Woodturning Lathes
Always switch the machine ‘OFF’ and wait until the work piece has stopped rotating before attempting any adjustments. • Do not mount a work piece that contains excessive splits or loose knots or bark. DML305-VS Manual 3.0.indd 6 19/09/2013 11:13... -
Page 7: Record Power Guarantee
Guarantee should be made directly to Record Power or its Authorised Record Power guarantees that for a period of 5 years from the date Distributor (for details of the Authorised Distributor in your country of purchase the components of qualifying Products (see clauses 1.2.1 please see your Product manual or check www.recordpower.info... -
Page 8: Machine Description & Technical Specifications
1 or 2 Morse Taper (please refer to machine specification label) Hole through spindle: 9.5 mm Tailstock spindle travel: 63.5 mm Noise Emission: Sound power level < 83 dB (A) Sound pressure level < 83 dB (A) DML305-VS Manual 3.0.indd 8 19/09/2013 11:13... -
Page 9: Assembly
25mm thick. Four mounting holes are easily accessible at the base of the lathe. Fig.6.5. Drill holes in the work surface, using a 1/2” or 13mm drill bit, following the dimensions below. Note: Use of the DML305/A Adjustable Stand is recommended. Fig.6.5 Mounting holes 670mm DML305-VS Manual 3.0.indd 9 19/09/2013 11:13... - Page 10 3 Female cross brace 4 M10 x 25mm set screw x 2 5 M8 x 35mm bolt x 2 6 M10 x 80mm bolt x 12 7 Upright column x 2 8 Base x 2 DML305-VS Manual 3.0.indd 10 19/09/2013 11:13...
- Page 11 590mm the other is approximately 590mm. Hold in place using two M10 x 25mm set screws. Fig.6.9. M10 x 25 mm set screws DML305-VS Manual 3.0.indd 11 19/09/2013 11:13...
- Page 12 1 M10 x 50mm Bolt x2 2 M8 x 35mm Bolt x2 3 M10 Washer x2 4 M8 Washer x4 5 M10 Spring Washer x2 6 M8 Nut x2 7 Allen Key 8 Bed Extension DML305-VS Manual 3.0.indd 12 19/09/2013 11:14...
- Page 13 640mm (25”) so that the bed extension can sit on the leg extension safely. Hold in place by attaching the two M10 x 25mm set Main Leg Stand screws in the female cross brace, Fig 6.14. 640mm Hole for Set Screw DML305-VS Manual 3.0.indd 13 19/09/2013 11:14...
- Page 14 (not supplied) without causing damage to the product, Fig.6.19. DML305 Fig.6.17 DML305 Grub Screw Holes Bed Extension Fig.6.18 Bed Extension Fig.6.19 DML305-VS Manual 3.0.indd 14 19/09/2013 11:14...
-
Page 15: Adjustment
Please note: The indexing mechanism should not be used as a method of holding the spindle whilst removing accessories such as face plates, chucks etc. Always hold the spindle with a spanner on the spindle nose when removing accessories. DML305-VS Manual 3.0.indd 15 19/09/2013 11:14... - Page 16 Move the drive belt to the desired pulley combination. Loosen locking arm, lower lever and the weight of the motor will provide the correct tension on Tension lever the drive belt. Tighten locking arm and close access cover, Fig 7.9. DML305-VS Manual 3.0.indd 16 19/09/2013 11:14...
-
Page 17: Operation
Turn the speed control knob to its lowest setting before attempting to re-start the machine. Once the power is restored, the machine can be re-started by pressing the green button marked ‘I’ on the switch. DML305-VS Manual 3.0.indd 17 19/09/2013 11:14... -
Page 18: Intended Use Of The Lathe & Basic Woodturning Instructions
Never attempt to reposition the tool rest while the lathe is in motion. Tool rest height is also important and varies depending on the chisel DML305-VS Manual 3.0.indd 18 19/09/2013 11:14... - Page 19 There are a wide variety of specialised chisels and many complementary accessories available for Record Power lathes which enable a huge variety of work to be created. For further instructions on more advanced safe and effective woodturning, please seek professional training.
-
Page 20: Dust Extraction
10.2 Record Power Extractors 0.5 micron filtration; suitable for MDF Record Power offer a range of high quality dust extractors, starting at the single motor 45 litre RSDE1 right up to the 200 litre twin motor DX5000. We CX2600 Chip Collector offer both drum and bag type extractors high filtration models filter down Large capacity chip collector, with a powerful 0.37 kW induction motor. -
Page 21: Electrical Connection & Wiring Diagram
In this case there will not be an earth wire within the circuit. qualified electrician. In the case of the BS1363 plug for use in the UK, always ensure that it is fitted with a fuse conforming to BS1362 appropriate to the rating of the DML305-VS Manual 3.0.indd 21 19/09/2013 11:14... -
Page 22: Parts List & Diagram
Bed plate Handwheel Pan head screw Handwheel handle Lifting handle clamping Screw Lifting handle Hex socket set screw Cover plate Set screw M5X10 Lock lever Motor pulley Thread shaft Hex. Socket set screw Spring DML305-VS Manual 3.0.indd 22 19/09/2013 11:14... -
Page 23: Eu Declaration Of Conformity
EU Declaration of Conformity Cert No: EU / DML305-VS / 1 RECORD POWER LIMITED, Unit B, Ireland Industrial Estate Adelphi Way, Staveley, Chesterfield, Derbyshire S43 3LS declares that the machinery described:- 1. Type: Variable Speed Midi Lathe 2. Model No: DML305-VS 3. - Page 24 Chesterfield, Derbyshire S43 3LS Tel: 1300 124 422 Tel: 0800 142 326 Tel: 01246 561 520 Tel: 01246 561 520 Fax: 1800 262 725 Fax: 09 2717 237 www.recordpower.co.uk www.recordpower.co.uk www.recordpower.com.au www.recordpower.co.nz Made in China DML305-VS Manual 3.0.indd 24 19/09/2013 11:14...
