Extend the Life of Your Dosatron
REBUILD KIT
800-523-8499 • 727-443-5404
D14MZ2VFII
Part #: MKD14MZ2VF
Kit includes:
Part 1: Piston Kit
Upper flange
Lower flange
Omega spring
Connecting rod
Push rod seal
Part 2: Seal Kit
Injection sleeve o-ring
Injection stem o-ring
Check valve assembly
Plunger seal
