swisherinc.com
OWNER'S
MANUAL
STARTING SERIAL #:
L117-335001
MODEL NO.
WHERC10224C
WHERC10224
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Operation
Service and Adjustment
Repair Parts
8/23/2019
21024 REV 17-335
COMMERCIAL PRO
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE (660) 747-8183 FAX (660) 747-8650
24" WALK BEHIND
12V ROUGH CUT
PREDATOR TALON
WHERC10224C
PREDATOR
WHERC10224
ade I The
USA
of US and Global Parts
Advertisement
Table of Contents
Related Manuals for Swisher COMMERCIAL PRO PREDATOR TALON
Summary of Contents for Swisher COMMERCIAL PRO PREDATOR TALON
- Page 1 24” WALK BEHIND 12V ROUGH CUT Operation Service and Adjustment Repair Parts ade I The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093 8/23/2019 PHONE (660) 747-8183 FAX (660) 747-8650 of US and Global Parts 21024 REV 17-335...
- Page 2 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
- Page 3 Thank you for choosing Swisher’s 24” Walk Behind Rough Cut. Before operating your Walk Behind, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers can be potentially dangerous if not properly used.
- Page 4 • Turn off the blade when not mowing. Before leaving the machine, turn off the blade and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the mower if it has been dropped or damaged in any manner or if the mower vibrates excessively.
- Page 5 OPERATING YOUR NEW WALK BEHIND The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine.
- Page 6 STARTING THE ENGINE See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Engine must be level to accurately check and fill oil. Do not overfill. • Make sure unit is level, blade is disengaged, and transaxle in “NEUTRAL” •...
- Page 7 TRANSPORTING • Remove the key from ignition switch. • Shut off fuel at the engine. • Secure in place while unit is being transported. • Unit should be left in low gear to avoid any slight rolling. SUGGESTED PRACTICES • Always operate engine at full throttle when cutting to assure the best cutting performance and proper discharge of material.
- Page 8 SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher. OD55--DANGER DECAL OD45--WARNING DECAL OD83--RN1234 SHIFT DECAL 10749--REVERSE LOCK DECAL OD99112--LARGE LOGO WHITE DECAL OD99156--SMALL LOGO WHITE DECAL 20076--SWISHER FLAG DECAL DECALS NOT SHOWN 19722-- Predator Talon LH Decal...
- Page 9 ASSEMBLY DETAIL WHERC10224C MODEL SHOWN WITH CASTERS When ordering replacement parts *USE PAINT CODE: TK=BLACK BATTERY NOT INCLUDED: REQUIRES A 12V LAWN AND GARDEN BATTERY WITH A 235 MIN CCA. U1 GROUP FOR CORRECT FIT. Tip: Valve stems should be turned to avoid contact with caster yoke.
-
Page 10: Table Of Contents
ENGINE & PULLEY ASSEMBLY Item # Description Part # Item # Description Part # Nut - Nyloc 5/16-18 NB181 Bolt - 3/8-16 X 1 1/2 NB107 Bolt - Serr Flange, 5/16-18 X 1 10548 Washer - SAE Flat 3/8 NB272 Nut - Serr Flange 5/16-18 NB170 Pulley - Idler, OD-2.16", ID-3/8"... -
Page 11: Item # Description
REAR COVER ASSEMBLY Item # Description Part # Nut - Serr Flange 5/16-18 NB170 Plate - Cover, Back 10679* Arm - Anti Reverse 10680* Spacer B99S Bolt - Serr Flange, 5/16-18 X 3/4 NB596 HANDLE BAR & LEVER ASSEMBLY Item # Description Part # Knob - T... -
Page 12: Nb170
BLADE DRIVER ASSEMBLY Item # Description Part # Nut - Jam 3/4-16 NB175 Washer - Belleville .760 X 1.5 X .098 AS155 Pulley - Blade, 5.5" 20651 Spacer - 3/4 ID X 1 12823 Washer - 3/4 ID X 1 1/4 OD NB179 Bearing - Blade Shaft - Blade 6", Long Shoulder... -
Page 13: Bolt - Serr Flange, 5/16-18
DECK & CASTER ASSEMBLY PAGE 12 FOR MODEL WHERC10224C Item # Description Part # Deck - Weldment 10695* Bolt - 1/4-20 X 3/4 NB250 Clip - Blade Engagement Cable 10673* Nut - Nyloc 1/4-20 NB180 Nut - Serr Flange 5/16-18 NB170 Weldment - WB Skid 18512*... -
Page 14: Nb596
TRANSAXLE ASSEMBLY Item # Description Part # Item # Description Part # Wheel - Asy Right; WB24 4.8x8 2401RK Grip - Transmission Lever 2427 Screw - Set 5/16-18 X 1/2 NB312 Lever - Transmission 20652* Pulley - Transmission, 8" 2410 Nut - Serr Flange 5/16-18 NB170 Washer - SAE Flat 1/4... - Page 15 WIRING CONFIGURATION Wiring Harness PN 20988 BELT CONFIGURATION 2410 TRANSAXLE PULLEY 690 – TRANSAXLE BELT TOP ENGINE PULLEY CONFIGURATION B27 – TRANSAXLE IDLER PULLEY 2411 – TOP ENGINE PULLEY BB105 – LOWER ENGINE PULLEY 20655 – BLADE ENGAGEMENT BELT T30V – V-BELT PULLEY BOTTOM ENGINE PULLEY CONFIGURATION B527 –...
- Page 16 All cutter parts listed herein may be ordered directly from MODEL NO. Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the engine supplied with your cutter...
