Swisher T11544 Owner's Manual

44” finish cut trailmower
Hide thumbs Also See for T11544:
Table of Contents

Advertisement

Quick Links

swisherinc.com
OWNER'S
MANUAL
MODEL NO.
START SERIAL # L110-323001
T11544
T11544EC
T11044
T10544BSPB
T12544
T1144HSP
POL11544D
POL11544DEX
T11544-CA
T12544-CA
T12544EC
IMPORTANT
Read and follow all Safety
Precautions and
Instructions before
operating this equipment.
Rev 10-323
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
10662
44" FINISH CUT
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE 660-747-8183 FAX 660-747-8650
Made In The
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T11544 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swisher T11544

Summary of Contents for Swisher T11544

  • Page 1 OWNER’S MANUAL MODEL NO. START SERIAL # L110-323001 T11544 T11544EC T11044 T10544BSPB 44” FINISH CUT T12544 T1144HSP TRAILMOWER POL11544D POL11544DEX T11544-CA T12544-CA T12544EC IMPORTANT Assembly Read and follow all Safety Precautions and Operation Instructions before Service and Adjustment operating this equipment.

  • Page 2: Limited Warranty

    Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.
  • Page 4 • Turn off the blades when not mowing. Before leaving the machine, turn off the blades and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the mower if it has been dropped or damaged in any manner or if the mower vibrates excessively.

  • Page 5: Safety Decals

    SAFETY DECALS Replace decal immediately if damaged. Order by part number from Swisher OD33-Speed Decal TrailMower Serial # OD55-Triangle Danger Decal (All four deck corners) OD99127-44" Deck White Decal (Not Pictured) OD99127-44" Deck White Decal (Not Pictured) Engine Serial #...
  • Page 6 OPERATING YOUR TRAILMOWER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any cutter produces sound waves that are damaging to the human ear.

  • Page 7: Starting The Engine

    See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Mowers equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard “12N12A” battery. • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged.
  • Page 8 When offsetting the mower do so to the side opposite the discharge of the tow vehicle. • Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle.

  • Page 9: General Troubleshooting

    SUGGESTED MOWING PRACTICES • Operate mower engine at full throttle to assure the best cutting performance and maximum material discharge. • Allow wet grass to dry. Wet grass will clump and collect under the mowing deck. • Mowing should be started with tow vehicle in low gear and increased only as safe mowing conditions permit.

  • Page 10: Mower Maintenance

    MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this TrailMower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season.

  • Page 11: Repair Parts

    BLADE CARE AND SERVICE For best results cutter blades must be kept sharp. The blades can be sharpened with a few strokes of a file or grinding wheel. Do not attempt to sharpen blades while they are on the cutter. Disconnect spark plug wire before servicing unit. Important: Replace blades that have been damaged or deeply nicked.
  • Page 12 BALL LOCK PINS FRONT LEFT RIGHT Left offset shown REAR FIGURE ONE Slide plastic tube snug against toggle switch. FIGURE TWO (FIGURE FIVE FOR DETAILS)

  • Page 13: Parts Not Shown

    12 VOLT MODELS BATTERY (12N12A) RECOMMENDED SOLD SEPARATELY SOLENOID 1002004 BATTERY CABLE - POSITIVE BCSR BATTERY CABLE - NEGATIVE EXTRAS VELCRO STRAPS 7033 SWISHER DECAL OD99125 44" DECAL OD99127 INTERLOCK MODULE MOD1 BATTERY BOX 10231 BATTERY PAD BATPAD BATTERY CABLE...
  • Page 14 SEE DETAILS 13, 23 40, 41, 42 FIGURE FOUR T-HANDLE OPTION SEE DETAIL SINGLE POINT HEIGHT ADJUST ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # BELT COVER 10599* 5/16 NUT NB170 MOTOR BASE 4517* 5/16 BOLT NB596 1/4 BOLT NB114 3/8 NUT NB182...
  • Page 15 FIGURE SIX BLADE SET-UP FIGURE FIVE ENGINE SET-UP ITEM # DESCRIPTION PART # 3/4 NUT NB175 ITEM # DESCRIPTION PART # UPPER BELLEVILLE AS155 ENGINE NOT AVAILABLE BLADE PULLEY B4104 5/16 BOLT NB253 THIN WASHER NB179 5/16 NUT NB170 BLADE DRIVER 9018 TOGGLE BRACKET 4483Z...
  • Page 16 SEE FIG. NINE FIGURE SEVEN T-HANDLE OPTION FIGURE EIGHT ITEM # DESCRIPTION PART # STANDARD ENGAGE T-HANDLE LEVER 4463TK COTTER PIN NB597 ITEM # DESCRIPTION PART # 1/4 NUT NB180 ENGAGE STANDOFF 4547TK WASHER NB274 5/16 Spade Bolt NB260 ENGAGE LINK 4461TK 1/2 BOLT NB155...
  • Page 17 ITEM # DESCRIPTION PART # 106A 3/8 NUT NB280 WASHER NB272 IDLER PULLEY B527 WASHER NB556 5/16 SERR FLG BOLT NB253 IDLER SPRING 4422 5/16 NUT NB170 BRAKE LINK 4532 3/8 BOLT NB107 5/16 SPADE BOLT NB260 EYE BOLT V139EB 5/16-18 NUT NB210Z 3/8 NUT...
  • Page 18 FIGURE ELEVEN BRAKE ARM CONFIGURATIONS Item # Description Part # 1/4-20 BOLT NB162 1/4-20 NUT NB524 BRAKE ARM 10589 1/4-20 NYLOCK NB180 BRAKE PAD 9039 10-24 BOLT NB710 10-24 KEP NUT NB172 EYE BOLT V139EB 1/4-20 NUT NB180 1/4-20 BOLT NB102 1/4-20 x 2 BOLT NB218...

  • Page 20: How To Order Repair Parts

    The serial number for the engine will be found on the top of the blower fan housing. All TrailMower parts listed herein may be ordered directly T11544 from Swisher, your nearest Swisher dealer, or from our website. www.swisherinc.com T11544EC All engine parts may be ordered from the nearest dealer of the...
