Swisher FC11544BS Owner's Manual

44” finish cut trail mower
Hide thumbs Also See for FC11544BS:
Table of Contents

Advertisement

Quick Links

swisherinc.com
OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL # L113-001001
FC11544BS
FC12544BS
POL11544D
POL11544DEX
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Rev 13-001
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
10662
CHANGING YOUR LANDSCAPE SINCE 1945
44" FINISH CUT
TRAIL MOWER
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER
PHONE 660-747-8183 FAX 660-747-8650
Made In The
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC11544BS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swisher FC11544BS

Summary of Contents for Swisher FC11544BS

  • Page 1 OWNER’S MANUAL MODEL NO. STARTING SERIAL # L113-001001 FC11544BS FC12544BS POL11544D POL11544DEX CHANGING YOUR LANDSCAPE SINCE 1945 44” FINISH CUT IMPORTANT TRAIL MOWER Read and follow all Safety Precautions and Instructions before operating this Assembly equipment. Operation Service and Adjustment...

  • Page 2: Limited Warranty

    Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.
  • Page 4 • Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times. • Do not mow in reverse. Always look down and behind before and while backing. • Turn off the blades when not mowing. Before leaving the machine, turn off the blades and stop the engine.

  • Page 5: Safety Decals

    SAFETY DECALS Replace decal immediately if damaged. Order by part number from Swisher. OD33-Speed Decal Trail Mower Serial # OD55-Triangle Danger Decal (All four deck corners) OD99127- 44" Deck Decal Engine Serial # OD15-Void Warranty Decal OD11-No Step Decal OD36-Deflector Decal...
  • Page 6 OPERATING YOUR TRAIL MOWER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before staring any cutting machine and while operating such a machine.

  • Page 7: Starting The Engine

    See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Mowers equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard “12N12A” battery. • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged.
  • Page 8 When offsetting the mower do so to the side opposite the discharge of the tow vehicle. • Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle.

  • Page 9: General Troubleshooting

    SUGGESTED MOWING PRACTICES • Operate mower engine at full throttle to assure the best cutting performance and maximum material discharge. • Allow wet grass to dry. Wet grass will clump and collect under the mowing deck. • Mowing should be started with tow vehicle in low gear and increased only as safe mowing conditions permit.

  • Page 10: Mower Maintenance

    MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trail Mower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season.

  • Page 11: Repair Parts

    BLADE CARE AND SERVICE For best results mower blades must be kept sharp. The blades can be sharpened with a few strokes of a file or grinding wheel. Do not attempt to sharpen blades while they are on the mower. Disconnect spark plug wire before servicing unit. Important: Replace blades that have been damaged or deeply nicked.

  • Page 12: Parts Not Shown

    Fig. 1 WIRING CONFIGURATIONS FC44 RECOIL START FC44 12 VOLT START PARTS NOT SHOWN DESCRIPTION PART # RECOIL START MODELS Harness - Wiring, Recoil 10638 Module MOD1 12 VOLT START MODELS Harness - Wiring, 12V 10235 Harness - Toggle/Ground Wire Assembly 9090 Solenoid - 3 Pole 1002004...
  • Page 13 Fig. 2 PARTS BREAKDOWN ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # Cover - Belt 10599* Nut - Nyloc 1/2-13 NB281 Bolt - 1/4-20 X 1/2 NB114 Bolt - 1/2-13 X 2 1/2 NB588 Bracket - Roller, Left 4015* Base - Motor 4517*...
  • Page 14 Slide plastic tube on tether 6736 snug against toggle switch 685SP. Fig. 3 Fig. 4 ENGINE SET UP BLADE SET UP ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # Nut - Jam 3/4-16 NB175 Engine - 11.5HP Engine - 12.5HP 12V Washer - Belleville .760 X 1.5 AS155 Pulley - Blade 4 1/2"...
  • Page 15 Fig. 5 Fig. 6 STANDARD ENGAGE HEIGHT ADJUSTMENT ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # QTY Bolt - 1/2-13 X 5 NB155 Rod - Crank ES214 Bolt - Spade, 5/16-18 X 10.5 NB260 Nut - Push, 5/16 NB117 Nut - Nyloc 5/16-18 NB181...
  • Page 16 Fig. 7 Tension Assembly ITEM # DESCRIPTION PART # Nut - 2 Way Lock 3/8-16 NB280 Washer - 3/8 NB272 Pulley - Idler B527 Bolt - 1/4-20 X 2 NB218 Bolt - 3/8-16 X 1 1/4 NB618 Washer - Idler 6040Z Nut - Nyloc 1/4-20 NB180...
  • Page 17 RIGHT ASSEMBLY PART # 10590 Fig. 9 Item # Description Part # Arm - Brake 10589* BRAKE ARM CONFIGURATIONS Eyebolt - 1/4-20 X 3/4 V139EB Nut - Nylock 1/4-20 NB180 Nut - Serr Flange 1/4-20 NB524 Bolt - HTC 1/4-20 X 1 1/2 NB162 Nut - Kep 10-24 NB172...
  • Page 18 Fig. 10 HITCH ASSEMBLY ITEM # DESCRIPTION PART # QTY. Weldment - "L" Hitch RTB & T44 18829* Tube - Hitch RC44 & FC44 18832* Tube - Hitch Elbow RC44 & FC44 18833* Washer - SAE Flat 3/8 ZY Carbon Steel NB272 Bolt - 3/8-16 X 2 1/2 HCC GR5 ZY NB221...

  • Page 20: How To Order Repair Parts

    FC11544BS All Trail Mower parts listed herein may be ordered directly FC12544BS from Swisher, your nearest Swisher dealer, or from our website. www.swisherinc.com POL11544D All engine parts may be ordered from the nearest dealer of the POL11544DEX...
