OWNER'S
MANUAL
Starting serial number:
L111-005001
MODEL NO.
PST67522
PST67522-CA
PST67522EC
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
ONPM03
Rev 11-005
TOW MOWER & FENCE
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE (660) 747-8183 FAX (660) 747-8650
POSTMASTER
POST TRIMMER
Made In The
USA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Swisher POSTMASTER PST67522
Summary of Contents for Swisher POSTMASTER PST67522
- Page 1 OWNER’S MANUAL Starting serial number: L111-005001 MODEL NO. PST67522 PST67522-CA PST67522EC POSTMASTER TOW MOWER & FENCE POST TRIMMER Assembly Operation Service and Adjustment Repair Parts 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 Made In The PHONE (660) 747-8183 FAX (660) 747-8650...
- Page 2 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
- Page 3 SAFETY PRECAUTIONS & DECALS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands and feet, and throw objects.
- Page 4 OD55- Danger- Triangle Decal OD45- Warning Serious Injury Decal ASSEMBLY • Disconnect spark plug wire from spark plug and place where it cannot make a connection. • All engines are filled with oil at the factory. Verify oil level and add if necessary before starting engine.
- Page 5 SLOPE OPERATION! Use extra caution when mowing on slopes. Operate self-propelled units up and down slopes. There is a significant risk of overturns when operating across slopes. If you feel uneasy on a slope then do not mow it. INTENDED USE This is not a lawn mower.
-
Page 6: Cutting Height
BEGIN TRIMMING • Make sure area is clear of all bystanders. • Make sure that all guards, belt guides, and the spark plug wire are properly attached. • Start engine, setting desired engine speed. Note: This machine is designed to operate at maximum engine speed. - Page 7 SUGGESTED PRACTICES • Always operate engine at full throttle when cutting to assure the best cutting performance and proper discharge of material. • Offset unit to the right-hand side whenever possible (as shown). Debris is thrown away from the operator. •...
- Page 8 STORAGE • Do not store engine indoors or other poorly ventilated areas. • If unit is to be stored for longer than 30 days, prepare as directed below: Drain fuel outside into an approved container. Start engine and run until unit is completely out of fuel. Removing fuel prevents gum deposits from forming inside carburetor.
- Page 9 MAIN BODY ASSEMBLY SEE DETAIL FIGURE 1 Page 11 SEE DETAIL Page 11 SEE DETAIL Page 11 Item # Description Part # Item # Description Part # Plastic Cover 3526 1/2 NR Mach Bushing 14 GA NB177 3/8-16 Nyloc Nut NB182 3/4-16 Jam Nylok Nut NB122...
- Page 10 HITCH FRAME ASSEMBLY FIGURE 2 Item # Description Part # 5/8-11 Nylok Nut NB561 5/8-11 X 1 1/2 HCC GR5 ZP NB145Z Safety Hitch Pin 5/16-18 Nyloc Nut NB181 Plug for H1 10063 Hitch 3549TC 5/16-18 X 2 1/2 HCC GR5 ZP NB138 Chain - Tension Adjustment 3568...
-
Page 11: Engine Assembly
NOT ACTUAL ENGINE ASSEMBLY ENGINE USED FIGURE 3 (REF. ONLY) Item # Description Part # 3/8-24 X 1 Engine Bolt Locktite NB238N Engine Pulley- 6" 2065 3/16 X 1 Key Stock 9030 5/16-18 X 1 1/4 Serr. Flng Bolt NB253 5/16-18 Serr. - Page 12 OWNER’S blower fan housing. All mower parts listed herein may be ordered directly from Swisher or your nearest Swisher dealer. MANUAL All engine parts may be ordered from the nearest dealer of the engine supplied with your mower MODEL NO.
