Quick start guide
2-port PCI Express 10GBase-T Ethernet network card
ST20000SPEXI
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging contents
• 1 x PCI Express® 10GBase-T Ethernet network card
• 1 x low-profile bracket
• 1 x quick start guide
System requirements
• PCI Express enabled computer with an available PCI Express slot
(x4, x8, or x16)
• Any of the following operating systems:
• Microsoft® Hyper-V®
• Windows® 7 (32-bit or 64-bit)
• Windows 8 (32-bit or 64-bit)
• Windows 8.1 (32-bit or 64-bit)
• Windows Server® 2003
• Windows Server 2008 R2
• Windows Server 2012
• Linux® kernel 2.6.x and 3.x
Note: Operating system requirements are subject to change. For the
latest requirements, please visit www.startech.com/ST20000SPEXI.
Product diagram
Link speed LED
Ethernet port
Link state and activity LED
For the latest information, technical specifications, and support for
www.startech.com/ST20000SPEXI
this product, please visit
Installation
Install the PCI Express card
WARNING!
PCI Express cards can be severely damaged by static electricity. Make
sure that you're properly grounded before you open your computer
case or touch your PCI Express card. You should wear an anti-static
strap when you install any computer component. If an anti-static
strap isn't available, discharge any built-up static electricity by
touching a large grounded metal surface for several seconds. Only
handle the PCI Express card by its edges and don't touch the gold
connectors.
1. Turn off your computer and any peripherals that are connected
2. Unplug the power cable from the back of your computer.
3. Disconnect any peripheral devices that are connected to your
4. Remove the cover from your computer case. Consult the
5. Locate an open PCI Express slot and remove the corresponding
6. Gently insert the card into the open PCI Express slot and fasten
Note: If you install the card into a small form factor or a low-profile
desktop system, it may be necessary to replace the preinstalled
standard-profile bracket with the included low-profile (half height)
installation bracket.
7. Place the cover back onto your computer case.
8. Reconnect the power cable to the back of your computer.
9. Reconnect all of the peripheral devices that you disconnected in
10. Turn on your computer.
Install drivers on a computer running Windows
1. If the Found New Hardware dialog box appears on your screen,
close the dialog box or click Cancel.
PCIe x4
2. To download the latest drivers, navigate to
connector
and enter ST20000SPEXI in the Search field.
3. Click Support.
4. Download the driver.
5. When the download is complete, double-click the appropriate
driver for the version of Windows that you're running and follow
*actual product may vary from photos
the on-screen instructions to complete the installation.
.
to your computer (for example, printers, external hard drives, and
so on).
computer.
documentation that came with your computer for details about
how to do this safely.
metal cover plate from the back of the computer case. Consult
the documentation that came with your computer for details
about how to do this safely. This card works in PCI Express slots of
additional lanes (x4, x8, or x16 slots).
the bracket to the back of the case.
step 3.
www.StarTech.com
Manual Revision: 06/16/2015
