- Page 1 DESIGN SL-07M 7” video door phone DIRECT User manual Thank you for the { Design. Uniqueness. Innovation } choice of our equipment...
-
Page 2: Table Of Contents
This manual can contain some inaccuracy or misprint. The owner reserves the right to 3. Description......................................4 make corrections to the information described in the user manual and device package. 4. Installation.......................................5 The last revision of this manual is available on www.slinex.com 4.1 Cable requirements..............................5 Safety instructions 4.2 Schematic diagrams..............................6 Read and keep that manual. -
Page 3: Package
DESIGN { Design. Uniqueness. Innovation } DIRECT 1. Package 3. Description SL-07M door monitor − 1 pc. Wall mounting bracket − 1 pc. Connection wires − 7 pcs. Mounting screws and nuts − 1 pkg. User manual − 1 pc. 2. -
Page 4: Cable Requirements
DESIGN { Design. Uniqueness. Innovation } DIRECT 4. Installation 4.2 Schematic diagrams Diagram 1. SL-07M door panels, cameras, locks and TV connection. 4.1 Cable requirements Disconnect all power cables before device installation. This device can be connected with such cable types depends on the distance between door monitor and door panel: ) Use 4-wire cable with such parameters: •... -
Page 5: Unit Mount
DESIGN { Design. Uniqueness. Innovation } DIRECT 4.3 Unit mount Diagram 2. SL-07M system connection. 1) Take the surface mount bracket from the kit and situate it 150-160 cm from the oor line. 2) Mark and drill four halls in the wall. 3) Take four nuts from the kit and hammer them into the drilled halls. -
Page 6: Operation
DESIGN { Design. Uniqueness. Innovation } DIRECT 5. Operation 5.2 Door panel and camera image view 5.1 Incoming call Standby mode Standby mode Monitor will display Press «Monitor» the image from the button on the rst door panel monitor Visitor presses call button Visitor presses call button (monitoring time –... -
Page 7: Intercom
DESIGN { Design. Uniqueness. Innovation } DIRECT Notes: 5.4 Intercom 1) If only one door panel connected to the monitor then you can escape monitoring mode by pressing Two monitors connected into one system are used. «Monitor» button one more time. (all other sources of video signal should be disabled in the monitor settings). -
Page 8: System Settings
DESIGN { Design. Uniqueness. Innovation } DIRECT Release date − date of software release. Format SD − micro SD card formatting. Please format microSD card before use it. Recommended to use microSD cards of the 6-th class and above. Format flash − internal memory formatting. Backup pictures−... -
Page 9: Melody And Volume Settings
DESIGN { Design. Uniqueness. Innovation } DIRECT Main menu Software version: 1.1.3.2 Main menu Release date: 2016-07-08 Door 1 Format SD Format flash Door 2 Ring Backup pictures System Update Reboot Return Ring select Information Return 6.3 Melody and volume settings Press «Ring»... -
Page 10: Alarm Settings
DESIGN { Design. Uniqueness. Innovation } DIRECT CAM1 − «On» or «O », include or exclude first CCTV camera from the monitoring list. Record mode: «Snapshot» – take snapshot while incoming call or manually; CAM2 − «On» or «O », include or exclude second CCTV camera from the monitoring list. «Record»... - Page 11 DESIGN { Design. Uniqueness. Innovation } DIRECT Software motion detector can observe and detect motion without any external sensors using any camera image changes with the time. Camera power that is used for motion detection should be constantly on to let the monitor observe image changes and detect it.
- Page 12 DESIGN { Design. Uniqueness. Innovation } DIRECT Press «Record files» or «Snapshot files» icon to enter snapshots or records playback menu then choose the Every video source has its own image settings: le to play. Brightness – parameter range from 0 to 50, 25 used by default. Choose one of three operations: Contrast –...
-
Page 13: External Sensors Motion Detection Recording
DESIGN { Design. Uniqueness. Innovation } DIRECT 7. Manual recording 9. Limited warranty User can take snapshots or record video during monitoring door panel or CCTV camera. Press Manufacturer guarantees product normal functioning during the warranty period if the user keeps all safety button to start recording then press button again to stop recording.
