- Page 1 Quick Installation Guide 1/2.8” Network Board Camera, 1920x1080, Day&Night, D-WDR, PoE, 12V NXP-880Fxx...
-
Page 2: Table Of Contents
Table of content Components ........................5 Installation ........................6 Extension Cable .................................6 Connection ..................................6 Micro SD memory slot ..............................6 RJ-45 port ..................................7 Connecting Alarms ..............................7 Connecting the Power ..............................7 Connecting Audio ................................8 Network Connection & IP assignment ........................8 Operation ........................10 Access from a browser ..............................10 Access from the internet .............................. - Page 3 Safety instructions General safety instructions • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
- Page 4 Class A device note This is a Class A device. This device can cause malfunctions in the living area; in such an event, the operator may need to take appropriate measures to compensate for these. WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems).
-
Page 5: Components
Components This system comes with the following components; • Module Camera • Installation Guide Notice: Check your package to make sure that you received the complete system, including all components listed above. Notice: Adapter for DC 12V is not supplied. -
Page 6: Installation
Installation For the operation of the Network Camera, it is necessary to connect a network cable for data transmission, power connection from supplied power adapter. Depending on operation methods, it is possible to connect an alarm cable additionally. For its fixation on different locations, please consult with an installer. -
Page 7: Rj-45 Port
RJ-45 port Connect a standard RJ-45 cable to the network port of the network camera. Generally a cross-over cable is used for directly connection to PC, while a direct cable is used for con- nection to a hub. You can also use a router featuring PoE (Power over Ethernet) to supply power to the camera. -
Page 8: Connecting Audio
The eneo Scan Device Tool (downloadable from www.eneo-security.com) is used to locate all eneo network cameras in a local network. The tool does not need to be installed with a setup program. The program exe-file can be started with a simple double click to use the program. - Page 9 Select the „Editing the camera IP address“ option to open a window for setting the cam- eras IP properties. When you are done click the „Activate“ button to update the camera settings. For further information, please refer to the eneo Scan Device Tool Quick Start Guide.
-
Page 10: Operation
Operation The network camera can be used with Windows operating system and browsers. The recommended browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows. Notice: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX controls. -
Page 11: Access From The Internet
Access from the internet Once connected, the network camera is accessible on your local network (LAN). To access the network camera from the Internet you must configure your broadband router to allow incoming data traffic to the network camera. To do this, enable the NAT traversal feature, which will attempt to automatically configure the router to allow access to the network camera. -
Page 12: General Controls
to select the most suitable one out of those modes. Adjust the mode in accordance with your PC specifications and monitoring purposes. General controls Live View Page Playback Page Setup Page Help Page The video drop-down list allows you to select a customized or pre- programmed video stream on the Live View page. -
Page 13: Video Streams
The Digital Zoom button activates a zoom-in or zoom-out function for video image on the live screen. The Full Screen button causes the video image to fill the entire screen area. No other windows will be visible. Press the ‘Esc’ button on the computer keyboard to cancel full screen view. - Page 14 The description of playback window follows. ① Video Screen: You can see the video screen when playing the video clip in the Micro SD memory. ② Playback Buttons: To view a recording data in the SD local storage, select it from the list and click the Play- back buttons.
- Page 15 Step forward play: go forward one frame of the video clip. Forward Play: play forward the video clip. Fast forward play: play fast forward of the video clip. Go to the last: go to the end of the video clip. Clip copy: copy the video clip.
-
Page 16: Network Camera Setup
⑧ Event List Window: Event List displays the event(s) that were recorded in the SD local storage. Select a list and click the play button. The video clip will be played. Network Camera Setup This section describes how to configure the network camera. Administrator has unrestricted access to all the Setup tools, whereas Operators have access to the settings of Basic Configuration, which are Live View, Video &... -
Page 17: Resetting To The Factory Default Settings
(Default IP 192.168.1.10) Further information Make sure to always upgrade to the latest firmware version available from the eneo web- site at www.eneo-security.com to receive the latest functionality for your product. The manual, and other software tools are available on the eneo website at www.eneo-se- curity.com. - Page 18 The software included in this product contains copyrighted software that is licensed under open source licenses. You may obtain the complete corresponding source code from eneo for a period of three years after the last shipment of this product by sending email to: opensource@eneo-security.com.
