INSTALLATION INSTRUCTIONS
HB0072
INTENDED FOR DOMESTIC COOKING ONLY
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14.
Venmar Ventilation ULC, Drummondville, Québec
REGISTER YOUR PRODUCT ONLINE AT: www.broan.ca
E64000LC SERIES
www.broan.ca 877-896-1119
!
21242 rev. 02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Broan E6436SSLC
Summary of Contents for Broan E6436SSLC
- Page 1 INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14. Venmar Ventilation ULC, Drummondville, Québec www.broan.ca 877-896-1119 REGISTER YOUR PRODUCT ONLINE AT: www.broan.ca 21242 rev. 02...
-
Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following
Use an appropriate make-up air device or open a window close to or in the kitchen. 10. To reduce the risk of fire and electric shock, the Broan Elite E64E Series hood must be installed with one Broan exterior blower model 331H, 332H, 335 or 336;... - Page 3 E64000LC SERIES RANGE HOOD SYSTEM - INTERNAL BLOWERS ODEL (10" R OUND ALL CAP ODEL (7" R OUND ODEL ODEL ODEL ALL CAP APACITY (8" R OUND ODEL 8" R OUND (7" R OUND DJUSTABLE LBOW DJUSTABLE LBOW ODEL (10" R OUND DJUSTABLE LBOW...
- Page 4 E64000LC SERIES RANGE HOOD SYSTEM - IN-LINE AND EXTERIOR BLOWERS ODEL IGH CAPACITY HLB9 (800 ODEL HLB11 (1100 335 (1200 ODEL LINE LOWER 331H (600 ODEL 336 (1500 8" 12" INCLUDES TWO 332H (900 XTERIOR BLOWER 10" ROUND TRANSITIONS XTERIOR LOWER ODEL (10"...
- Page 5 The Broan Elite E64000LC Series range hood includes many configurations: hoods with single or double internal blowers (included with the hoods), or hoods using external blowers. For hoods using external blowers, the Broan Elite E64000LC Series must be installed with in-line blower models HLB3, HLB6, HLB9 or HLB11, or exterior blower model 331H, 332H, 335 or 336 only.
-
Page 6: Prepare The Installation
2. PREPARE THE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. NOTE: Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the manufacturer. Make sure that the following items are included: - Range hood - Accessories:... -
Page 7: Install Backsplash (Optional)
2. PREPARE THE INSTALLATION ( CONT’D Cut-out the openings for duct (A) and power cable (B), in cabinet or wall, according to the direction of discharge chosen. See figures below. NOTE: For all internal blower hoods, the cut-out opening for house wiring can be made in cabinet bottom OR wall, no matter the discharge chosen (vertical or horizontal). -
Page 8: Remove The Adapter
4. REMOVE THE FILTERS AND THE GREASE DRIP RAIL NOTE: For 36” and 42” wide double blower hoods, the adapter is taped on top of the filters. Remove adapter and set aside before removing filters. A. Remove tape on filters. Remove filters from hood and set aside. -
Page 9: Horizontal Discharge Installation
6. CHOSE THE OPENING(S) (INTERNAL BLOWER HOODS ONLY) Remove the knockout for the chosen opening(s) (horizontal at the back of the hood or vertical on top). See illustrations below. ERTICAL DISCHARGE ORIZONTAL DISCHARGE HR0021 Punch out the appropriate electrical knockout hole on top (A) or back (B) of the hood. - Page 10 7. HORIZONTAL DISCHARGE INSTALLATION (INTERNAL BLOWER(S) ONLY) (CONT'D) Slide the blower to disengage its flange from the retaining bracket. HD0270 Flip the blower and engage its flange in the back wall retaining bracket. Using a 5/16" socket and the screws previously IGHT OUNTING removed, secure the blower to the hood.
-
Page 11: Install The Hood
9. INSTALL THE HOOD (ALL BLOWERS) INTERNAL BLOWER: Run power cable to installation location. Remove wiring cover and place the hood in its location. Mark the position of the screws (smaller part of the key holes [A]) with a pen. Remove the hood and install the four 1/2" double thread screws at marked positions, leaving a 1/8"... -
Page 12: Led Lighting
12. LED LIGHTING The lighting of this hood is produced by two LED modules (included). WARNING Do not touch lamps during or soon after operation. Burns may occur. Cannot be replaced by any other type of light bulb or LED module. 13. -
Page 13: Operation
14. USE AND CARE Baffle Filters The baffle filters should be cleaned frequently. Use a warm detergent solution. Wash often if your cooking style generates a lot of grease— like frying food or wok cooking. Remove baffle filters by pushing them towards the back of the hood and rotating them downward. Baffle filters are dishwasher safe. Allow filters to dry completely before reinstalling them in the hood. -
Page 14: Warranty
ONE YEAR LIMITED WARRANTY FOR BROAN ELITE PRODUCTS Venmar Ventilation ULC warrants to the original consumer purchaser of Broan Elite products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. LED modules and LED driver are also covered by this warranty for a period of one (1) year. -
Page 15: Wiring Diagrams
17. WIRING DIAGRAMS Broan Elite E64000LC Series Internal blower(s) hoods USE ONLY WITH APPROPRIATE NEON MAKE-UP AIR SYSTEM BLOWER MOTOR ORA ORA 9408 FAN SWITCH A A A A MAIN SWITCH THERMOSTAT LINE NEUTRAL GROUND LED CONTROL COLOR CODE BLACK... -
Page 16: Service Parts
18. SERVICE PARTS Broan Elite E64000LC Series Broan Elite E64000LC Series Internal blower hoods Exterior or In-Line blower hoods HL0238 HL0239 . (H . (H OOD WIDTH OOD WIDTH ESCRIPTION ESCRIPTION 30" 36" 42" 48" 30" 36" 42" 48" 62612 SV13296 3¼"...
