INSTALLATION INSTRUCTIONS
HB0072
E64000 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14.
Broan-NuTone Canada Inc., Mississauga, Ontario www.broan.ca 877-896-1119
REGISTER YOUR PRODUCT ONLINE AT: www.broan.ca
SV20343 rev. 03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elite E64000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Broan Elite E64000 Series

Summary of Contents for Broan Elite E64000 Series

  • Page 1 INSTALLATION INSTRUCTIONS HB0072 E64000 SERIES INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14. Broan-NuTone Canada Inc., Mississauga, Ontario www.broan.ca 877-896-1119 REGISTER YOUR PRODUCT ONLINE AT: www.broan.ca...

  • Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following

    Use an appropriate make-up air device or open a window close to or in the kitchen. 10. To reduce the risk of fire and electric shock, the Broan Elite E64E Series hood must be installed with one Broan exterior blower model 331H, 332H, 335 or 336;...
  • Page 3 ORIZ RONT ORIZ IGHT ORIZ DAPTER AMPER 3¼" 10" SUPPLIED WITH SINGLE BLOWER HOOD 4½" 18½" DAPTER SUPPLIED WITH E64000 SERIES HOOD DOUBLE BLOWER HOOD (1100 OUBLE LOWER 36" 42" (1200 OUBLE LOWER (600 48" INGLE LOWER ONLY RMP SERIES BACKSPLASH...
  • Page 4 HLB3 (280 ODEL LINE LOWER 8" 10" INCLUDES ONE ROUND TRANSITION ODEL (10" R OUND ECTIONS E64000 SERIES HOOD 332KR LINE AND XTERIOR LOWER OUGH SUPPLIED WITH HOOD RMP SERIES BACKSPLASH TAINLESS TEEL WALL COVERING WITH WARMING SHELVES PTIONAL HL0098...
  • Page 5 The Broan Elite E64000 Series range hood includes many configurations: hoods with single or double internal blowers (included with the hoods), or hoods using external blowers. For hoods using external blowers, the Broan Elite E64000 Series must be installed with in-line blower models HLB3, HLB6, HLB9 or HLB11, or exterior blower model 331H, 332H, 335 or 336 only.

  • Page 6: Prepare The Installation

    2. PREPARE THE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. NOTE: Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the manufacturer. Make sure that the following items are included: - Range hood - Accessories:...

  • Page 7: Install Backsplash (Optional)

    2. PREPARE THE INSTALLATION ( CONT’D Cut-out the openings for duct (A) and power cable (B), in cabinet or wall, according to the direction of discharge chosen. See figures below. NOTE: For all internal blower hoods, the cut-out opening for house wiring can be made in cabinet bottom OR wall, no matter the discharge chosen (vertical or horizontal).

  • Page 8: Remove The Adapter

    4. REMOVE THE FILTERS AND THE GREASE DRIP RAIL A. Remove tape on filters. Remove filters from hood and set aside. NOTE: It is recommended to start with the center one(s). B. Remove tape on grease drip rail (1). Lift out grease drip rail and set aside. HD0240 5.

  • Page 9: Horizontal Discharge Installation

    6. CHOSE THE OPENING(S) (INTERNAL BLOWER HOODS ONLY) Remove the knockout for the chosen opening(s) (horizontal at the back of the hood or vertical on top). See illustrations below. ERTICAL DISCHARGE ORIZONTAL DISCHARGE HR0021 Punch out the appropriate electrical knockout hole on top (A) or back (B) of the hood.
  • Page 10 7. HORIZONTAL DISCHARGE INSTALLATION (INTERNAL BLOWER(S) ONLY) (CONT'D) Slide the blower to disengage its flange from the retaining bracket. HD0270 Flip the blower and engage its flange in the back wall retaining bracket. Using a 5/16" socket and the screws previously IGHT OUNTING removed, secure the blower to the hood.

  • Page 11: Install The Hood

    9. INSTALL THE HOOD (ALL BLOWERS) INTERNAL BLOWER: Run power cable to installation location. Place the hood in its location. Mark the position of the screws (smaller part of the key holes [A]) with a pen. Remove the hood and install the (4) 1/2" double thread screws at marked positions, leaving a 1/8" gap. Remove wiring cover.

  • Page 12: Install Light Bulbs

    12. INSTALL LIGHT BULBS This hood requires 120 V, 50 W max., MR16 with GU10 base or PAR16 with GU10 base, shielded halogen lamps (not included). (2 required for 30" and 36" hood widths, 3 required for 42" and 48" hood widths.) WARNING Do not touch lamps during or soon after operation.

  • Page 13: Operation

    14. USE AND CARE Baffle Filters The baffle filters should be cleaned frequently. Use a warm detergent solution. Wash more often if your cooking style generates greater grease—like frying foods or wok cooking. Remove baffle filters by pushing them towards the back of hood and rotating filters downward. Baffle filters are dishwasher safe. Allow filters to dry completely before reinstalling them in the hood.

  • Page 14: Warranty

    ONE YEAR LIMITED WARRANTY FOR BROAN ELITE PRODUCTS Broan-NuTone Canada (Broan-NuTone) warrants to the original consumer purchaser of Broan Elite products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

  • Page 15: Wiring Diagrams

    17. WIRING DIAGRAMS Broan Elite E64000 Series Internal blower(s) hoods USE ONLY WITH APPROPRIATE NEON MAKE-UP AIR SYSTEM BLOWER MOTOR ORA ORA 9408 FAN SWITCH A A A A MAIN SWITCH THERMOSTAT LINE NEUTRAL GROUND LAMP SWITCH COLOR CODE BLACK...

  • Page 16: Service Parts

    18. SERVICE PARTS Broan Elite E64000 Series Broan Elite E64000 Series Exterior or In-Line blower hoods Internal blower hoods HL0179 HL0167 . (H . (H OOD WIDTH OOD WIDTH ESCRIPTION ESCRIPTION 30" 36" 42" 48" 30" 36" 42" 48" SV13296 3¼"...
