- Page 1 22” HD Ready Digital LCD TV Instruction Manual L22DIGB10 L22DIGB10_IB_110126_Annie.indd 1 11年1月26日 下午4:58...
- Page 2 L22DIGB10_IB_110126_Annie.indd 2 11年1月26日 下午4:58...
-
Page 3: Table Of Contents
Contents Perparation ......................................5 Unpacking the TV ..........................................5 Installing / Removing the Base Stand ..................................6 Front / Top View and Controls......................................7 Rear View and Sockets ........................................8 Installing Batteries in the Remote Control ................................9 Remote Control Operation Range ....................................9 Remote Control ..........................................10 Connections . - Page 4 Customising the TV Settings (DTV Mode) ................................28 − Auto Tuning ........................................... 28 − Manual Tuning ........................................29 − Channel Edit .......................................... 29 − Timer ............................................30 − Rating ............................................30 − CI (Common Interface) (DTV Mode) ................................31 Customising the TV Settings (PC Mode) ................................. 32 Customising the TV Settings (HDMI and YPbPr Modes)............................
-
Page 5: Perparation
Thank you for purchasing your new Logik 22” HD Ready Digital LCD TV. Your new TV has many features and incorporates the latest technology to enhance your viewing experience. We recommend that you spend some time reading this instruction manual in order that you fully understand these features. -
Page 6: Installing / Removing The Base Stand
Installing / Removing the Base Stand • Remove the base stand before mounting the TV onto the wall. • The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. -
Page 7: Front / Top View And Controls
Front / Top View and Controls Item Description Receives IR signals from the remote control. IR (Infrared Receiver) Do not put anything near the sensor, as its function may be affected. Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby POWER LED mode. -
Page 8: Rear View And Sockets
Rear View and Sockets ON OFF CARD FACE FRONT Item Description POWER ON/OFF Switch on the POWER ON/OFF switch to turn the TV to standby mode. Connect the mains cable to the mains socket. Connect earphones for private listening. RF (75 Ω) Connect to the aerial socket on the wall with the RF coaxial cable. Connect to the Composite VIDEO and AUDIO (L/R) output sockets on external video VIDEO / AUDIO (L/R) devices. -
Page 9: Installing Batteries In The Remote Control
Installing Batteries in the Remote Control 1. Press and lift the back cover up to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( – ) ends of the batteries with the (+) and ( – ) ends indicated in the battery compartment. -
Page 10: Remote Control
Remote Control Switch the TV between on and standby mode. Mute and restore your TV sound. 3 P.MODE Selects picture mode: Personal / Standard / Movie / Mild / Game. S.MODE Selects sound mode: Standard / Music / Voice / Theatre / Personal. - Page 11 13 SOURCE Select among the different input signal sources: DTV / TV / AV / S-VIDEO / SCART / YPBPR / HDMI / PC 14 CH +/- Select a channel. 15 VOL +/- Adjust the volume. 16 MENU Display the OSD (On Screen Display) menu. 17 EXIT Exit the OSD (On Screen Display) menu.
-
Page 12: Connections
Connections Making Video and Audio Connections Not all AV devices have the ability to connect to a TV, please refer to the owner’s manual of your AV device for compatibilty and connection procedures. When connecting any external AV device, do not connect the mains cable to the mains socket until all other connections are complete. -
Page 13: Connecting A Computer With Vga Cable
Connecting a Computer with VGA Cable 1. Use a VGA cable to connect the TV’s VGA input Right Rear Side View of TV socket to a computer’s VGA output socket. Use an audio cable to connect the TV’s PC AUDIO input socket to the computer’s audio output socket. CARD FACE FRONT 2. Plug the connected devices into the mains socket before switching on the POWER ON/OFF switch... -
Page 14: Connecting An Av Device With Scart Cable
Connecting an AV Device with SCART Cable Right Rear Side View of TV 1. Use a SCART cable to connect the TV’s SCART input socket to an external AV device’s SCART output socket. CARD FACE FRONT 2. Plug the connected devices into the mains socket before switching on the POWER ON/OFF switch at the side of the TV. -
Page 15: Connecting An Av Device With Composite Cable
Connecting an AV Device with Composite Cable Right Rear Side View of TV 1. Use the supplied AV cable to connect the TV’s AUDIO(L/R)/VIDEO input sockets to an external AV device’s composite audio/video sockets. (Video = yellow, Audio Left = white, and Audio Right = red) CARD FACE FRONT 2. Plug the connected devices into the mains socket before switching on the POWER ON/OFF switch... -
Page 16: Connecting A Usb Storage Device
Connecting a USB Storage Device Right Rear Side View of TV 1. Switch off the TV before connecting any USB storage device. 2. Connect your USB storage device to the USB port of CARD FACE FRONT your TV. 3. Plug the connected devices into the mains socket before switching on the POWER ON/OFF switch at the side of the TV. -
Page 17: Initial Setup
Initial Setup Turning the TV On for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. Switch on the POWER ON/OFF switch at the side of the TV. At this stage, the TV switches to standby mode. The red LED indicator will illuminate on the front panel of the TV. -
Page 18: Channel Selection
Channel Selection Press the CH + / – buttons repeatedly or the 0-9 buttons to select the channel. • Alternative In DTV mode, press the OK button to enter the Channel List. Then use the buttons to highlight and select the channel. Press the OK button to view the selected channel. -
Page 19: Using The Features
Using the Features Customising the PICTURE Setting Picture Mode Allows you to set your preferred picture mode. 1. Press the MENU button and then use the buttons to select the PICTURE menu and then press the button. 2. Press the buttons to highlight an individual Picture option. 3. Press the buttons to change the following settings. -
Page 20: Customising The Sound Setting
Customising the SOUND Setting Sound Mode Allows you to select an audio-enhancement technique. 1. Press the MENU button and then use the buttons to select the SOUND menu and then press the button. 2. Press the buttons to highlight an individual Sound option. 3. Press the buttons to change the following settings. -
Page 21: Customising The Function Setting
Customising the FUNCTION Setting Video Size Allows you to watch the screen in various picture formats. For TV Mode, Auto / Full / 4:3 / 14:9 / Zoom are the available options. For DTV mode, Auto / Full are the available options. For YPbPr and HDMI mode, Full / 4:3 are the available options. 1. Press the MENU button and then use the buttons to select the FUNCTION menu and then press the... -
Page 22: Tt Language
TT Language Allows you to select your preferred Teletext language. 1. Press the MENU button and then use the buttons to select the FUNCTION menu and then press the button. 2. Press the buttons to select TT Language. 3. Press the buttons to change the settings. 4. Press the MENU button to save the setting and return back to the previous menu. -
Page 23: Osd Timer
OSD Timer Allows you to select the display time of the on-screen menu. 1. Press the MENU button and then use the buttons to select the FUNCTION menu and then press the button. 2. Press the buttons to select OSD TIMER. 3. Press the buttons to select time: 5 / 10 / 30 / 60 sec / NEVER. -
Page 24: Key Locked
4. Press the button and then press the button to select CHANGE CODE. 5. Use the 0–9 buttons to input a 4-digit password. • The default password is “0000”. • If you change the password, be sure to remember the new password! If you forget your password, press the master password “8899”... -
Page 25: Reset
Reset Restores all settings to factory defaults. 1. Press the MENU button and then use the buttons to select the FUNCTION menu and then press the button. 2. Press the buttons to select RESET and then press the OK button or the button. -
Page 26: Customising The Tv Setting (Tv Mode)
Customising the TV Setting (TV Mode) Country Allows you to select the country where you are using the TV. 1. Press the MENU button and then use the buttons to select the TV menu and then press the button. 2. Press the buttons to select COUNTRY. 3. Press the buttons to select the country: UK, Italy, Spain, France, Germany and Other. -
Page 27: Manual Tuning
Manual Tuning Allows you to make manual fine tuning adjustments if the channel reception is poor under TV mode. 1. In the TV menu, press the buttons to select MANUAL TUNING and then press the OK button or the button. 2. Press the buttons to change the following settings. -
Page 28: Customising The Tv Settings (Dtv Mode)
To Lock a. Press the buttons to highlight a channel and then press the BLUE button. b. Press the BLUE button again to unlock. To Move a. Press the buttons and then press the button to select a channel. b. Press the buttons to move the selected channel. -
Page 29: Manual Tuning
Manual Tuning Allows you to make manual fine tuning adjustments if the channel reception is poor under DTV mode. 1. Press the MENU button and then use the buttons to select the DTV menu and then press the button. 2. Press the buttons to select MANUAL TUNING and then press the OK button or the button. -
Page 30: Timer
Timer Timer programming is only available when a USB storage device is connected. 1. Press the MENU button and then use the buttons to select the DTV menu and then press the button. 2. Press the buttons to select TIMER and then press the OK button or the button. -
Page 31: Ci (Common Interface) (Dtv Mode)
CI (Common Interface) (DTV Mode) The common interface allows the use of a Common Access Module to enable you to view scrambled (pay to view) services. These services are provided by TopUp TV (UK only) and others. The Common Access Module and viewing card can be obtained from the service provider. -
Page 32: Customising The Tv Settings (Pc Mode)
Customising the TV Settings (PC Mode) Allows you to adjust the PC desktop content. 1. Press the MENU button and then use the buttons to select the PC menu and then press the button. 2. Press the buttons to highlight an individual PC Position option. 3. Press the buttons to change the following settings. -
Page 33: Teletext (Tv Mode)
Teletext (TV Mode) Teletext is a free service broadcast by some TV stations which gives up-to-the-minute information on news, weather, television programmes, share prices and many other topics. Using the Teletext control buttons you can view pages of information that are listed in the teletext index. To Turn on Teletext Function •... -
Page 34: Digital Teletext (Dtv Mode)
Digital Teletext (DTV Mode) Digital teletext can access special digital teletext services and specific services which broadcast digital teletext. The subtitle will temporarily auto off when digital teletext function is turned on. Teletext within Digital Service 1. In DTV mode, press the OK button to display the Channel List. Press the buttons to select a channel with a icon displayed. -
Page 35: Using The Features Via Usb Port
Using the Features via USB Port My Album 1. Press the SOURCE button and select DTV mode and then press the MEDIA button. 2. Press the buttons and then press the OK button to select My Album. 3. Press the BLUE button to open the directory. Press the buttons to select your desired folder and then press the OK button to enter the folder. -
Page 36: My Music
My Music 1. Press the SOURCE button and select DTV mode and then press the MEDIA button. 2. Press the buttons and then press the OK button to select My Music. 3. Press the buttons to navigate in the music folder. Select the music you want to play and then press the OK button to play it. -
Page 37: My Recorder
3. If more than one USB storage device is connected, press the DISPLAY button to switch to the device type menu. Press the buttons to select the active device and then press the OK button to confirm. 4. Press the buttons to navigate in the movie folder. -
Page 38: Recording Device
To Play a. In the Recorded List, press the buttons to select the recorded programme you want to view. b. Press the GREEN button to preview the recorded programme and then press the OK button to play the selected programme. • If the selected programme was stopped before it had finished the last time you viewed it, the “DVR PLAY OPTION”... -
Page 39: Recording Preference
2. Press the buttons to adjust the settings. Device Type Indicates that a USB device is connected. Slot Select the active USB storage device connected to the USB hub slot (1 Partition Select the active partition (1 … max.15) on the selected USB device. 3. Press the RED button to select Format. -
Page 40: Dvr (Digital Video Recorder)
DVR (Digital Video Recorder) Time Shift Function This function allows the TV to automatically record live TV and make it available for viewing at any time. With the Time Shift Mode set to Auto or Pause, you may pause or rewind normal TV viewing at any time without missing any of the live broadcast. -
Page 41: Recording Dtv Programme Onto A Usb Storage Device
Recording DTV Programme onto a USB Storage Device Use this function to record the DTV programme you are watching on the main screen and save them for future viewing. You may use the DVR Time Shift function during recording to view the recorded programme instantly. Please refer to the section “Time Shift Function”... -
Page 42: Timer Programming
Timer Programming This function is used to perform scheduled recording. 1. Press the EPG button on the remote control. The EPG menu will appear. 2. Press the RED button on the remote control to enter the Timer Programming menu. Alternative 1. You may press the MENU button and then use the buttons to select the DTV menu and then press the button. -
Page 43: Maintenance
Maintenance Maintenance Careful and regular cleaning can prolong the life of your TV. Be sure to switch off the POWER ON/OFF switch and disconnect the mains cable from the mains socket before you start any cleaning. 1. Use a soft dry cloth to wipe away the dust from the screen and surfaces. 2. If the surfaces are extremely dirty, clean the TV with a cloth which has been dipped in a weak soapy water. -
Page 44: Hints And Tips
Hints and Tips The audio function does not work. • Press the VOL + / - buttons. Picture OK but no sound • Sound muted? Press the button. • Try another channel. The problem may be caused by the broadcaster. No output from one of the speakers • Adjust the Balance settings in the SOUND menu. • A change in ambient humidity or temperature may result in an unusual noise when Unusual sound from Inside the TV the TV is switched on or off and does not indicate a fault with the TV. -
Page 45: Display Modes
Display Modes Display Modes The screen resolution has been optimised during production for the display modes listed below. Whilst the TV is capable of accepting a 1080p input, it is not capable of displaying this screen resolution and therefore the display will be scaled to fit the native resolution of the screen automatically. YPbPr Mode Resolution Vertical Frequency (Hz) -
Page 46: Specification
Specification Specification Model L22DIGB10 Panel System 21.6 inch LCD panel Display Resolution 1366 pixels (horizontal) x 768 pixels (vertical) Television System PAL I/BG/DK, SECAM L/BG/DK Brightness 300-350 cd/m Contrast Ratio 600-1000:1 Inputs/Output SCART HDMI PC AUDIO S-VIDEO YPbPr VIDEO IN (RCA) AUDIO IN (RCA) 1 (L + R) RF (75 Ω) -
Page 47: Safety Warnings
Safety Warnings Safety Warnings Safety • Read all the instructions carefully before using the unit and keep them for future reference. • Always disconnect the unit from the mains supply before connecting/disconnecting other devices or • Retain the manual. If you pass the unit onto a third moving the unit. - Page 48 Earphones CAUTION • Listening to loud sounds for prolonged periods of time may permanently damage your hearing. RISK OF ELECTRIC SHOCK DO NOT OPEN • Before putting on earphones, turn the volume down The lightning flash with arrowhead symbol, then put the earphones on and slowly increase the within an equilateral triangle, is intended to volume until you reach a comfortable listening level.
- Page 49 If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number Remote Control I.14.000000740 Batteries (x2) E.17.101570001 AV Cable E.14.113150013 Mains Cable E.14.050150900 TV Stand Support I.01.526226381 Base Stand I.01.526226311 Screw A x 4 I.03.TW3012A01 Screw B x 4 I.03.MP4010001...
